CRB Mounting Bracket INST ALLA TION INSTRUCTIONS Note: This mounting bracket is designed for use with the Boston Acoustics CR6 and CR7 loudspeaker systems. Use with any other speakers may result in damage to the speaker system or the mounting surface.
Page 2
INSTALLATION • Determine the mounting orientation. Horizontally, with adjustable tilt downward Vertically, with adjustable pivot side-to-side • Identify the appropriate holes on the back of the speaker for the BRACKET: For horizontal mounting, use these holes Boston Boston For vertical mounting, use these holes •...
Page 3
• Drill the wall holes: Horizontal Vertical mounting, Vertical mounting, mounting– arrows left speaker– right speaker– ar- pointing up arrows pointing rows pointing right left Holding the BASEPLATE in position as a template, mark the centers of the two elongated mounting holes with a pencil. Drill "...
Page 4
Wiggle speaker slightly to make sure both of the pins on the speaker are fully engaged into the bottom of the T-slots. BostonAcoustics Boston and Boston Acoustics are registered 300 Jubilee Drive trademarks of Boston Acoustics, Inc. Peabody, MA 01960 Specifications subject to change without notice.
