Summary of Contents for Mantis C2000
-
Page 2: Table Of Contents
C2000 Mercedes Application Guide Contents USING THIS GUIDE ....................3 DECLARATION..........ERROR! BOOKMARK NOT DEFINED. CERTIFICATION AND SAFETY APPROVALS............5 INTRODUCTION ...................... 6 ..............6 LUETOOTH ECHNOLOGY C2000 B ....6 BOUT THE ANTIS LUETOOTH ANDSFREE ..............7 RODUCT PECIFICATIONS ................ -
Page 3: Using This Guide
Without written permission from Mantis Wireless Products, reproduction, transfer, distribution or storage of part or all of the contents in this document in any form is prohibited. Mantis Wireless Products reserves rights to make any changes and improvements to the product described in this document without prior notice. -
Page 4: Declaration
C2000 Mercedes Application Guide 2. Declaration Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your device. Operate Your Vehicle Safely: Using any electronic device while driving, especially a mobile phone, can be extremely dangerous. -
Page 5: Certification And Safety Approvals
C2000 Mercedes Application Guide 2. Certification and Safety Approvals This product has been tested and found to comply with Bluetooth BQB requirements, part 15 of FCC rules, R&TTE Directive 99/5/EC or CE marked requirements. Warning: Users should not make changes or modify the device in any way. Changes or modifications without expressly approved by the party responsible for compliance could void the user’s authority to operate the device. -
Page 6: Introduction
About the Mantis C2000 Universal Media Bluetooth (UMB) Handsfree Car Kit This Mantis Wireless UMB interface is a 4 in 1 device designed to provide USB interconnect to mass storage class devices (MSC) as flash drives and portable hard drives as well as interconnect to most popular media players as Zune, SanDisk, Sansa, authenticate iPod, iPhone and navigate them via the head unit interface. -
Page 7: Product Specifications
C2000 Mercedes Application Guide Product Specifications Bluetooth V2.1 compliant, Class II, operating range up to 10 meters Supports mobile phone based voice commands including voice dialing Universal Media and Bluetooth Controls Control and Play IPod or any Mp3 player from the Head Unit ... -
Page 8: Installing The Handsfree Car Kit
To prevent damage to your vehicle or its components, we highly recommend you have the C2000 Universal Media Bluetooth Handsfree Car Kit installed by a professional installer. The installation instructions in this guide are recommendations only. Mantis is not responsible for any damage to your vehicle or the device that result from improper installation or operation. -
Page 9: Mount The Microphone
C2000 Mercedes Application Guide Alternate Mounting Location for Microphone 4.2.2 Mount the Microphone Mount the Microphone to the Sun Visor Fasten the mounting clip to the sun visor. Mount the microphone to the mounting clip. Point the Microphone towards the Driver... -
Page 10: Umb Installation
C2000 Mercedes Application Guide Power USB Host Interface Configuration switch Most 2+4 FO MoConnec 5.3 UMB Installation Step 1: Remove the navigation screen and the radio tuner to begin your installation and set them aside. - Page 11 Step 3: On the Factory optical insert, press the blue lock out to remove it as shown on the drawing Step 4: On the C2000 optical plug repeat the previous 2 steps and remove the lock...
- Page 12 C2000 connector to the output of the factory connector Step 7: On the C2000 optical plug take the optical lead removed from the output of the factory connector and insert it into the output of the C2000 connector...
- Page 13 C2000 Mercedes Application Guide Step 8: The final assemble will look like this Step 9: Plug back the insert with leads into the C2000 and the Factory connector Step 10: Crimp the black wire to the ground and the red wire...
- Page 14 C2000 Mercedes Application Guide Step 11: Connect the MOST and the Power plugs to the rear C2000 panel Step 12: Connect the USB and the microphone plugs to the front panel of the C2000 Installation Kit Includes: UMB Module, 2+4 MOST Harness,...
-
Page 15: Bluetooth Set-Up
C2000 Mercedes Application Guide 5.4 Bluetooth Set-up NOTE: Before connecting the C2000 unit verify that the Portable Audio system tab is enabled Step1: USB’ and ‘IPOD’ is made available by choosing the ‘CD changer’ menu. Step 2: When UMI is installed and CD changer selected the audio menu is ready for media to be inserted or phone to be paired. - Page 16 C2000 Mercedes Application Guide Step 3: The ‘Magaz.’ menu is selected; the magazine is empty if media is not inserted. Step 4: To connect to a Bluetooth device select the ‘TEL’ Button. Step 5: Pair the phone by typing *PAIR on the numeric...
- Page 17 C2000 Mercedes Application Guide Step 6: Delete pairing by typing *DEL on the numeric keyboard or *335. Step 7: When the phone is connected the antenna field strength will update on the bottom right corner and return to the audio menu.
-
Page 18: Phone And Usb Support
C2000 Mercedes Application Guide 5.5 Phone and USB Support Step 1: To dial a number select TEL menu, type the phone number and press SEND. Step 2: When call arrives it will be displayed in a pop up window. Press SEND to accept. - Page 19 C2000 Mercedes Application Guide Step 4: When the call is accepted the telephone menu will open during the call. Step 5: When hands free is paired and audio menu selected will default to the menu below. Step 6: Pair the phone by typing *PAIR on the numeric...
- Page 20 C2000 Mercedes Application Guide Step7: Delete pairing by typing *DEL on the numeric keyboard or *335 then pres SEND. Step 8: When USB drive has been inserted the audio, with start immediately and the track name will be displayed on screen.
- Page 21 C2000 Mercedes Application Guide Step 10: Selecting ‘Detail’ tab will display info for the song playing. Step 11: Selecting ‘Setting’ tab will display media player options.
-
Page 22: Ipod/ Iphone Support
C2000 Mercedes Application Guide 5.6 iPod/ iPhone Support Step 1: When iPod is connected the HU menu displays the iPod categories. Step 2: Navigate the category via the joystick or the –SEEK, SEEK+ knobs. Step 3: When ‘Magaz.’ tab is selected the category... - Page 23 C2000 Mercedes Application Guide Step 4: Change song or album by using the joystick to switch up/down or between songs left/right. Step 5: Pair iPod Touch or iPhone to the Bluetooth by entering into pairing mode. Step 6: Delete pairing by typing *DEL on the numeric keyboard...
- Page 24 C2000 Mercedes Application Guide Step 7: If no other media connected the HU will show the Bluetooth standard menu. Step 8: Navigate through iPod Touch or iPhone menus to play the songs in this mode. Step 9: Pair up to 8 devices with by repeating the...
- Page 25 C2000 Mercedes Application Guide Note: • Only one device can play at a given time • To switch between the devices use play/stop functions from the device menu • Phone hands free will have priority when place or receive call •...
