Summary of Contents for BIGHA BIKE

  • Page 1 Owner’s Manual...

  • Page 2: Table Of Contents

    Batteries…………………………………………………………………………...20 Section 3: Maintenance, Repair and Adjustments Adjusting the Shock………………………………………………………………21 Adjusting the Brakes……………………………………………………………...21 Shifting Adjustments……………………………………………………………...22 Seat Adjustments………………………………………………………………….23 Handlebar Adjustments…………………………………………………………...26 Turning the bike Upside Down…………………………………………………...26 Rear Wheel Removal/Installation………………………………………………...27 Front Wheel Removal/Installation………………………………………………..31 Changing the Batteries……………………………………………………………33 Folding/Unfolding for Storage……………………………………………………34 Removing/Installing Front Fender………………………………………………..35 BiGHA...

  • Page 3: Section 1: Getting Started

    Getting Started...

  • Page 4: Unpacking

    You only need to unfold the handlebars and attach the seat. Here’s how to do it: 1. Start by opening the box. Place one foot inside the box and lift the bike so it’s standing on both wheels. Now pick the bike up and set it outside the box. Make sure you kick the kickstand down so it stands on its own.
  • Page 5 6. Now it’s time to adjust the seat to your leg reach. Start by sitting on the bike with the kickstand up. Open the seat lever by pulling it away from the bike.

  • Page 6: The First Ride

    How to master your new BiGHA You’re ready to take your first spin on a BiGHA. Riding the bike should be easy, but don’t sweat it if you don’t pick it up immediately. It’s a new exercise, and like anything, it takes some getting used to.

  • Page 7: Customizing Your Bigha

    Do you find the steering to be twitchy and difficult to balance? If so, you’re over-steering the bike. Quite literally, you need to sit back in the seat and relax your upper body, especially your arms and shoulders. Pretend you’re sitting in your car seat and your arms are draped over the steering wheel.
  • Page 8 In case you forgot how to do this, just stand in front of the bike with the wheel sandwiched between your legs. Now twist the handlebar stem until it’s aligned with the front wheel.
  • Page 9 Twist knob Shifting Gears: Your BiGHA has 27 gears. Nine gears are on a standard chain ring – otherwise known as a cassette – and three riding modes are available via an internal hub.

  • Page 10: Powering The Electronics

    Tip: You can see the internal hub on your rear tire – it’s the silver piece of metal in the center. Now look at the drive side of the bike, directly above the derailleur. There’s another gray and black component called the Clickbox.

  • Page 11: Section 2: Using Your Electronics

    Using Your Electronics...

  • Page 12: Electronics Operation

    It starts again automatically whenever you move the bike or press any button. You bike is shipped in hard off condition to preserve battery life. When yo u first get the bike you’ll need to press the right turn signal button once. Normal operations should immediately begin.

  • Page 13: Console Operation

    Automatic startup of the electronics can be a problem when you are transporting the bike. If you mount the bike on a car rack and start driving, the car’s motion will make the bike think it is in use, wasting valuable battery energy. A feature called “hard off” is provided to overcome that problem.

  • Page 14: English/Metric Display

    English/Metric Display BiGHA can display measurements of speed, distance, elevation and temperature in either English or metric. To alternate between the two formats simply do a long press on the select button (the middle button with the green stripe).

  • Page 15: Altitude Adjustments

    120 feet when Jim parked it after a long ride. That night a weather system moved in and changed the barometric pressure. But when Jim gets on his bike the next day his altimeter still displayed 120 feet. Why? BiGHA’s altimeter is self regulated by a motion detector.

  • Page 16: Clock

    Even if your altimeter’s absolute readings are distorted by changes in the weather, BiGHA’s altimeter will still accurately register changes during your ride. So if you climb a 300 foot hill, you’ll still see a net elevation gain of 300 feet on your altimeter regardless of whether or not the base reading is correct.
  • Page 17 You may notice a little bouncing around of your altimeter’s last diigt. Your bike can be sitting still and have altimeter readings of 260 then 259, 258 and back to 260. We’re working to filter out such noise and still provide you moment by moment altitude updates as you descend steep hills, etc.
  • Page 18 Clock BiGHA’s bike clock is quite accurate: to within about four minutes a year. But daylight savings time or moves to other time zones brings the need to change even the most accurate clock. Doing so is easy. Just make a long Down press from the Odometer screen to enter the Calibration screen.
  • Page 19 A good goal is one complete turn in 15-20 seconds. When you’ve finished the circle, make a long press on the Up key. The Odometer screen returns. Turn your bike in a circle again to check that the compass is working. It will stay...

  • Page 20: Batteries

    Batteries From time to time you will need to change the batteries in your BiGHA. Just how often your batteries need depends on a number of variables – how often you ride, use of turn signals, horn and alarm, use of light, even the climate – that makes it impossible to tell when you’ll have to change them.
  • Page 21 Maintenance and Repair...

  • Page 22: Adjusting The Shock

    As a general guideline, one full rotation of the shock is equal to a 15 pound adjustment. So if you weigh 150 lbs and you loan your BiGHA to a 175 lb friend, you should turn the twist the shock clockwise almost 2 full rotations.

  • Page 23: Shifting Adjustments

    When you shift gears, you apply tension to a cable that stretches from the handlebar to the derailleur in the rear of the bike. When you shift into an easier gear, you pull on this cable. When you shift into a more difficult gear, you release tension.

  • Page 24: Seat Adjustments

    Find the barrel adjuster that attaches to the back of your thumb lever. Twist the adjuster one or two clicks at a time and then test to see if the bike shifts properly into a lower gear. Then make sure the bike shifts properly into a higher gear. You may have to go back and forth a time or two until the shifter shifts up and down without hesitation.
  • Page 25 Tools needed: none 1. Find the air stem located under the seat cushion on the non-drive side of the bike. 2. Get off of the seat and open the stem by twisting it counter-clockwise. The cushion will fill up with air. Now close the stem.
  • Page 26 2. Use the wrench to loosen the black screws underneath the seat cushion. The screws are easy to spot as they’re resting on top of silver washers. There is one screw on each side of the bike – make sure you loosen both.

  • Page 27: Handlebar Adjustments

    In case you forgot how to do this, just stand in front of the bike with the wheel sandwiched between your legs. Now twist the handlebar stem until it’s aligned with the front wheel.

  • Page 28: Removing The Rear Wheel

    If you don’t have a stand, you’ll need to turn the bike upside down to perform various maintenance tasks such as removing the rear wheel. Tool required: None 1. Find the silver thumbscrew underneath the seat and turn it counterclockwise.
  • Page 29 3. Find the gray Clickbox on the left side of the rear wheel. Locate the black button on center of the Clickbox and pus h it up (if the bike were right side up, you’d be pushing down). Push button upwards With the button pushed down, pull the Clickbox away from the bike.

  • Page 30: Installing The Rear Wheel

    Remember, there is a nut and washer on each side of the bike. It is not necessary to remove the nuts or washers, Loosen nut and but should they come off the bike, be sure not to washer on brake side lose them. of bike.
  • Page 31 2. It’s easiest to install the rear wheel with the bike in 9th gear. To switch gears, stand to the left side of the bike with one hand on the pedal and the other on the twist shifter. Spin the pedal with your left hand as you twist into 9 gear with your right.

  • Page 32: Removing The Front Wheel

    9. Now you’re ready to reinstall the Clickbox. Double check to make sure the thumb lever is in the uphill riding mode. Since the bike is upside down, the thumb lever should be pushed all the way to the right, or towards the inside of the bike.

  • Page 33: Changing The Batteries

    The wheel should drop away from the bike. Lift bike, hold wheel down. 4. Fold the kickstand up and balance the front of the bike on the fork. Balance bike on fork. Installing the front wheel: Tools needed: none 1.
  • Page 34 Folding the bike for storage: 1. Loosen the thumbscrew underneath the seat. Remove the seat. 2. Standing on either side of the bike, hold both break levers while pushing the handlebars (and steering mast) forward. You may want to loosen the steering mast pivot if you can’t push the handlebars...
  • Page 35 2. Swing the handlebars away from the frame until they’re pointing forward. 3. Standing on one side of the bike, use one hand to push down on the frame while the other pulls the steering mast into it’s riding position.
  • Page 36 Installing the front fender: Tools needed: 1. right angle Phillips screwdriver 1. Remove the front wheel. 2. Push fender up into the fork. Align the holes on the fender with the screw holes on the fork. Insert Phillips screws into each hole and tighten...

  • Page 37: Safety Tips

    Safety Tips...
  • Page 38 And be sure to signal your intentions when changing speed or direction. 6. Ride a bike that fits. Adjust your seat to match your leg length. See XXX for details. Make sure handlebars are set high enough that your knees don’t hit them when you pedal.
  • Page 39 Wheels. Lift each wheel off the ground and give it a quick spin. It should turn true, without any wobble. Make sure brake discs don’t rub either. If the wheel does not spin true, seek the help of a bike shop or qualified bike mechanic.
  • Page 40 Never ride with two people on the bike. Use a trailer to tow small children, pets or heavy loads. c. The optional cargo rack mounts over the rear wheel and is rated for a maximum of 30 pounds. Don’t overload it.
