Modt i975Xa– YDG Quick Manual

i975Xa– YDG
i975Xa– YDG
May the Dual Force be with you
Realtek HDA CODEC
Marvell Gigabit LAN Chip
Printer Connector
PCI Express x 1 Slot x 2
COM Connector
32-bit PCI Expansion Slot x 2
Stand by LED
FDD Connector
Front Audio Connector
IEEE 1394 Connector
Power Master Ready II LED
USB 2.0 Connector x 2
Front Panel Connector
Power Master II Jumper
Power Master II Connector
Reset Switch Connector
Power Switch Connector
AOpen reserves the right to revise all the specifications and information contained in this
document, which are subject to change without notice.
IEEE 1394 Port RJ45 LAN Jack
PS2 Mouse
PS2 Keyboard Serial ATA II USB 2.0 Ports
S/PDIF Out
Line-In
Rear Surround
Speaker Out
Sub-woofer
MIC-In
Side Surround
S/PDIF In
CD_In Connector
JP28 PS2 KB/Mouse Wakeup Jumper
4-pin 12V ATX Power Connector
1x4 Peripheral Connector
J4, J5 Front Side Bus Frequency Jumper
PCI Express x16 Slot x 2
ATA133 IDE Connector x 2
479 PIN Socket Supporting Intel Core
Due/Solo Processor
JP14 CMOS Data Clear Jumper
Intel 975X / ICH7
Boot LED
CPU Fan Connector
240-pin DDR II DIMM x 4
Serial ATA II Connector x 4
System Fan1 Connector
Power Fan Connector
ATA100 IDE Connector
24-pin ATX Power Connector
