GPS G53
Portable Automobile Navigation System
Product User Manual
Version: V1.0
January 2007
Support info
GLOPEX and GPS G53 are trademarks of Glopex Networks Inc.
All other trademarks belong to each registered companies.
Note
Contents of this manual will be modified without further notice.
The proper operation temperature of the product is between 0℃~40℃.
Operating or recharging in an environment with temperature over 45℃
might cause system to stop functioning. yet this should be considered as a
normal phenomenon. Please do not operate in an extreme temperature
environment.
GPS G53
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Glopex Networks GPS G53
Summary of Contents for Glopex Networks GPS G53
- Page 1 Product User Manual Version: V1.0 January 2007 Support info GLOPEX and GPS G53 are trademarks of Glopex Networks Inc. All other trademarks belong to each registered companies. Note Contents of this manual will be modified without further notice. The proper operation temperature of the product is between 0℃~40℃.
-
Page 2: Safety Precautions
When disposing of the battery, follow the instructions. The replacement battery must be original factory approved. 2. Regulations must be observed when recycling or disposing of batteries. 3. The battery should only be used in this device. GPS G53... -
Page 3: Warranty Statement
Warranty Statement • This warranty applies to parts and services of GPS G53 and sold through Glopex Networks Inc. The local area covered is Canada; the warrantee length is one year from date of purchase (counting from the date on the sales receipt). Under normal user operation, Glopex Networks Inc. -
Page 4: Technical Support
• If the answer cannot be found on our website, please send us e-mail gps@glopex.com or call 1-866-466-4237 for the questions or reseller location. Maintenance Service Glopex Networks Inc. 1- 866 –466 – 4237 Web Site: http://www.glopex.com/ E-mail: gps@glopex.com GPS G53... -
Page 5: Table Of Contents
Top View ................. 6 Getting Started ..............7 SD memory card installation ........7 Using the stylus.............8 I/O interface..............8 Charging.................9 Using Home / Travel adapter: ........... 9 Using the car charger:............. 10 Using the GPS Cradle / Suction Cup Holder ....12 GPS G53... - Page 6 Stylus Adjustment ............30 Backlight Setting ............. 31 Version................32 About ................33 Using the CD ..............34 Troubleshooting..............34 System reset ..............34 Quick Troubleshooting ..........35 Normal Care and Maintenance ........35 Keep dry ............... 35 Do not drop the unit ............ 35 GPS G53...
- Page 7 Keep away from strong magnetic fields ....36 Operating temperature ..........36 Avoid exposure to sunlight......... 36 Using the stylus ............36 Cleaning the screen............. 36 Do not disassemble ............. 36 Storage .................36 Appendix................37 Specifications ..............37 Federal regulations ............38 GPS G53...
-
Page 8: Preface
Preface We appreciate your purchase of the GPS G53. Please read all instructions thoroughly for a full understanding of the products’ features. Symbols For fast reference to the data you wish to find, this manual uses the following symbols. This icon means to take note to messages and to read for while during use. -
Page 9: Other Functions
Other Functions • Music playback: plays MP3 music files. • Image display: displays photographs or image files • Video play films • eBook display text file GPS G53... -
Page 10: First Time Use
First time use Copyright Without the written consent of Glopex Networks Inc. this manual including the product and the software may not be duplicated, transmitted, recorded or saved on storage devices; nor shall it be translated under any circumstances into any other languages. -
Page 11: Package Contents
Package Contents Your product should include the following accessories: GPS-G53 Unit GPS Cradle Suction Cup Holder Adapter Plate Car Adapter Home / Travel Adapter SD Memory Card CD-ROM Quick Guide GPS G53... -
Page 12: Basic Operation
Basic Operation Introduction Front View 3.5” TFT LCD Charging with touch indicator LED screen Charging: Full: Green Rear View Stylus Speaker System power switch I/O interface GPS G53... -
Page 13: Left Side
Left Side External Antenna port USB port Right Side Stylus SD card slot Reset button Top View Power button Menu button Note: The Menu button is only functional during GPS navigation. GPS G53... -
Page 14: Getting Started
Do not set the SD memory card as write protected, or the system will not operate properly. When operating, accidental removal of the memory card will result in showing an error message. Please reinsert the memory card and the system may need to be reset before further use. GPS G53... -
Page 15: Using The Stylus
The I/O interface has five pins, and each pin function is described as below. Function VCCIN (DC 5.4 ± 0.2 1A) Serial Data output port A (TTL Level；Voh≧2.4V， Vol≦0.4V; Ioh=Iol=2mA) Serial Data input port A(TTL Level；Vih≧0.7*VCC； Vil≦0.3*VCC) 1 2 3 4 5 Outside device (Reserve of software program definition.) GPS G53... -
Page 16: Charging
Charging Using Home / Travel adapter: Before using the device for the first time, we strongly suggest you use a fully charged battery. Insert the USB connector into the unit. Plug the adapter into a power outlet. GPS G53... -
Page 17: Using The Car Charger
While using the device in a vehicle, use the included car charger for long periods of usage. Plug in the small plug into the power jack on the rear of the GPS Cradle. Insert the other end into the cigarette lighter. GPS G53... - Page 18 This will prevent excessive battery discharge. • When charging starts, the charging indicator light will be red, please wait for the charging to complete (this might take several hours). After charging is completed the indicator light will be green. Charging indicator LED GPS G53...
-
Page 19: Using The Gps Cradle / Suction Cup Holder
This device will effectively secure the GPS G53 unit in the vehicle. Follow the procedures below to secure the bracket: 1. Follow the arrows and stable the GPS G53 unit into the GPS Cradle fitting holes to secure. 2. Gently push in the unit until the unit is tightly fixed with the cradle. -
Page 20: Gps Mounting Kit Contents
GPS Mounting Kit Contents: GPS Cradle Suction Cup Holder Adapter Plate Suction Cup Holder G53 Cradle Adapter Plate GPS G53... -
Page 21: Step Up Gps Mounting Kit In Your Car
* Place the Adapter Plate on the GPS Cradle and securely connected as the pictures shown below. Push the Plate to the right to connect Step 1. Hold the Suction Cup Holder Base firmly against your windshield, and then press forward while Suction Cup Holder in place. GPS G53... - Page 22 Step 3. The GPS Cradle set up is complete. When using the GPS Mounting Kit, do not install in a location that will block the view of the driver The GPS Mounting Kit should be resting securely on the windshield to prevent excessive shock. GPS G53...
-
Page 23: Adjusting The Suction Cup Holder
2. Unfasten the horizontal adjustment knobs and change the horizontal angle of the connecting flange so that it is facing in your preferred direction: in line with the vehicle, towards the driver, or towards the passenger. Tighten the knob to lock in place. GPS G53... -
Page 24: Operating Methods
While power is on, press the power button to turn off power. If the unit will not be used for a long time, turn the system power switch at the rear side Off. System power switch Power button GPS G53... -
Page 25: Using Functions
Loads the navigation program and navigation screen Note: If the SD card with navigator software is inserted, the system will enter GPS function automatically after startup. Music Plays MP3 music Photo Plays images Enter expansive functions (Video, eBook) and Other system setup GPS G53... -
Page 26: Function Menu Music Playback Function
All the files need to be stored under the MP3 directory, and the file format needs to be “*.mp3”. Starting music playback Insert the SD memory card with stored MP3 files into the SD memory card slot on the unit. Power on, and select the [Music] icon on the main menu. GPS G53... - Page 27 Playback Window. Use the buttons to control each playback function. Play Progress bar Stop Timer Previous Music Status Repeat mode Repeat mode indicator Next Volume display Battery indicator Time Exit GPS G53...
-
Page 28: Image Browsing Function
SD memory card slot on the unit. Power on, and select [Photo] icon on Main Menu. The Image Browsing Window. Exit Next Previous Full screen mode Zoom in / out Previous Next Exit full Zoom in / out screen mode GPS G53... -
Page 29: Other
"film". Insert the SD memory card with video files into the SD memory card slot on the unit. Power on, and at the Main Menu Screen, select the [ Other ] icon. GPS G53... - Page 30 On the sub menu, select [ Video ] icon to enter. Use the arrow key right/left to forward/backward the film. Video Title Play Video status Stop Screen Forward Volume Next Time Full Screen Exit Previous Timer / Total Video Time Battery GPS G53...
- Page 31 Full Screen Mode Double click at anywhere on the screen to exit full screen mode Press "X" to exit the film viewer. GPS G53...
-
Page 32: Ebook
1. Insert the SD memory card with ebook files into the SD memory card slot on the unit. 2. Power on, and at the Main Menu Screen, select the [ Other ] icon. 3. On the sub menu, select [ eBook ] icon to enter. GPS G53... - Page 33 4. Use the arrow key up and down to change between books. eBook Title Next Screen Page up Time Page down Exit Page Status Previous Battery 5. Press "X" to exit the ebook reader. GPS G53...
-
Page 34: Setting
Setting Time 1. After system startup, select [Other] from the main screen to go into the System Settings window. GPS G53... -
Page 35: Volume
5. Select to return to main menu screen. Volume Under the settings window, control the volume directly with the scroll bar. There are six levels of volume in total. Scroll Bar GPS G53... -
Page 36: Startup Message
Startup Message Under the settings window, check on the Warning Voice to (check / uncheck)for whether the startup message is to be broadcasted. GPS G53... -
Page 37: Stylus Adjustment
Touch the cross in the second position once. Touch the cross in the third position once. Continue the calibration by touching the cross. Setting window will return when stylus adjustment is finished. GPS G53... -
Page 38: Backlight Setting
(1 min, 3 min, 5 min, 10 min, 30 min, Always). Backlight brightness Scroll the brightness bar to control backlight brightness. There are six levels in total. Select to confirm or select to keep the original settings. Select to return to main menu screen. GPS G53... -
Page 39: Version
Version 1. Under the setting window, select Version to enter the version window. 2. The screen display will show the version information. 3. Select to exit the Version screen. GPS G53... -
Page 40: About
About 1. Under the Other window, select About to enter the about page. 2. The screen display will show instructions for all function. 3. Select to exit the Version screen. GPS G53... -
Page 41: Using The Cd
No response with selection on the screen. • Switch the system power to be off and switch it back on. System Power switch • The system will immediately reset. • You will now see the main screen and the system is ready for use. GPS G53... -
Page 42: Quick Troubleshooting
If violently impacted or shocked, serious damage may be caused. Avoid sudden temperature changes Condensation may occur when entering a warm room on a cold day. To prevent condensation from damaging the unit, please place into an airtight plastic bag before sudden temperature changes. GPS G53... -
Page 43: Keep Away From Strong Magnetic Fields
For storage, keeping the unit in a dry box is recommended. Please do not keep the product in the following environments: Unventilated and humid locations. In a car window that is exposed to excessive amounts of sunlight. In an environment where humidity is over 90%. GPS G53... -
Page 44: Appendix
320 x 240 resolution Red/Green LED for battery charging status Built-in speaker. Audio Software volume control. Operation Temperature 0°C ~ 40°C Storage Temperature -10°C ~ 60°C Mini-USB Connector USB client; DC power in Optional Function Bluetooth / Waterproof / TMC GPS G53... -
Page 45: Federal Regulations
Federal regulations This equipment is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC. GPS G53...
