Summary of Contents for Global Machinery Company PEDG
- Page 1 INSTRUCTION MANUAL • Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris Petrol Lawn Edger PEDG 050603 ED10 JJ...
-
Page 2: Table Of Contents
Description of symbols Specifications Safety instructions Additional safety rules for edgers Contents of carton Unpacking Know your product Assembly Fueling Starting the edger Stoping the edger Running in the engine Cutting depth Edge guide Edging Landscaping / trenching Changing the blade Maintenance... -
Page 3: Dear Customer
Dear Customer If you require any help with your product, whether it is a Warranty claim, spare part or user information, please phone our Help Line for an immediate response. Phone 1300 880 001 in Australia or 0800 445 721 in New Zealand. -
Page 4: Specifications
Specifications Engine: 26cc, 2 Stroke Speed: 0 - 2200min Depth of cut: 10mm, 20mm, 30mm Size of blade: 180mm Bore size: 18mm fuel type: Unleaded Fuel mixture: Unleaded petrol / oil (40:1) Fuel tank capacity: 700ml Equivalent Spark plugs: NGK BM4A CHAMPION CJ14 DENSO W14M-U10 BOSCH WS8E... -
Page 5: Additional Safety Rules For Edgers
Never refuel whilst the engine running. • Be careful where you store the edger. Store the edger in a dry area away from flammable liquids. • Keep your distance. The edger emits exhaust fumes. -
Page 6: Contents Of Carton
• Always keep blade area clean. • When using the edger, stones, pieces of metal and other objects can be thrown out at high speed by the blade. The tool and guard are designed to reduce the danger. However, the following special precautions should be taken: •... -
Page 7: Know Your Product
Know your product 1. Lock off button 2. Throttle trigger 3. Ignition switch 4. Auxiliary handle 5. Shaft 6. Edger guide lever 7. Wheel 8. Auxiliary handle lock knob 9. Height adjustment knob 10. Guide wheel 11. Blade cut indicator 12. -
Page 8: Assembly
Assembly Inserting the shaft Remove the nut from the hole in the base of the edger and insert the shaft. Replace the nut and retighten it. Telescope handle adjustment The shaft handle can be set at three different heights. To set the height for your... -
Page 9: Starting The Edger
4. After the first two hours of work, stop and make sure that all nuts and screws are securely fastened, and tighten them if necessary. Cutting depth The cutting depth of the edger can be altered to one of 3 settings 10mm, 20mm and 30mm. -
Page 10: Edge Guide
4. Before starting the edger, line up the tool so the edge guide rests against the edge of the paved surface, both rear wheels should be on the paved surface when edging. -
Page 11: Landscaping / Trenching
Lift the edge guide lever (6) for all trenching. Set depth to only that required for the job, do not overload, if tool slows, pull back slightly and wait until the blade returns to normal speed. -
Page 12: Storage And Maintenance After Use
Do not store in a nylon bag as this can encourage the formation of mould. • At the end of the season, give the petrol edger an overall cleaning and a thorough check. Whenever the machine is not used for a long period of time, proceed as follows: •... - Page 16 Carefully read the entire Instruction Manual before using this product. Before returning this product for a Warranty Claim or any other reason Please Call 1300 880 001 (Australia) or 0800 445 721 (New Zealand) When you make your call, please have the following information at hand: •...
