Summary of Contents for FAURE FWG 3125
- Page 1 User manual Washing Machine FWG 3125 FWG 5145...
-
Page 2: Table Of Contents
Contents Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2 What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13 Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4 Technical data _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 15 Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5... -
Page 3: Child Safety
• After having installed the appliance, check that it is • Never use the appliance if the power supply cable, not standing on the inlet and drain hose and the the control panel, the working surface or the base worktop is not pressing the electrical supply cable are damaged so that the inside of the washing ma- against the wall. -
Page 4: Product Description
Product description Detergent dispenser drawer Control panel Door opening handle Rating plate Drain pump Adjustable feet Detergent dispenser drawer Compartment for detergent used for prewash and soak phase or for stain remover used during the stain action phase (if available). The prewash and soak de- tergent is added at the beginning of the wash pro- gramme. -
Page 5: Control Panel
Control panel Below is a picture of the control panel. It shows the programme selector dial as well as the buttons, pilot lights and the display. These are presented by relevant numbers on the following pages. Programme selector dial START/PAUSE button SPIN reduction button DELAY START button OPTIONS button... -
Page 6: First Use
Extra Rinse When selecting a washing programme both lights This appliance is designed for saving energy. If it nec- 7.1 (Wash) and 7.2 (Rinses/Spin) illuminate. essary to rinse the laundry using an extra quantity of After having pressed the button 5 the only light cor- water (extra rinse), select this option. - Page 7 Measure out the detergent and the fabric Select the available options by pressing softener buttons 3 and 4 Depending on the programme, different functions can be combined. These must be selected after choosing the desired programme and before starting the pro- gramme.
-
Page 8: Helpful Hints And Tips
Start the programme by pressing button 5 If you cannot open the door but you need to open it you have to switch the machine off by turning the selector To start the selected programme, press the button 5 , dial to O . -
Page 9: Degrees Of Water Hardness
Blood: treat fresh stains with cold water. For dried All commonly available washing machine detergents may be used in this appliance: stains, soak overnight in water with a special detergent then rub in the soap and water. • powder detergents for all types of fabric Oil based paint: moisten with benzine stain remover, •... -
Page 10: Washing Programmes
Main wash - Rinses PREWASH Maximum spin speed at 1400 rpm for model FWG 5145 SUPER QUICK (model FWG 3125 : 1200 rpm) EXTRA RINSE Max. load 6 kg - Reduced load 3 kg White cotton (heavily or normally soiled items). - Page 11 Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry EASY IRON SPIN 40° RINSE HOLD Main wash - Rinses PREWASH Maximum spin speed at 900 rpm EXTRA RINSE Max. load 1,5 kg Synthetic or mixed fabrics: selecting this programme the laundry is gently washed and spun to avoid any creasing.
- Page 12 RINSE HOLD Maximum spin speed at 1400 rpm for model FWG 5145 EXTRA RINSE (model FWG 3125 : 1200 rpm) Max. load 6 kg With this programme it is possible to rinse and spin cotton garments which have been washed by hand. The machine performs 3 rinses, followed by a final long spin.
-
Page 13: What To Do If
What to do if… Certain problems are due to lack of simple mainte- Once the problem has been eliminated, press the but- nance or oversights, which can be solved easily without ton 5 to restart the programme. If after all checks, the calling out an engineer. - Page 14 Problem Possible cause/Solution Too much detergent or unsuitable detergent (creates too much foam) has been used. • Reduce the detergent quantity or use another one. Check whether there are any leaks from one of the inlet hose fittings. It is not always easy to see this as the water runs down the hose;...
-
Page 15: Technical Data
Water supply pressure Minimum 0,05 MPa Maximum 0,8 MPa Maximum Load Cotton 6 kg Spin Speed Maximum 1200 rpm (FWG 3125) 1400 rpm (FWG 5145) Consumption values Programme Energy consumption Water consumption (li- Programme duration (KWh) tres) (Minutes) White Cottons 90°... -
Page 16: Care And Cleaning
Programme Energy consumption Water consumption (li- Programme duration (KWh) tres) (Minutes) Synthetics 40° Delicates 40° 0.55 Wool/ Handwash 30° 0.25 1) «Cottons Eco» at 60°C with a load of 6 kg is the reference programme for the data entered in the energy label, in compliance with EEC 92/75 standards. -
Page 17: Cleaning The Water Inlet Filter
Place a bowl with a small Replace the emergency edge close to the pump emptying cap into the fil- to collect any spillage. ter cover and fix it firmly. Pull out the emergency Close the pump door. emptying cap from the fil- ter cover, using a pliers. -
Page 18: Installation
• Refit the emergency emptying cap into the filter and by gravity into the bowl. When the bowl is full, refit screw the water inlet hose back. the emergency emptying cap into the filter. Empty the bowl. Repeat the procedure until water stops •... -
Page 19: Water Inlet
If necessary, check the The other end of the inlet hose which connects to the setting with a spirit level. appliance can be turned as showed in the picture. Do not place the inlet hose downwards. Angle the hose to the left or right depending on the position of your water tap. -
Page 20: Electrical Connection
Electrical connection Information on the electrical connection is given on the any responsibility for damage or injury through rating plate on the inner edge of the appliance door. failure to comply with the above safety precaution. Check that your domestic electrical installation can take Caution! The power supply cable must be the maximum load required, also taking into account easily accessible after installing the machine. - Page 24 192995700- 00 - 022009...
