Technical Data - Echo Instruction Manual Instruction Manual

Model ............................................................................................. Cs-303t
Dimension L x W x H ..................................................................... 260 x 235 x 220 mm (10.2 x 9.3 x 8.7 inch)
Weight Power head, dry ................................................................ 3.5 kg (7.7 lb) Without chain and guide bar
Engine .................................................... type .............................. air-cooled, two-stroke, single cylinder
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
Fuel......................................................... Mixture ratio .................. 50 : 1 Power Blend X
.......................................................................................................
.......................................................................................................
................................................................
.......................................................................................................
.......................................................................................................
.......................................................................................................
......................................................
Oil .................................................................................................. Power Blend X
................................................................
................................................................
................................................................
guide bar / saw chain ................................................................... 12 in., 14 in.
standard features .......................................................................... top Handle
.......................................................................................................
.......................................................................................................
.......................................................................................................
.......................................................................................................
idle speed .................................................................................... 3,000 RPM
Clutch Engagement ....................................................................... 4,400 RPM
Wide Open throttle (WOt) ............................................................ 11,500 RPM
kickback safety Features ............................................................. Double guard Low kick guide Bar
.......................................................................................................
.......................................................................................................
.......................................................................................................
.......................................................................................................
* technical data subject to change without notice.
30
T D
eCHniCal
Displacement ................ 30.1 cc (1.83 cu.in.)
Carburetor ..................... Diaphragm type
Magneto ........................ Flywheel magneto : CDi system
spark Plug .................... ngk BPM-8Y
starter ........................... automatic rewind starter
Power transmission ...... automatic centrifugal clutch
gasoline ........................ Use 89 Octane unleaded. Do not use fuel containing
tank Capacity ............... .25 L (8.5 fl oz U.S.)
Bar and chain ................ ECHO bar and chain oil (or motor oil)
tank Capacity ............... 0.15 L (5.1 fl. oz. U.S.)
Lubrication .................... adjustable automatic oil pump
aTa
isO-L-EgD (isO/CD 13738)
tM
and J.a.s.O. M345- FD, two-stroke, air-cooled
engine oil..
methyl alcohol, more than 10% ethyl alcohol or 15%
MtBE. Do not use alternative fuels such as E-15 or
E-85.
Premium Universal 2-stroke Oil
tM
Front hand guard,
anti-vibration device,
throttle control lockout, Chain brake,
Chain catcher, Spark arrestor muffler
Low kick guard Link saw Chain
Front Hand guard/Chain Brake Lever
Chain Brake
kick guard
