VTEC AIR FLOW CONVERTER
WIRING DIAGRAM BY MODEL
This document describes car models to which the VTEC Airflow
Converter II (Product code: 401-A915/401-A815) is applicable,
and ECU terminal arrangement drawings. For the operating
method and precautions for the VTEC Airflow Converter II, refer
to the Instruction Manual.
For installing the VTEC Airflow Converter II, both this document
and the Instruction Manual are required.
Even if the car model and manufacturing year coincide with the
Contents described in this document, this product may not be
installed in a special specification vehicle or remodeled vehicle.
The manufacturing years of applicable vehicles are as of March
2005.
For application to vehicles released after that, consult
the respective APEXERA business office for information.
Advertisement
Table of Contents
Summary of Contents for APEXi V-AFC II
- Page 1 VTEC AIR FLOW CONVERTER WIRING DIAGRAM BY MODEL This document describes car models to which the VTEC Airflow Converter II (Product code: 401-A915/401-A815) is applicable, and ECU terminal arrangement drawings. For the operating method and precautions for the VTEC Airflow Converter II, refer to the Instruction Manual.
- Page 2 Contents Introduction Precaution on Installation Installation ECU Arrangement Drawing How to Refer to the ECU Terminal Arrangement Drawing Table of Applicable Models ECU Terminal Arrangement Drawing Introduction “Safety precautions” are described in the Instruction Manual. Please read them before starting the installation work. “Signal words and their meanings”...
-
Page 3: Precaution On Installation
Precaution on Installation When installing this product, do not use any electro-tap in any case. Using the electro-tap makes the contact status unstable. Its contact defect may causes a malfunction to the product and damage to this product and the vehicle. Be sure to use the attached splice and dedicated tools such as cutting pliers for electric work to install the product securely. - Page 4 The ground conductor of this product has two branches (black and brown). This has a very important significance to secure the voltage conversion accuracy. Connect the ground conductor by referring to the following figure. Installing the ground conductor in a different way from the connecting method specified by A’PEX will give damage to this product and the mounted car engine.
- Page 5 .Locate the Engine Control Unit (hereafter referred to as ECU) of the vehicle by referring to the Wiring Diagram by Model. .Connect the harness attached to the V-AFC II securely to the power cable of the vehicle harness, grounding conductor, engine revolution signal wire, throttle signal wire, and TDC signal wire, VTC signal wire, and VTM signal wire that are connected to the ECU, by referring to the Wiring Diagram by Model.
- Page 6 VTEC solenoid signal Plug: VTEC solenoid side Plug receptacle: ECU side VTM signal .Connect the harness attached to the V-AFC II to the plug installed in 4. Plug receptacle: White wire Pressure sensor signal Plug: Yellow wire Plug receptacle: Purple wire...
- Page 7 Installation (cont.) Wire connecting method Red wire (IG power) Red wire (IG power) Black wire (ground) Brown wire (ground) Green wire (rpm) Gray wire (throttle signal) Orange wire (VTC cam signal) Light blue wire (TDC signal) Engine Control Unit Blue wire (VTM signal) Purple wire (VTEC solenoid signal input) Pink wire (VTEC solenoid signal output) Yellow wire (pressure signal output)
-
Page 8: Initial Setup
When passing the connecting harness of the V-AFC II, arrange the harness so as not to touch the moving portion. The connecting harness may be cut or short-circuited. The V-AFC II will be damaged, thereby giving damage to the vehicle and electric parts. - Page 9 CAUTION Do not start the engine in any case before the initial setup is performed. If the engine is started without initial setup, the engine may be damaged. Set the corresponding items by referring to page 13 in the Chapter pertaining to “Initial Setup” in the separate Instruction Manual with regard to the initial setup method.
- Page 10 ECU Arrangement Drawing Perform operations by referring to the symbols in the corresponding columns of the tables of applicable models on and after page 12. A Lower part of the passenger seat dash side B Right side of the glove box C Foot position of the passenger seat D Inner part of the glove box E Inner part of the center console...
- Page 11 How to Refer to the ECU Terminal Arrangement Drawing This ECU terminal arrangement drawing is on the assumption that the connector is viewed from the direction of the arrow. The direction of the ECU varies depending on each vehicle. Perform the installation work after confirming the connector shape and the number of pins carefully.
- Page 12 Table of Applicable Models Excluding VTEC 3 cars Manufacturing Terminal VTEC Sensor Car name Car model Engine model Remarks year position drawing type ‘99.4 ‘03.9 S2000 F20C H6-a Type R 1 H7-a ‘01.7 ‘03.8 K20A INTEGRA H4-a (including the ‘95.9 ‘01.6 ’98 H2-c specification)
- Page 13 Engine Manufacturing Terminal VTEC Sensor Car name Car model Remarks model year position drawing type B16A ‘92.3 ‘95.10 H3-a CR-X D15B ‘89.9 ‘92.2 B16A H1-a ‘96.12 ‘00.9 H4-a PRELUDE H22A Without H3-a ‘91.9 ‘96.11 With H2-a ACCORD ‘00.6 ‘02.9 H22A H6-a EURO R ‘02.12...
- Page 14 Manufacturing Terminal Vehicle Car name Car model Engine model ECU position Remarks Sensor type year drawing TORNEO ‘00.6 ‘02.9 H22A H6-a EURO R H6-a ‘00.6 ‘02.9 H5-a F20B PR-6 TORNEO H6-a ‘97.9 ‘02.9 H5-a F18B ‘99.6 ‘04.4 LAGREAT J35A H5-b ‘03.10 PR-11 K24A...
- Page 15 It is not necessary to wire for the ECU Terminal Arrangement Drawing vehicle without the VTM signal Pressure signal VTM signal Pressure signal IG power IG power Throttle signal Ground Ground VTM signal VTEC Throttle signal VTEC solenoid signal solenoid signal IG power IG power Pressure signal...
- Page 16 It is not necessary to wire for the vehicle without the VTM signal VTEC IG power solenoid signal Ground Throttle signal VTC cam signal Pressure signal signal VTEC IG power Ground solenoid signal Throttle signal VTC cam signal Pressure signal signal VTEC solenoid signal...
- Page 17 It is not necessary to wire for the vehicle without the VTM signal signal VTEC IG power Ground solenoid signal VTC cam signal Throttle signal Pressure signal VTC cam signal TDC signal IG power Ground VTEC solenoid signal Throttle signal Pressure signal...
- Page 18 Third edition 26, 2003 Jun. 10, 2004 7107-0300-03 Fourth edition Apr. 1, 2005 7107-0300-04 Fifth edition APEXERA Co.,Ltd. http://www.apexera.co.jp Head office 1-17-14 Tanashioda,Sagamihara-city Kanagawa,229-1125 JAPAN ph+81-42-778-3991 fx+81-42-778-4495 USA office http://www.apexi-usa.com A’pex Integration,Inc. 330W Taft Orange,CA.92865,USA ph : (714)685-5700 fx : (714)685-5701...
