CoolMax USA
CoolMax CN-390
NAS User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CN-390 and is the answer not in the manual?

Questions and answers

Summary of Contents for Coolmax CN-390

  • Page 1 CoolMax USA CoolMax CN-390 NAS User Guide...
  • Page 2 CoolMax USA Instructions for First Time users: 1. Place the new hard drive into the NAS unit 2. Hard drives, a. For new hard drives, use USB connection and partition the drive to 1 primary partition; DO NOT FORMAT b. For old hard drives, you will need to erase your drive; delete partition and partition the drive to 1 primary partition;...
  • Page 3 CoolMax USA 1.Install storage Note: new hard drives requires 1 primary partition and DO NOT FORMAT; Format only thru the NAS web interface. 1.1 Search Storage 1.1.1 Search Disk Please download Scantool vis this link: http://coolmaxusa.com/NASTOOLS.ASP A. Execute "ScanTool" Utility Click scan to get IP address 2.

  • Page 4: Web Control Page

    CoolMax USA Default user name and password User: admin Password: admin 2.WEB Control Page 2.1 Status Display storage current status...

  • Page 5: System Information

    CoolMax USA 2.1.1 System Information 2.1.1.1 Host Name / Group Name Click status -> host and group name field -> “Change” button to get into Identification page Host Name: default value is STORAGE-XXXX. The last 4 digital xxxx depend on storage MAC address 。...

  • Page 6: Network Information

    CoolMax USA 2.1.1.3 Date/Time Double click status -> Date/Time field -> “Change” button to get into Date and Time page Date: set manual Date (yyyy/mm/dd) Time: set manual Time (hh:mm:ss) SNTP: enable/disable SNTP client Time server: locate time server Time Zone: click your current time zone in the list, and then click OK.

  • Page 7: Service Information

    CoolMax USA 2.1.3 Service Information SAMBA Service :Disable / Enable SAMBA server FTP Service :Disable / Enable FTP server 2.1.4 Disk Information Display Hard Disk model / Free Size / Total Size information 2.2 IP config 2.2.1 Auto IP Upon boot-up the device must check for DHCP servers on the network...

  • Page 8: Maintenance

    CoolMax USA Subnet Mask: an address code that determines the size of the network; this is the subnet mask of the storage, when seen by external users on the Internet (including your ISP). The subnet mask is provided by your ISP.
  • Page 9 CoolMax USA Windows client or server as if it is a Windows file and print server. Share one or more directory trees Share one or more Distributed filesystem (Dfs) trees Assist clients with network browsing Provide or assist with Windows Internet Name Service (WINS)
  • Page 10 CoolMax USA this page can modify as bellow password: password of SMB account access control : read only / read and write access control of SMB account folder sharing: Folder List is all of exist folder on storage , Sharing List is share folder of SMB account .
  • Page 11 CoolMax USA no Settings item in the Start menu in XP). By default, XP will display the Control Panel in Category View mode. If you see this, click the Switch to Classic View item in the upper-left corner of the window. All of our directions are for using the Control Panel in Classic View mode.
  • Page 12 CoolMax USA Internet Protocol (TCP/IP) • If you do not see either Client for Microsoft Networks or Internet Protocol (TCP/IP) in your list, you will need to add them. For either, the method is to click the Install... button, click the type of component (Client or Protocol), and then click the Add...
  • Page 13 CoolMax USA Computer and Workgroup Names From the Control Panel, double-click the System icon to open the System Properties dialog box. Click the Computer Name tab, and your System Properties dialog box will look similar to: To give your system computer a name and a workgroup, click the Change...
  • Page 14 CoolMax USA the one you specified in the web page of your Samba server. Don't worry that Windows forces the workgroup to be all capital letters; it's smart enough to figure out what you mean when it connects to the network.
  • Page 15 CoolMax USA of "Toltec". If it works, congratulations! Try copying files to and from the server by dragging their icons to and from the Samba server's test folder. You might be pleasantly surprised how seamlessly everything works. 2.5 FTP server File Transfer Protocol (FTP) is a network protocol used to transfer data from one computer to another through a network, such as over the Internet.
  • Page 16 CoolMax USA 2.5.1 Configure FTP server Connect to storage SMB page ,the page as bellow: FTP port: configure port number, port range is 1025 to 65500 and default port is 21 . If you behind firewall ,remember to open port number...
  • Page 17 CoolMax USA Latin I (CP1252) Albanian, Danish, Dutch, Faroese, Finnish, French, German, Icelandic, Irish, Italian, Norwegian, Portuguese, Spanish and Swedish. Baltic (CP1257) Estonian, Latvian, Lithuanian. NEW: create FTP share account and password ,default account is "guest" Modify: this page can modify as bellow...
  • Page 18 CoolMax USA Delete: delete FTP account Note: FTP is an added feature. FTP configurations may vary depending on your ISP, Router and Operating System settings. 2.5.2 Using FTP Within Microsoft Internet Explorer 7 1.Open Internet Explorer 7 2.In the address bar, type the following command: ftp:// IP address ex: ftp://10.130.xxx.xxx...
  • Page 19 BitTorrent is a peer-to-peer file sharing (P2P) communications protocol. 2.6.3 Using Bit Torrent client Note: CoolMax doesn’t support illegal downloading. CoolMax will not support illegal torrent downloading concerns. Please use Bit Torrent legally and responsibly. login BT forum and download torrent file to PC 2 Double click BitTorrent page 3.Browse and select torrent file to upload Download Queue...
  • Page 20 CoolMax USA 5.When torrent download percentage show 100% ,the data will store in download path 6.You can access file from SMB client or FTP client on the PC 7. Information and configuration : System ID: torrent ID Number of the Downloads: number of torrent active...

  • Page 21: Mail Notification

    CoolMax USA 9. Button of torrent queue Path: open file manager by Samba (Network Neighborhood) FTP: open file by default FTP client of PC (default path is public) Restart: you can select a torrent to restart from download queue Pause: pause you can select a torrent to pause from download queue...
  • Page 22 CoolMax USA 3. Click Start and select Printers and Faxes. 4. Under Printer Tasks, click Add a Printer. Click Next.
  • Page 23 CoolMax USA 5. Select the Local Printer attached to this computer radio button. 6. Uncheck the automatically detect and install my Plug and Play printer check box. 7. Click Next. 8. Select the Create New Port radio button. 9. From the Type of port: drop down list choose Standard TCP/IP Port.
  • Page 24 CoolMax USA Select configuration...
  • Page 25 CoolMax USA 12. setup protocol LPR and queue name Note: If you receive an error message saying that the "LPD server did not respond as expected ...", click Cancel. Attempt to reenter the IP Address or Print Queue name. Click OK again. If this process fails, the device may not support LPR printing.

  • Page 26: Media Server

    CoolMax USA Note: At this point, you should have the device listed in the Printers and Faxes folder. You can attempt to use it as a printer. 2.9 Media Server 1.Select Media Server sharing folder 2.Double click set button 3.Make sure media server (storage) is same subnet with media player (X box 360 PS3 and iTunes) 4.Browse content from iTunes (music only) , Xbox 360 and PS3...
  • Page 27 CoolMax USA 1. Connect your console to your storage as described above. 2. Click Media Server page of storage, and set up sharing list (photo, music, and video) 3. When setup is complete, Media Server of storage should automatically start.
  • Page 28 CoolMax USA Share Media from Storage(Media server) with PS3(Media player) On your Storage: Click Media Server page of storage, and set up sharing list (photo, music, and video) On your PS3: 1. Go into the PS3's Settings menu and navigate to Network Settings - Media Server Connection, and select Enabled.
  • Page 29 CoolMax USA 2. When you turn on the PS3™ system, Media Servers on the same network are automatically detected and icons for the detected servers are displayed under (Photo), (Music), and (Video). 3. Select the icon of the DLNA Media Server that you want to connect to under...
  • Page 30 CoolMax USA Hints for PS3 The PS3™ system must be connected to a network. For details on • network settings, see (Settings) > (Network Settings) > [Internet Connection Settings] in this guide. When the method of allocating IP addresses has been changed from •...
  • Page 31 CoolMax USA Share Media from Storage(Media server) with iTuner(Media player) 1. You need to connect an Ethernet cable from the Ethernet port on the back of your iTunes to your storage 2. Make sure storage media server enable (music) 3.select storage on shared class...
