Panasonic TH-55LFV50 Specifications

Installation Examples
Transportation Shop signage
Product specification
Model No. TH-55LFV50
DISPLAY
Screen Size (Diagonal) 54.6-inch (1,387 mm)
Aspect Ratio 16:9
Panel Type IPS / DIRECT LED
Number of Pixels (H x V) 1,920 x 1,080 pixels
Brightness 800 cd/m 2
Contrast Ratio 1,400:1
Response Time 10 ms (G to G)
Viewing Angle 178°/178°
(Horizontal/Vertical)
CONNECTION TERMINAL
VIDEO In BNC x 1 (Shared with Component-Y)
Audio In (L/R) RCA Pin Jack x 1 set (Side) (Shared with Component In)
HDMI In HDMI Type A x 1
Component In BNC x 3
Audio In (L/R) RCA Pin Jack x 1 set (Side) (Shared with VIDEO In)
DVI-D In DVI-D 24-pin x 1
Audio In (L/R) M3 Jack x 1 (Shared with PC In)
PC In Mini D-Sub 15-pin x1 (Female)
Audio In (L/R) M3 Jack x 1 (Shared with DVI-D In)
DVI-I Out DVI-I 29-pin x 1
Audio Out (L/R) RCA Pin Jack x 1 set
CONTROL
Serial In/Out D-Sub 9-pin x 1/D-Sub 9-pin x 1, RS-232C Compatible
LAN RJ45 x 1 (Web Browser Control Only)
IR Transmitter In/Out IR x 1/ x 1
AUDIO
Speaker Out External Speaker Terminal, 20 W [10 W/8 Ω + 10 W/8 Ω ]
ELECTRICAL
Power Requirements 110-127 V AC, 50 Hz/60 Hz (U model)/220-240 V AC, 50/60 Hz, (W model)
Power Consumptions 320 W
Stand-by Conditions Approx. 0.5 W
MECHANICAL
Dimensions (W x H x D) 1,215.5 x 686.3 x 121.2 mm (47.85" x 27.02" x 4.77")
Bezel Width 3.4 mm (0.14") [Left/Top], 1.9 mm (0.08") [Right/Bottom]
Weight Approx. 36.0 kg (Approx. 79.3 lbs)
ENVIRONMENTAL
Operating Environment Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Humidity: 10% to 90% (Non condensation)
Event venue
Connection Terminal
Control unit
Imaging unit
Sound unit
Optional Accessories
Slim Even with the Optional
Attaching the cover frame to the unit provides
Cover Frame Attached
even stronger protection against impacts.
The screw holes for attaching the frame
cannot be seen, so they do not adversely
affect the beauty of the display.
Cover Frame Kit
TY-CF55VW50
Remote Control Kit
TY-RM50VW
Calibration Kit
•Device Driver Disc
ACS-SCKIT
•USB/RS232C Converter
•RS232C F/F Changer
(Cross Type)
•Dongle for
For details, please consult your nearest dealer.
Calibration Software
Calibration Software
and Operation Manual
Panasonic video walls are color-adjusted for multi-screen use when they are shipped from the factory.
Each Panasonic TH-55LFV50 model is individually adjusted for brightness and color temperature prior to being shipped. This minimizes the
possibility of color differences between displays when they are installed as a video wall.
•There are cases, however, when fine visual adjustments are needed once the video wall is installed.
Simulated pictures on screen.
Design and specifications are subject to change without notice.
As of July 1, 2013
CT13-G02PF-LFV
A Super Narrow Bezel for
Optimal Multi-Screen Layouts.
For Displays with High Brightness and Visibility
1.
Narrow Bezel
2.
High Visibility
3.

Low Power Consumption

For more information about Panasonic professional displays, please visit:
panasonic.net/prodisplays
Super Narrow Bezel LED LCD Display
TH-55LFV50
55-inch class
55''
