Speed Queen SCN080GF Product Specifications

ON-PREMISES LAUNDRY
FEATURES & BENEFITS
• Advanced water protection alerts owners if the
washer has a stuck drain, slow drain condition or
leaking inlet valve, which helps conserve water.
• Rugged door handle and new lock mechanism
ensure easy opening and closing and reliable locking
— no more door lock error codes.
• New dual triple-lip seals and a stainless steel sleeve
around the trunnion, deliver the strongest line of
defense in protecting the bearings against the
damaging effects of moisture.
• Four-compartment chemical dispenser adds
chemicals at the right time, automatically saving
staff time. The new dispenser design eliminates
over-sudsing conditions.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications subject to change without notice. The
quality management system of Alliance Laundry Systems' Ripon facility has been registered to ISO#9001:2000.
Printed in the U.S.A.
speedqueen.com
HARDMOUNT
QUANTUM STANDARD OPL CONTROL
For laundry managers requiring basic management options, Quantum
Standard comes with four cycle selections, two water levels and manual
programming. It also offers a maximum extraction speed of 100 G-force.
© 2012 Alliance Laundry Systems LLC AO11-0682R1
SCN080GF

PRODUCT SPECIFICATIONS

SCN080GF
Capacity
80 lb
Width 41 1/2"
Depth
51 1/2"
Height 56 3/16"
Cylinder Diameter 36"
Cylinder Depth 22"
Cylinder Volume 12.4 cu. ft.
Door Opening Size 18 1/2"
Door Bottom to Floor 17 3/4"
Wash Speeds
39 RPM
Extract Speed 443 RPM
Distribution Speed
70 RPM
Extract G-Force 100
Water Inlet
2 @ 3/4"
Drain Diameter 1 @ 3"
Drain Height To Floor 5 3/4"
Motor Size 5 HP
Electrical Specs X 200-208/220-240/50/60/1/3
Voltage/Hz/Phase
Q 200-208/220-240/50/60/3 (electric heat)
P 380-415/50/60-3
N 440-480/50/60/3
Net Weight 1262 lb
Shipping Weight
1275 lb
Shipping Width 48"
Shipping Depth
56"
Shipping Height 65 3/4"
Agency Approvals
cETLus, CE
