Summary of Contents for Avizia MX200
- Page 1 Extended Height Cart | User & Installation Guide Extended Height Cart for Cisco MX200/MX300 USER AND INSTALLATION GUIDE © 2013 Avizia Inc. All rights reserved. | aviziatech.com | AVZ-MXC-DOC-UIG-04...
-
Page 2: Table Of Contents
Tools and Parts for Installation ..........5 tion and other resources. Assembly and Installation ............6 Cart Assembly ................6 Cable Installation..............7 Display Installation | MX200 ............8 Display Installation | MX300 ............9 Cable Plugin ................11 Storage Shelf Installation ............12 Cable Cover Installation ............13 Adjusting Cart Height ..............14... -
Page 3: Important Safety Instructions
Extended Height Cart | User & Installation Guide Important Safety Instructions SAFETY PRECAUTIONS, CAUTIONS, AND WARNINGS Safety Precautions Cautions Warnings Failure to read, thoroughly understand, and follow all This caution symbol means be aware and pay This warning symbol means danger. You are in instructions can result in serious personal injury, damage to attention as you work on any equipment. -
Page 4: Cart Overview
Extended Height Cart | User & Installation Guide Cart Overview CART OVERVIEW AND DIMENSIONS The Avizia Extended Height Cart for the Cisco MX200/MX300 is designed to transform the way people learn and the way instructors present material in a collaborative, geographically distributed environment. -
Page 5: Tools And Parts For Installation
Extended Height Cart | User & Installation Guide Tools and Parts for Installation Phillips Screwdriver (not included) Tighten Fastener Loosen Fastener Adjust Hex Head Wrench By Hand Phillips Screwdriver © 2013 Avizia Inc. All rights reserved. | aviziatech.com | AVZ-MXC-DOC-UIG-04... -
Page 6: Assembly And Installation
Extended Height Cart | User & Installation Guide Assembly and Installation Cart Assembly CAUTION: Attachment holes may be damaged if a power drill is used to insert button head cap screws. Screws should Cart Handle first be inserted and turned BY HAND with the hex key or with a handheld screwdriver BEFORE using a hex head drill bit and power drill (optional) to complete the attachment. -
Page 7: Cable Installation
Extended Height Cart | User & Installation Guide Assembly and Installation Cable Installation Power and Starting from the back of the column, the display power Ethernet cord and network cable can be run through the cutout cables towards the top of the post and down through the front of the post. -
Page 8: Display Installation | Mx200
Extended Height Cart | User & Installation Guide Assembly and Installation Display Installation | MX200 This cart has been designed specifically for the Cisco Telepresence MX200 or MX300 flat panel displays. It is not recommended that any other display be used to mount on this cart. -
Page 9: Display Installation | Mx300
CAUTION: Before attaching display to cart, set the brakes on the back wheels by pressing down on the tabs to prevent instability that could result in possible injury. Remove MX200 BACK COVER BRACKET from the column assembly (D) by removing two screws and washers. MX300 back cover bracket Reuse screws and washers from Step 1 to secure the MX300 BACK COVER BRACKET (P) to column assembly. - Page 10 Extended Height Cart | User & Installation Guide Assembly and Installation Display Installation | MX300 Carefully slide display onto column assembly (D). MX300 DISPLAY WARNING: Two people are required to lift the chassis. To prevent injury, keep your back straight and lift with your legs, not your back.
-
Page 11: Cable Plugin
Extended Height Cart | User & Installation Guide Assembly and Installation Cable Plugin Plug all of the cables routed through the post in previous steps into their respective plugs on the back of the MX unit including: power, ethernet, DVI content sharing with associated audio, touchpanel, and microphone(s). -
Page 12: Storage Shelf Installation
Extended Height Cart | User & Installation Guide Assembly and Installation Storage Shelf Installation Use four 1/4-20 x 3/4” button head cap screws (H) to secure pole attachment plate (G) to storage shelf (F). NOTE: Pull the slack between the column and the shelf out of the cables running through the storage shelf as the shelf is moved towards the column. -
Page 13: Cable Cover Installation
NOTE: MX200 aluminum cable cover used to complete cart installation is included with the Cisco TelePresence MX200 42 Table Stand Option, Cisco part number CTS-MX200-42-TSK, which should be ordered with the MX200 per the datasheet instructions. Appearance of MX200 aluminum cable cover may vary from the illustration. -
Page 14: Adjusting Cart Height
Extended Height Cart | User & Installation Guide Adjusting Cart Height NOTE: The column assembly contains a gas spring which allows for safe and easy height adjustment after the display has been mounted. Adjusting the height when the display is not attached is much more difficult and not recommended. -
Page 15: Cart Use And Maintenance
Extended Height Cart | User & Installation Guide Cart Use and Maintenance CAUTION: This cart is intended for use only with the products and maximum weights indicated. Use with other products or products heavier than the maximum weights indicated may result in instability causing possible injury. CAUTION: Cart can tip over resulting in risk of injury and damage to the system. - Page 16 Extended Height Cart | User & Installation Guide MX Series Guides and Regulatory Compliance and Safety Information Guide: http://www.cisco.com/en/US/partner/products/ps11776/prod_installation_guides_list.html THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED.
