- Page 1 User's Guide GPIO Terminal Block...
- Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec- manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
-
Page 3: Table Of Contents
Contents What Is the GPIO Terminal Block?..........5 About the Terminal Block Connections....... 6 About the Input, Output, and Power Terminal Connections ..............6 Installing the Terminal Block............7 Installing the Terminal Block............8 Using the Terminal Block ............10 About the IF5 GPIO Interface........... - Page 4 GPIO Terminal Block User’s Guide...
-
Page 5: What Is The Gpio Terminal Block
You connect the terminal block to the IF5 with a 25-pin GPIO cable (P/N 236-057-001). The block provides access to each of the four general purpose inputs and outputs on the IF5 via standard screw terminals. -
Page 6: About The Terminal Block Connections
About the Input, Output, and Power Terminal Connections The terminal block provides standard screw terminals that you use to connect industrial control wiring to the IF5 GPIO and power interfaces. The screw terminals are located inside the terminal block on the main circuit board and are arranged as shown in the next illustration. -
Page 7: Installing The Terminal Block
+12V Ground Ground +12V +12V Ground Ground +12V +12V Ground Ground +12V +12V Ground Ground +12VDC Power Ground Terminal Connections: This illustration shows the input, output, and power terminal connections on the main circuit board. GPIO Terminal Block User’s Guide... -
Page 8: Installing The Terminal Block
2 Drill four mounting holes. Use the included drilling template (P/N 931-008-001). 3 Remove the top cover from the terminal block. 4 Place the terminal block in the location and secure it to the mounting surface with four appropriate fasteners. Mounting hardware (4 places) GPIO Terminal Block User’s Guide... - Page 9 7 Install the sleeve, split ring, and bushing on the strain relief connector body (finger tighten only). 8 Install the top cover. 9 Connect the 25-pin GPIO cable (P/N 236-057-001) to the terminal block serial port and to the Control Port connector on the IF5.
-
Page 10: Using The Terminal Block
Using the Terminal Block This section explains how the terminal block connects to the IF5 GPIO interface and how you connect devices to the terminal block input, output, and power terminals. About the IF5 GPIO Interface The IF5 reader has four general purpose input and output interfaces. - Page 11 • Supply the input interface with power from the IF5. • Isolate the IF5 from the input power source. • Use an open collector solid-state drive from a remote device to control the inputs. For more information, see the next examples. GPIO Terminal Block User’s Guide...
-
Page 12: If5 Powered Input
-Input and Ground posts. If the input device is a switch closure, you can connect the other side of the switch to the +12V post as shown in the next illustration. +12V +Input External input switch IF5 Powered Input GPIO Terminal Block User’s Guide... -
Page 13: Isolated Input Interface
12VDC power from the IF5 or the IF5 reference chassis ground. The next illustration shows how this input method is wired. External input switch +Input -Input 10-48 VDC Twisted pair Isolated Input Interface GPIO Terminal Block User’s Guide... -
Page 14: Open Collector Input Interface
The illustration shows the IF5 providing power to the pull up resistor for the open collector. Remove the jumper between the -Input and Ground posts, and use it to short out the +12V and +Input posts. Input Ground Open Collector Input Interface GPIO Terminal Block User’s Guide... -
Page 15: Connecting Devices To The Output Terminals
Output Terminal Schematic: This illustration shows an output terminal. The +Output and +12V posts are shorted by a jumper. Each terminal block output terminal includes a green indicator LED that can be enabled or disabled depending on system requirements. GPIO Terminal Block User’s Guide... - Page 16 • Switching the high side, with the load powered by the IF5 • Switching the low side, with the load powered by the IF5 • Switching the high side, with the load powered externally • Driving a DC relay that controls an AC load GPIO Terminal Block User’s Guide...
-
Page 17: Switching The High Side Using If5 Power
Switching the High Side Using IF5 Power The GPIO Terminal Block is factory configured for high side switching, with power coming from the IF5. Only the single output being switched will be affected if the interface cable fails. This configuration supports many indicator lamp applications. -
Page 18: Switching The Low Side Using If5 Power
0.25A maximum +12V +Output Switching the Low Side of the Output Load Note: In this configuration the indicator LED for the output terminal is disabled and may create some confusion with maintenance activity. GPIO Terminal Block User’s Guide... -
Page 19: Switching The High Side Using External Power
Switching the High Side With External Power Note: If the IF5 ground is not connected to the external power ground, the output terminal LED will behave unpredictably, but will light up if there is a sneak path in the chassis ground. GPIO Terminal Block User’s Guide... -
Page 20: Driving A Dc Relay To Control An Ac Load
Driving a DC Relay: The external relay provides dry contacts for controlling the AC motor. Note: In many installations, the relay and AC wiring must be placed in an enclosure that meets local fire code regulations. GPIO Terminal Block User’s Guide... -
Page 21: Connecting Devices To The Power Terminal
0.5A, and the fuse is self-recovering once the excessive load is removed. The total load on the GPIO interface power must stay within the 0.5A limit. When you design a system that uses this supply, be sure to complete a power budget assessment to ensure that the supply is adequate for the system. -
Page 22: Sample System Diagram
All are connected to the power terminal on the terminal block and powered by the IF5. Outputs Inputs Output #2 +12V Position indicator detection lamp +Input sensor -Output Ground Output #1 +12V Position indicator detection +Input lamp sensor -Output Ground +12VDC Ground GPIO Terminal Block User’s Guide... -
Page 23: Where To Go From Here
You may need additional information when working with the IF5 in your data collection system. Please visit www.intermec.com to download PDF files of our current manuals. To order printed versions of Intermec manuals, contact your local Intermec representative or distributor. - Page 24 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2005 Intermec Technologies Corporation. All rights reserved. GPIO Terminal Block User’s Guide *934-001-001* P/N 934-001-001 Rev A...
