Page 1: Important Safety Instructions
® IntelliBrite Outdoor Landscape LED Color-Changing Light User’s and Installation Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS IntelliBrite Landscape Light Installation and User’s Guide... - Page 2 Pentair Water Pool and Spa, Inc. Those names and brands may be the trademarks or registered trademarks of those parties or others. P/N 690034 Rev C - 9/9/2010...
-
Page 3: Table Of Contents
IMPORTANT SAFETY WARNINGS AND PRECAUTIONS Notice: 1. FOR USE WITH LANDSCAPE LIGHTING SYSTEMS ONLY. 2. THE DEVICE (INTELLIBRITE® LANDSCAPE LIGHTS) IS ACCEPTED AS A COMPONENT OF A LANDSCAPE LIGHTING SYSTEM WHERE THE SUITABILITY OF THE COMBINATION SHALL BE DETERMINED BY CSA OR LOCAL INSPECTION AUTHORITIES HAVING JURISDICTION. -
Page 4: Intellibrite Landscape Lights Overview
AC power to a standard landscape light magnetic transformer. By turning the transformer switch off and on a specific number of times, the light activates one of the seven light show modes or five fixed colors. IntelliBrite landscape lights can also be controlled using the wall mounted IntelliBrite ®... -
Page 5: Operating The "Intellibrite" Color Light Shows
Switch power on to the transformer. The previously selected color or color show will start. To select one of the IntelliBrite color light shows (1-7) or fixed colors (8-12), turn the transformer 120 Volt AC power switch OFF and ON a specific number of times. -
Page 6: Operating The "Landscape" Color Light Shows
Switch power on to the transformer. The previously selected color or color show will start. To select one of the IntelliBrite color light shows (1-7) or fixed colors (8-12), turn the transformer 120 Volt AC power switch OFF and ON a specific number of times. -
Page 7: Connecting The Light Wires To The Transformer
CONNECTING THE LIGHT WIRES TO THE TRANSFORMER IntelliBrite landscape LED lights are powered by a standard 12 VAC to 12 VAC landscape transformer (purchased separately). Select the correct transformer rating (Wattage) which is able to power the number of IntelliBrite landscape LED lights installed. -
Page 8: Intellibrite Landscape Lights Transformer Wiring For Automation Systems
• When using IntelliBrite landscape LED lights with an IntelliTouch or EasyTouch pool and spa control system, the transformer must always be set to 'ON'. Also, select the light circuit as an “IntelliBrite” light from the automation control panel, •... -
Page 9: Recommended Minimum Wire Gauge (11.5 Vac And 14.5 Vac)
(for use with 14.5 VAC transformer output) Note: (**) Use the “Transformer (VA)” rating (bottom row) to determine transformer rating. Note: (**) A transformer rating of 20 Volt-amps per light will cover losses in the wiring. IntelliBrite Landscape Light Installation and User’s Guide... -
Page 10: Intellibrite Controller (Accessory)
• Six (6) IntelliBrite LED landscape lights (each light 20 Watt maximum) Wiring the IntelliBrite Controller to a 12 VAC Transformer The following diagram shows how to connect the IntelliBrite LED lights to a 120 VAC wall outlet using a 12 VAC transformer (plastic transformer, 2-wire (no ground wire) or metal transformer, 3-wire (with ground wire)). -
Page 11: Installing Intellibrite Landscape Lights
MINIMUM WIRE GAUGE” table on page 7. Light Placement and Orientation Position the IntelliBrite landscape LED light in the desired location. The light can be mounted in any orientation (pointing upward or downward). The ½" mounting pipe can be attached to other mounts instead of the supplied ground stake. -
Page 12: Splice Light Wires
(maximum of 6 inches) for protection against the elements. The cables can also be covered with chips, dirt, or placed on the ground against a wall. SHORT LIGHT WIRES FROM LANDSCAPE LIGHT WIRE NUTS MAIN LOW VOLTAGE LIGHTING CABLE IntelliBrite Landscape Light Installation and User’s Guide... -
Page 13: Tilt And Horizontal Light Adjustment
Tilt and Horizontal Light Adjustment The IntelliBrite landscape light can be adjusted to position the light beam for “up” lighting of trees and shrubs, or “down” lighting for paths, driveway, deck and patio areas. TO PREVENT PERMANENT DAMAGE TO THE INSIDE THREAD OF THE LIGHT”S ELBOW JOINT,... -
Page 14: Light Toggle Switch Settings
HI BRIGHTNESS* HI LUMINANCE* LANDSCAPE INTELLIBRITE* Note: (*) default light switch settings Light toggle switch description IntelliBrite mode (see page 3). Landscape mode (see page 4) High Luminance: Bolder color tones Low Luminance: Softer color tones High Brightness: Equivalent to a 20 Watt halogen bulb (approximately). -
Page 15: Setting The Color Swim Effect (Optional)
HOLE Setting the Color Swim Effect (optional) The additional “Color Swim” effect feature works with any of the “IntelliBrite” or “Landscape” color shows . The color effect starts from the first light, then the color change is delayed across to the adjacent lights creating a wave effect. - Page 16 6 9 0 0 3 4 P/N 690034 - Rev C IntelliBrite Landscape Light Installation and User’s Guide...
