Tripp Lite PDU3MV6L2120LV Specifications

Model Number: PDU3MV6L2120LV
3-Phase Metered PDU, 5.7 kW, 42 5-15/20R outlets, 120V output, 6 ft NEMA L21-20P input connection
Description
Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps via set of 3 built-in digital meters.
Enables visual monitoring of PDU current levels to preserve proper loading balance and prevent circuit overloads as additional equipment is added.
Offers reliable rackmount multi-outlet power distribution from any protected UPS, generator or mains input power source. High quality design
includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
Applications
Ideal for 3 phase network configurations in datacenters and heavily configured equipment racks
Package Includes
Metered Rackmount PDU with pre-installed mounting buttons
Cord retention brackets
Spare installation buttons (2 9mm / 4 6mm)
Rack mounting brackets
Owner's manual
Features
5.7kW 3 phase 120V output Metered Power Distribution Unit / PDU
Set of 3 built-in current meters continuously report load current per phase
Attached NEMA L21-20P 20A (3P+N+E) 208V 3 phase input plug with 6 ft. / 1.8m cord
0U, 70 in. / 178cm vertical form factor supports installation in 2 or 4 post equipment racks
42 total outlets arranged in three single phase output load banks
NEMA 5-15/20R outlets output 120V
Included cord retention brackets keep vital network equipment plugged in and continuously powered
Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications (set of
2 9mm buttons pre-installed, 2 9mm and 4 6mm spare buttons included)
TAA Compliant Version Available - Order Tripp Lite PDU3MV6L20LVTAA
Specifications
OVERVIEW
PDU Type
Highlights
Metered
Metered 5.7kW 3 Phase 120V output PDU; 70 in. / 178cm 0U vertical
rackmount
Reports load level per-phase via built in current meters
NEMA L21-20P (3P+N+E) 208V 3 phase input; 6 ft. / 1.8m line cord
42 NEMA 5-15/20R outlets (120V)
Toolless button-mount installation; cord retention brackets included
