INSTALLATION AND OPERATING
The Golden Blount vent-free gas
log sets comply with the National
Safety Standards and are tested
and design certified by CSA to
ANSI Z21.11.2-2000, unvented
heaters Z21.60a-2000 decorative
gas appliances for installation only
in a woodburning, masonry or UL
listed manufactured fireplace or in a
Golden Blount or any other CSA
approved vent-free fireplace. This
product may be burned with the
fireplace damper in either a closed
or open position.
MANUFACTURED BY:
4301 WESTGROVE DRIVE
ADDISON, TX. 75001
INSTRUCTIONS
FOR VENT-FREE
OR VENTED INSTALLATIONS
GOLDEN BLOUNT "TEXAS FLAME II" GAS LOGS
NATURAL GAS OR L.P.
18" - 24" & 30" SIZE SETS
INC.
Warning:
If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life
• Do not store or use gasoline or other
flammable vapors or liquids in the
vicinity of this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch;
do not use any phone in your
building.
- Immediately call your gas supplier
from a neighbor's phone.
- If you cannot reach your gas
supplier, call a fire department.
- Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Warning:
Logs must be arranged so that the
flames only touch bottom back log or front
ember log. Flames must not touch any other
log in set or any part of firebox.
This is an unvented gas-fired heater. It
uses air (oxygen) from the room in which
it is installed. Provisions for adequate
combustion and ventilation air must be
provided.
®
Advertisement
Table of Contents
Summary of Contents for Golden Blount 18" - 24" & 30"
- Page 1 INSTALLATION AND OPERATING GOLDEN BLOUNT “TEXAS FLAME II” GAS LOGS The Golden Blount vent-free gas log sets comply with the National Safety Standards and are tested and design certified by CSA to ANSI Z21.11.2-2000, unvented heaters Z21.60a-2000 decorative gas appliances for installation only in a woodburning, masonry or UL listed manufactured fireplace or in a Golden Blount or any other CSA...
-
Page 2: Safety And General Information
IMPORTANT! Read all instructions carefully before starting installation. Failure to follow these instructions may result in property damage, personal injury or possible loss of life SAFETY AND GENERAL INFORMATION • Use correct gas type for your appliance. Do not convert from one gas type to another. •... - Page 3 NOTE! CARBON MONOXIDE POISONING MAY LEAD TO DEATH. Early signs of carbon monoxide poisoning resemble the flu, with headache, dizziness and/or nausea. If you have these signs, the heater may not be working properly. Get fresh air at once! Have heater serviced. Some people - pregnant women, persons with heart or lung disease, anemia, those under the influence of alcohol, those at high altitude - are more affected by carbon monoxide than others.
- Page 4 Before starting installation, find out if local and state codes approve vent-free gas logs. If unvented gas logs are not approved, the installation must be made with the fireplace damper partially open and locked to assure the minimum vent area required by local codes or the National Gas Fuel Code (ANSI Z223.1-latest edition). Use the damper clamp provided.
- Page 5 PLACEMENT OF LOGS - 18” SETS Front ember log sits under front ember burner tube as shown. Bottom back log is to be placed on back of grate and against burner support brackets as illustrated. Notches in bottom log will go over grate bar.
- Page 6 PLACEMENT OF LOGS - 24” & 30” SETS Front ember log sits under front ember burner tube as shown. Bottom back log is to be placed on back of grate and against burner support brackets as illustrated. Notches in bottom log will go over grate bar.
-
Page 7: For Your Safety Read Before Lighting
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a push-button piezo ignition device which automatically lights the pilot. If the piezo fails to ignite the pilot, then follow the lighting instructions for lighting the pilot with a match. - Page 8 LIGHTING INSTRUCTIONS “MILLIVOLT VALVE” 1. STOP! Read the safety information previously listed above. 2. Make sure manual shutoff valve is fully open. 3. Set rocker switch to OFF position. 4. Press in and turn control knob clockwise 5. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! follow “B”...
- Page 9 TO TURN OFF GAS TO APPLIANCE “MILLIVOLT VALVE” CONT. SHUTTING OFF HEATER 1. Turn control knob clockwise 2. Set rocker switch to OFF position Shutting off burners only (pilot stays lit) You may shut off burner and keep the pilot lit by doing one of the following. 1.
-
Page 10: Parts List
ITEM QUANTITY PARTS LIST DESCRIPTION TF-II-18 TOP LEFT LOG TF-II-18 TOP RIGHT LOG TF-II-18 BOTTOM BACK LOG TF-II-18 BOTTOM FRONT LOG TF-II-18 FRONT EMBER LOG TF-II-24/30 MIDDLE LEFT LOG TF-II-24/30 MIDDLE RIGHT LOG TF-II-24/30 LEFT FRONT LOG TF-II-24/30 RIGHT FRONT LOG TF-II-24/30 BOTTOM BACK LOG (SPECIFY SIZE) TF-II-24/30 BOTTOM FRONT LOG (SPECIFY SIZE) TF-II-24/30 FRONT EMBER LOG... -
Page 11: Troubleshooting Reference
TROUBLESHOOTING REFERENCE With Proper installation and maintenance, your new Gas Appliance should provide years of trouble free service. If you do experience a problem, this guide will assist a CERTIFIED SERVICE PERSON in the diagnosis of problems and the corrective action to be taken. SYMPTOM 1.
