Healthy Climate Solutions HCWB2 Series User Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

E 2007
Dallas, Texas, USA
USER'S MANUAL FOR HCWB2 AND HCWP2 HUMIDIFIERS
Table Of Contents
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Humidifier Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Instructions −− Manual Humidistat
Operating Instructions −− Universal Humidistat
Operating Instructions (Automatic Mode)
Introduction
This manual includes information that will familiarize you
with your humidifier. It also details routine maintenance
required to keep the humidifier working properly.
!
WARNING
Electric shock hazard. Can cause injury
or death. Disconnect all electrical power
supplies before servicing. Shut off water
supply before disconnecting or tapping
into any water supply line.
!
CAUTION
Risk of Equipment Damage. After humidifier
installation is completed, turn water supply back
on.
IAQ −− HUMIDIFIERS
505,289M
08/2007
Supersedes 02/2007
KAZ # C.6046
1
Operating Instructions (Manual Mode)
Effect of Water Characteristics
1
Annual Maintenance
. . . . . . . .
2
Annual Shutdown
. . . . . .
2
Dealer Instructions for Preventative Maintenance
. . . . . . . . . .
3
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Humidifier Operation
This humidifier provides the proper relative humidity (RH)
during the heating season. The humidifier is wired to
operate when the indoor blower motor is on during the
heating mode and the indoor RH is below the selected
comfort level. During a call for humidity, water flows into
the EquaFlot distribution tray, where it is distributed
evenly across the width of the pan. The humidifier pad is
saturated with water. Dry hot air moves through the pad
where evaporation takes place. The humidified air carries
moisture in vapor form throughout the home.
Risk of Equipment Damage. Do not use the saddle
valve to regulate water flow. The valve is designed
to be completely opened or closed.
Page 1
HCWB2 & HCWP2 SERIES
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
!
CAUTION
Litho U.S.A.
3
4
4
4
.
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCWB2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Healthy Climate Solutions HCWB2 Series

Summary of Contents for Healthy Climate Solutions HCWB2 Series

  • Page 1 IAQ −− HUMIDIFIERS Litho U.S.A. 505,289M E 2007 08/2007 HCWB2 & HCWP2 SERIES Dallas, Texas, USA Supersedes 02/2007 KAZ # C.6046 USER’S MANUAL FOR HCWB2 AND HCWP2 HUMIDIFIERS Table Of Contents Introduction ........Operating Instructions (Manual Mode) .

  • Page 2: Manual Humidistat

    During humidifier operation, a steady stream of water TABLE 1 flows to the drain. This water flushes away minerals and Relative Humidity (RH) Settings other particles of solid residue. Some particles are Outside Temperature Recommended RH trapped by the humidifier pad. This eliminates the white (Fahrenheit) dust"...
  • Page 3 steps to adjust the automatic humidifier control. See 3 − Turn the control dial setting to the OFF position. figure 2. Then, slowly turn the dial clockwise until you hear the solenoid valve click on. Slowly turn the dial counterclockwise until you hear the solenoid valve UNIVERSAL HUMIDISTAT click off.

  • Page 4: Maintenance

    compromise between RH levels that are desirable for Maintenance comfort reasons and humidity levels, which will avoid NOTE − Annual inspection and maintenance is important condensation on your windows. for efficient and safe operation of your humidifier. Call The humidistat can be used to accurately determine the your dealer for humidifier service and maintenance RH in your home during the winter.

  • Page 5: Hcwb2 Required Maintenance

    HCWB2 REQUIRED MAINTENANCE 9 − Remove the drain hose from the bottom of the humidifier. Bend and flex the hose to loosen any Component identification for the following procedure is internal calcium deposits. Flush the hose with water listed in figure 3. under pressure and slip it back onto the drain spud.

  • Page 6: Hcwp2 Required Maintenance

    HCWP2 REQUIRED MAINTENANCE 10 −Remove the drain hose from the bottom of the humidifier. Bend and flex the hose to loosen the Component identification for the following procedure is internal calcium deposits. Flush the hose with water listed in Figure 4. under pressure and slip it back onto the drain spud.
