Doro DECT 4055 User Manual

Doro DECT 4055 User Manual

Caller display compatible digital cordless phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DECT 4055
Caller display compatible
digital cordless phone
This equipment is not designed for making emergency telephone calls when the power fails.
Alternative arrangements should be made for access to the emergency services.
User guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DECT 4055 and is the answer not in the manual?

Questions and answers

Related Manuals for Doro DECT 4055

Summary of Contents for Doro DECT 4055

  • Page 1 DECT 4055 Caller display compatible digital cordless phone This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to the emergency services. User guide...

  • Page 2: Table Of Contents

    DORO DECT 4055 CONTENTS Location of Controls ... 2 Handsets menu ....16 Handset ....2 Handset ringer volume level 16 Base unit .

  • Page 3: Location Of Controls

    LOCATION OF CONTROLS DECT 4055 HANDSET 1 Headset socket (on the side) 10 Charging contacts 2 Earpiece 11 Microphone 3 Display 12 On/Off-button 4 Talk button 13 Mute/Cancel button 5 Scroll button UP 14 Programming button 6 Keypad button 0-9, *, #...

  • Page 4: Base Unit

    BASE UNIT 18 Power supply socket 21 In use indicator 19 Line cord socket 22 Charge indicator 20 Charging contacts 23 Paging button UNPACKING In the box you should find the following items: Handset Power supply Base unit Line cord 2 NiMh batteries (re-chargeable types) User guide Belt clip...

  • Page 5: Installation

    INSTALLATION DECT 4055 LOCATING THE BASE UNIT It is essential to the overall range and performance that the base unit and handset can receive and transmit good radio signals. Place the base unit close to: n a telephone network socket n a 13 Amp mains socket The best location is in an upstairs room and central to the area to be covered.

  • Page 6: Handset Battery Care

    From new, the batteries (supplied) must be charged for 8 hours without interruption. You can obtain your replacement batteries from: Consumer support department, Doro Audioline Ltd, 22 Walkers Road, North Moons Moat, Redditch, Worcestershire, B98 9HE. Price available on request:...

  • Page 7: On/Off Button

    ON/OFF BUTTON The On/Off button is used to switch the handset on or off. When the handset is switched off, battery power is conserved and calls cannot be made or received. To switch off, press & hold the button until the handset beeps, then release. To switch on, press &...

  • Page 8: Handset Display

    HANDSET DISPLAY Numeric/alpha display Battery status Barred Range Mute Programming New number External call Internal call Indicator Function Battery status - indicates the battery power status. Range - is on when the handset is switched on and within range. - flashes when the handset is out-of-range of the base unit. Programming - is on when programming.

  • Page 9: Use

    DECT 4055 USING THE PHONE STANDBY MODE When the handset is not in-use (standby mode) the LCD display will show the handset identity number and the battery status. ANSWERING INCOMING CALLS When an external call is received, the base unit will ring first and the in-use LED will flash.

  • Page 10: Call Timer

    CALL TIMER The length of outgoing and incoming calls will be shown on the display approximately 10 seconds after a call is connected. LAST NUMBER REDIAL The last four numbers dialled are stored automatically in the memory. One or all of the numbers can be re-dialled as required.

  • Page 11: Earpiece Volume Control

    EARPIECE VOLUME CONTROL When on a call, the volume level in the earpiece can be increased or decreased on three levels using the buttons. MEMORY NUMBERS Ten of your most frequently used telephone numbers can be stored in the direct memory, using the kaypad digits 0-9 as the storage locations.

  • Page 12: Caller Display

    DECT 4055 CALLER DISPLAY Caller display allows you to see who is calling before you answer a call and to see who has called in your absence. When the service is implemented on your telephone line, seconds before your telephone rings the number of the incoming caller will appear on the display.

  • Page 13: Viewing Caller Display Numbers

    VIEWING CALLER DISPLAY NUMBERS The in-use indicator on the base unit will flash and the symbol will appear on the handset display when a new call(s) is received. Once the number(s) has been reviewed the indicator will stop flashing and symbol will not be visible on the display. When an incoming number is received it is assigned a call sequence number which appears on the left hand side of the display, commencing with 01 ( oldest call) up to 39 (latest call).
  • Page 14 The display will also provide the following information: The list has been reviewed to the oldest number. The list has been reviewed to the latest number. Call information is not available. It could be an international call. The caller has withheld their number or the number cannot be transmitted.

  • Page 15: Deleting A Number From The List

    DELETING A NUMBER FROM THE LIST Ensure the number you want to erase is on the display. ErASE Press the .button twice. The display will show " " and the phone number will be erased. DELETING ALL NUMBERS FROM THE LIST Ensure a call list number is on the display ErASE ALL Press and hold the...

  • Page 16: Menu Settings

    DECT 4055 MENU SETTINGS The DECT 4055 has a simple menu system which is controlled by five buttons: buttons are used to scroll through the menus. button is used to enter the menu system and confirm a setting. button can be used to revert back to standby mode without saving.

  • Page 17: Handsets Menu

    HANDSET MENU DECT 4055 To enter the handsets menu, press and then either HANDSET RINGER VOLUME LEVEL (BELL LOUD) You can change the ringer volume level in four levels: off, low, normal and high. Press followed by bELL Lou d Scroll to "...

  • Page 18: Display Information

    DISPLAY INFORMATION (BS/HS-DISP) When the unit is in standby mode it can display the handset (hS-diSP) and base (bS- diSP) identity numbers. This information can be switched on or off. Base unit Handset number number Press followed by bS dISP hS dISP Scroll until the display shows "...

  • Page 19: Auto Answer

    AUTO ANSWER (AUTO ACCEPT) If the handset is on the base unit, this feature allows the handset to connect with a call automatically when lifted off the base unit, without the need to press the Talk button. Press followed by Au to AccEPt Scroll until the display shows "...

  • Page 20: Select Base Unit

    ACTIVATE/DEACTIVATE BABY CALL Press followed by dirEct SEt Scroll until the display shows " ". Press Enter the handsets PIN-code (0000 from new). The display shows the current setting ( Scroll to desired setting with Press to store the setting. SELECT A BASE UNIT (SELECT BS) If the handset is registered to more than one base unit, you can select one base unit as a special base unit irrespective of how many base units are registered.

  • Page 21: Handset Pin Code

    HANDSET PIN-CODE(HS-PIN) A four digit PIN code is provided to ensure that some of programmable setting can not changed by unauthorised users. From new the code is set to 0000. Press followed by HS-Pin Scroll until the display shows " ".

  • Page 22: Reset

    RESET THE HANDSET The handset can be reset to the factory settings or the redial memory can be erased, if required. RESET THE LAST NUMBER REDIAL (ERASE REDIAL) Press followed by EraSE rEdiAL Scroll until the display shows " ". Press Enter the handsets PIN-code (0000 from new).

  • Page 23: Base Units Setting

    BASE UNIT MENU DECT 4055 To enter the base units settings, proceed as followed: Press followed by Scroll to the desired setting with the scroll buttons and follow the instructions for respective setting. For some of the settings you must enter a PIN-code (0000 from new) BASE UNIT RINGER VOLUME (BELL LOUD) There are four setting available (off, low, normal and high) for the base unit ringer.

  • Page 24: Priority Ringing

    PRIORITY RINGING (PRIORITY HS) If an additional handset(s) is added to one base unit, can you select the ring priority of incoming calls. From new, all handsets will ring. Press followed by PrioritY hS Scroll until the display shows " ".

  • Page 25: Pabx Usage

    PABX USAGE If you are connected to a PABX, the DORO DECT 4055 can be programmed to accept an access code and to insert a timed pause before the number is dialled. Up to 3 different primary access codes (4 digits each maximum) can be stored. If you are connected to two PABXs and it takes one more access code and two pauses to obtain an external line, a secondary access code can be also programmed.

  • Page 26: Emergency Number

    EMERGENCY NUMBER (SOS SET) Three emergency numbers can be programmed. This function is for making a call even if the call barring function is implemented. 999 and 112 are programmed from new. Press followed by SoS SEt Scroll until the display shows " ".
  • Page 27 Press followed by cALL bLoc Scroll until the display shows " ". Press Enter the base units PIN-code (0000 from new). Enter the identity number of the appropriate handset. The display shows the current setting. Scroll to desired setting with the scroll buttons. Press to store the setting.

  • Page 28: Least Cost Routing

    The DECT 4055 can be programmed to recognise a certain dialling code or type of call and automatically dial an access code.

  • Page 29: Pin Code

    BASE UNIT PIN-CODE (BS-PIN) From new the base unit PIN-code is 0000. It is recommended that this is changed to a number of your choice. followed by #. Press bS-Pin Scroll until the display shows " ". Press Enter the base units PIN-code (0000 form new). Enter the new PIN-code twice.

  • Page 30: Extending

    DECT 4055 EXTENDING The DECT 4055 can form the basis of a multi-handset DECT telephone system which will allow you to: Register up to 6 handset to the same base unit.. Register up to 4 handset to same handset. Make an internal call and transfer calls from one handset to another handset which connected to same base unit.

  • Page 31: Additional Handsets

    ADDITIONAL HANDSETS Adding additional handset to the system allows all users to make full use of the call transfer and intercom facilities. A maximum of one external call and one internal call can proceed at the same time. If an additional handset is added to the system, the batteries must be charged for 8 hours without interruption.

  • Page 32: Internal Call

    INTERCOM CALL When two or more handsets are registered to the same base unit it is possible to call handset to handset. This call is not charged for by your Network operator. TO MAKE A INTERCOM CALL Press the button. Enter the handset number of the handset you wish to call Press the button on the called handset to take the call.

  • Page 33: Miscellaneous

    Electronic equipment like TV's, computers, etc. emit strong electronic magnetic fields which can affect the radio signals. Try not to locate your DECT 4055 next to this type of equipment and ensure that the power line cords are separated from other electrical units.
  • Page 34 Please note that this is a Premium Line number and all calls are charged at 50 pence per minute. Price correct at the time of going to press. Alternatively, you can write to: Technical Support Group, Doro-Audioline Ltd., 22 Walkers Road, North Moons Moat, Redditch, Worcestershire, B98 9HE.

  • Page 35: Approved Use

    Compatible countries: UK, Sweden, Switzerland, Norway, Denmark, Finland. The REN number of the DECT 4055 is 1.The REN number (Ringer Equivalence Number) determines how many telephones can be connected to your telephone line. Most normal exchange lines have a REN capacity of 4. If you exceed the REN value one telephone may not ring.

  • Page 36: Technical Data

    TECHNICAL DATA Standby About 110 hours Talk time About 13 hours Range >300 metres in ideal conditions. Indirect memory 10 numbers Caller display memory 39 numbers Battery 2 x 1.2V AA NiMH type Weight Handset: 170 gm Base unit: 200 gm Size (B x H x D) Handset: 45 x 155 x 26 mm Base unit: 107 x 148 x 51 mm...
