Electrolux EFC 9460 User Manual

Electrolux cooker hood
Hide thumbs

Advertisement

Quick Links

Gebrauchsanweisung , Notice d'utilisation et d'installation
EFC 9460
Installatie- en gebruiksaanwijzing , User manual
D
F
NL
UK

Advertisement

loading

  Also See for Electrolux EFC 9460

  Related Manuals for Electrolux EFC 9460

  Summary of Contents for Electrolux EFC 9460

  • Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation EFC 9460 Installatie- en gebruiksaanwijzing , User manual...
  • Page 2: Table Of Contents

    Contents Safety warnings for the installer for the user Description of the appliance Extractor version Filter Version Control Panel Correct ventilation If the hood does not function Before you make contact to service Service and spare parts Maintenance and care Cleaning Metal grease filter Open the metal grease filter...
  • Page 3: Safety Warnings

    Safety warnings for the installer mance of the extractor hood. • If the hood is used in its filtering function, it will • When used as an extractor unit, the hood must operate simply and safely in the above be fitted with a 150mm diameter hose. conditions without the need for any of the Should there already be a pipe of diameter 125 aforementioned measures.
  • Page 4: Description Of The Appliance

    • The air is filtered through a charcoal filter and returned to the kitchen through the top grill of the outlet pipe. • You will need an original ELECTROLUX KF20 charcoal filter for the filtering function. (See Special Accessories). • Fix the deflector using 4screws Ø2,9x6,5mm .
  • Page 5: Control Panel

    Control Panel • The hood is fitted with one motor having several speed. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. The hood should be left ON/OFF on after cooking for about 15 minutes or until all Extractor fan the odours have disappeared.
  • Page 6: Maintenance And Care

    Maintenance and care The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning Warning • Warning: always disconnect the hood from the • Failure to observe the instructions on cleaning mains power supply before cleaning it. the unit and changing the filters will cause a fire Never insert pointed objects in the motor’s hazard.
  • Page 7: Charcoal Filter

    • The charcoal filter should only be used if you want to use the hood in its filtering function. • To do this you will need an original ELECTROLUX charcoal filter (see special accessories). • Cleaning/replacing the carbon filter Unlike other carbon filters, the LONGLIFE charcoal filter can be cleaned and reactivated.
  • Page 8: Technical Specifications

    Technical Specifications Dimensions Height 74,5-116 Width 89,8 Depth Lighting 2 x 20 W Grease filter power absorption 200 W We reserve the right to generate constructive and chromatic modifications as required by technological growth. Special accessories Carbon filter KF 20 942 120 600 Installation Unpacking...
  • Page 9: Mounting Accessories Included

    Installation Mounting accessories included 1 deflector 1 chimney support 1 reduction flange Ø 125-120 mm 1 support bracket 5 wood-screws 5 x 45 mm 5 wall plugs Ø 8 mm 6 metal screws 2,9 x 6,5 6 metal screws 3 x 9 Wall unit mounting - Fig.
  • Page 10 LI1X8C Ed.09/02...
