OWNER'S MANUAL
HELLO KITTY COUPE
,
this manual contains important safety
performance and
.
maintenance information
read the manual before taking your
first ride or allowing your child to ride your new electric
-
.
.
ride
on toy
keep the manual handy for future reference
DO NOT RETURN TO STORE!
QUESTIONS OR COMMENTS?
STOP
1-800-288-1560
FOR AGES 3-8 YEARS
MAXIMUM WEIGHT: 65 lbs. (29.5 kgs)
NOTE: Illustrations in this Manual are for reference purposes only and may not reflect the exact
appearance of the actual product. Specifications are subject to change without notice.
©1976, 2012 Sanrio Co., LTD. Used Under License.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coupe and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hello Kitty Coupe

  • Page 1 OWNER’S MANUAL HELLO KITTY COUPE this manual contains important safety performance and maintenance information read the manual before taking your first ride or allowing your child to ride your new electric ride on toy keep the manual handy for future reference...
  • Page 2 TABLE OF CONTENTS A Introduction, Safety and Warnings B Before You Begin Assembly C List of Assembled Parts D Assembly E How to Use Your Vehicle F Detailed Maintenance and Repair G Troubleshooting Guide H Warranty ELECTRIC CAR SPECIFICATIONS SUITABLE AGE 3-8 Years CAPACITY under 65lbs (29.5kgs)
  • Page 3 INTRODUCTION, SAFETY, AND WARNINGS ABOUT THIS MANUAL: This Manual was written to help you and your child get the most performance, comfort, enjoyment and safety when riding your new electric ride- on toy. It is important for you to understand your new electric ride-on toy. By reading this manual before you let your child go out on his/her first ride, you will know how to get the most from your new electric ride-on toy.
  • Page 4 Always wear appropriate clothing and shoes, including long sleeved shirts and long pants and lace-up or similar shoes with rubber soles. Never ride barefoot or in sandals and make sure that shoelaces or other fasteners are tied and kept away from the wheels and drive system of the ride-on toy.
  • Page 5 SAFE RIDING PRACTICES AND WARNINGS • Check and obey all local laws or regulations which may be in effect in the locations where the electric ride-on toy may be used. • Always wear a helmet and other safety equipment and appropriate clothing and shoes.
  • Page 6 • Do not to allow hands, feet, hair, body parts, clothing, or similar articles to come in contact with wheels or other moving parts. • Before each cycle of operation, you must perform the preoperation checks specified in this manual or by the manufacturer, including: • That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;...
  • Page 7 BEFORE YOU BEGIN ASSEMBLY WARNING Remove all packing and items from the display box. Make sure that the power switch is turned “OFF” before assembling the electric ride-on toy. ESTIMATED ASSEMBLY TIME You should allow approximately 25 minutes for assembly, not including initial charging time.

  • Page 8: Assembled Parts

    LIST OF ASSEMBLED PARTS Seat Main body Assembly Windshield Audio Input Cable View mirrors Hardware in poly bag Steering wheel set Charger Steering Column If you experience a problem with this product, or are missing a part, please call us at 1-800-288-1560, rather than return this product to the store.

  • Page 9: Parts Diagram

    PARTS DIAGRAM Plastic Body Assembly M5x35 Machine Screw View Mirrors Rear Wheel M10 Lock Nuts Front Wheel Ø10 Washer Gear Box Seat Charger Ø5 nut Windshield M5x16 Machine Screws Bushing Steering Column Axle Cap Rear Wheel Axle 4x12 Round Head Screws 10.

  • Page 10: Assembly

    ASSEMBLY Your new vehicle requires adult assembly. Please set aside around 25 minutes for assembly. Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. Tools Required: Phillips Screwdriver (not included) Standard slip joint pliers (not included) WARNING: Children can be harmed by small parts, sharp edges and sharp...

  • Page 11: Steering Wheel

    2. Steering Wheel Assembly • Put the vehicle body upright. • Remove the M5x35 machine screw and Ø5 nut from the steering wheel. • Insert the steering wheel to the end of the steering column. • Insert the M5x35 machine screw through the steering wheel and steering column (make sure to align their holes),...
  • Page 12 5. View Mirrors Assembly • Insert the view mirror into the hole in the vehicle body and push until you hear this click into place. • Repeat for the other side. 6. Connect Audio Input Cable • Plug the audio input cable on AUX line-in jack on the vehicle.

  • Page 13: Battery Charging

    BATTERY CHARGING IMPORTANT! Before first time use, charge the battery for at least 18 hours. Charge the battery for at least 12 hours after each use of the vehicle. Never charge the battery longer than 30 hours. Over charging or undercharging the battery may shorten battery life and decrease vehicle running time.

  • Page 14: Charging

    • Do not charge the battery on a surface (such as a kitchen counter top) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery. • Use only an original charger (120VAC 60Hz) with an output of 6 VDC (1A) to charge your vehicle battery.

  • Page 15: How To Use

    HOW TO USE YOUR VEHICLE FORWARD Move the “Forward-Backward switch” into the “Forward” position. Press the “Foot pedal”, and the vehicle will move forward. STOP The vehicle will stop automatically, when your child’s foot is removed from the “Foot pedal”. BACKWARD Press the “Forward-Backward Switch”...
  • Page 16 Plug one end of the audio input cable (included) into the audio input jack on the vehicle as shown. Plug the other end of the audio input cable into the headphone jack on your audio device or MP3 player. Note: You may be able to place your audio device or MP3 player inside the vehicle windshield as shown.

  • Page 17: Safety Precautions

    SAFETY PRECAUTIONS • Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time. • The child must have adult supervision at all times. • Do not ride on the road, footpaths, near pools, or bodies of water. •...
  • Page 18 DETAILED MAINTENANCE AND REPAIR Turn power “OFF” before conducting any maintenance procedures. Tools Required: Flat head Screwdriver 17mm Socket Wrench (not included) (not included) HOW TO REPLACE FRONT WHEELS Remove the Axle Cap with a flat head screwdriver. Remove the M10 locknut with a 17mm socket wrench. Remove the Ø10 washer.

  • Page 19: Replacing Rear Wheel And Gear Box

    HOW TO REPLACE REAR WHEEL AND GEAR BOX Remove the Axle Cap with a flat head screwdriver. Remove the M10 locknut with a 17mm socket wrench. Remove the Ø10 washer. Remove the driving wheel, and replace with new wheel. If you need to replace the gear box, please proceed to the next step. Unscrew the screws on the seat with a screwdriver and remove the seat.

  • Page 20: To Replace Power Switch

    HOW TO REPLACE THE POWER SWITCH Remove the power switch holder with a flat head screwdriver (not included). Take out the holder as shown. Unplug the main connector from the power switch as shown. Push down the clips on both sides of the switch (see 4-1), take out the switch from the holder (see 4-2), and then replace with a new switch.

  • Page 21: Battery Care And Disposal

    BATTERY CARE AND DISPOSAL Do not store the battery in temperatures above 75° F (23.5° C) or below 32° F (0°C). THIS SCOOTER CONTAINS SEALED LEAD ACID BATTERIES WHICH MUST BE RECYCLED IN ACCORDANCE TO YOUR LOCAL AND STATE LAWS. PLEASE CAREFULLY READ AND UNDERSTAND THE FOLLOWING DISPOSAL INSTRUCTIONS: Disposal: This product contains sealed lead acid batteries which must be disposed of...
  • Page 22 MAINTAINING YOUR VEHICLE Occasionally use a lightweight oil to lubricate moving parts such as wheels and the steering linkages. Park the vehicle indoors or cover it with a tarp to protect it from wet weather. Keep the vehicle away from sources of heat, such as stoves and heaters. Plastic parts may melt.

  • Page 23: Troubleshooting

    TROUBLESHOOTING GUIDE Problem Possible Cause Solution Vehicle does not run Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 12 hours after each use.
  • Page 24 Problem Possible Cause Solution Tripped thermal fuse The built-in thermal fuse may “trip” and shut down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once a fuse has “tripped”, release the button on the handle and wait 25 seconds before operating the vehicle again.
  • Page 25 Problem Possible Cause Solution Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first- time use, recharge the battery for at least 12 hours after each use.

  • Page 26: Limited Warranty

    WARRANTY Limited Warranty Subject to the following limitations, all electric ride-on toys manufactured for Dynacraft are warranted to the original purchaser to be free of defects in materials and workmanship for a period of 90 days from the date of purchase. No other express or implied warranty is given.

  • Page 27: Customer Service

    Dynacraft Customer Service 1.800.288-1560 7AM TO 4PM PACIFIC TIME Please have the following information available when you call: Model Number: (sample: 8595-95) Production Date: (sample: 2003.10.10) Serial Number: (sample: 03TD5899988) Having this information is required and helps us handle your call more effectively. DO NOT return this item to the store.
