30 Watt Speaker
ELK-44
The ELK-44 is a universal 30 Watt - 8 Ohm
Speaker which may be connected to any siren
driver or amplifier. It features a heavy duty voice
coil and magnet, allowing it to withstand up to 50
Watts of peak power. The ELK-44's removable "U"
shaped mounting bracket makes installation quick
and simple. It's small and compact size allows it to
be placed in vents, attic eaves and soffits, and
other unique locations where large and bulky units
will not fit.
Features
• Installer Friendly - Easy To Mount.
• Exterior / Interior use.
• Compact - Less Noticeable.
• Loud - Rivals Sound of Larger Speakers.
• Heavy Duty 1.8 lb Magnet.
• High Fidelity Voice Coil.
• Lifetime Limited Warranty.
Specifications
• Rating: 30 Watts Nominal / 50 Watts Peak.
• Impedance: 8 Ohms.
• Frequency Response: 500 to 7000 Hz.
• Size: 4"H x 4"W x 3.5"D.
Features or Specifications subject to change without notice.
PO Box 100 • Hildebran, NC 28637 • 800-797-9355 • 828-397-4200
Fax 828-397-4415 • www.elkproducts.com • info@elkproducts.com
05/02
ELK
PRODUCTS, INC.
Advertisement
Table of Contents
Related Manuals for Elk Products ELK-44
Summary of Contents for Elk Products ELK-44
- Page 1 30 Watt Speaker ELK-44 The ELK-44 is a universal 30 Watt - 8 Ohm Speaker which may be connected to any siren driver or amplifier. It features a heavy duty voice coil and magnet, allowing it to withstand up to 50 Watts of peak power.
- Page 2 4. Slide the speaker onto the bolt heads. Install a washer and nut on each bolt and tighten. 5. Connect Black and Red wires to the output of a siren driver or amplifier. ELK-45 ELK-44 WIRING CONFIGURATIONS ONE SPEAKER (8 OHMS) FOUR SPEAKERS (8 OHMS)
