DigilinX™ ns-IPD-100
iPod
Docking station
®
InstallatIon Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DigiLinX NS-IPD-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Netstreams DigiLinX NS-IPD-100

  • Page 1 DigilinX™ ns-IPD-100 iPod Docking station ® InstallatIon Manual...
  • Page 2 DigilinX ns-IPD-100 iPod Docking station Installation Manual Clearone Document no. 800-000-045 Rev. 1.1 - March 7, 2011 © 2011 ClearOne and NetStreams. All rights reserved. No part of this document may be reproduced in any form or by any means without written permission from ClearOne and NetStreams.

  • Page 3: Table Of Contents

    able of onTenTs CHaPtER 1: IntRoDuCtIon ................1 Product Overview ....................1 Service and Support ....................1 Technical Support ....................1 Sales and Customer Service .................1 Product Returns .....................1 Package Contents ....................1 CHaPtER 2: BasIC systEM ConnECtIons ............ 2 CHaPtER 3: DEalER sEtuP anD ConFIGuRatIon ........3 Screen Overview ....................3 Setup ........................4 CHaPtER 4: tECHnICal sPECIFICatIons ............

  • Page 4: Chapter 1: Introduction

    CHaPtER 1: IntRoDuCtIon PRoDuCt ovERvIEW The NS-IPD-100 connects to a DigiLinX system and becomes an integral part of the multi-room audio system. It charges the iPod battery and provides control of iPod playback from the DigiLinX system. The sleek NS-IPD-100 is the DigiLinX interface to Apple iPod media players.

  • Page 5: Chapter 2: Basic System Connections

    CHaPtER 2: BasIC systEM ConnECtIons Use the diagram below to configure a basic system integration. > notE: Cat5e cable run between the netstreams aP500 and the EIM Port on the host device (netstreams tla250 in above diagram) should not exceed 60’ in length. Cat5e cable runs back to the switch (netstreams sW1124 in above diagram) should not exceed 300’...

  • Page 6: Chapter 3: Dealer Setup And Configuration

    CHaPtER 3: DEalER sEtuP anD ConFIGuRatIon sCREEn ovERvIEW The components of the Dealer Setup screen are outlined below. technical support: 800-283-5936...

  • Page 7: Setup

    sEtuP Use the following steps to configure an IP Address and the optional DHCP Server. Launch the Dealer Setup application. The Dealer Setup application will search and identify each IPD100 device currently on the NetStreams network. A list of found devices will appear in the Device Panel of the Dealer Setup screen.
  • Page 8 On the Device Panel, click on the Enable Static IP and enter the IP , Subnet Mask and Gateway addresses of the interface device (TLA250 as shown in the Basic Connection diagram). Optionally, check the Enable DHCP checkbox if a DHCP server is to be used. If the DHCP is enabled and a DHCP server are not avail- able, the TLA250 or the SL251 will revert to the Auto IP address settings in the Dealer Setup.
  • Page 9 Select the Audio Port tab on the Device Panel. Locate the Service Name field on the Device Panel. Enter the name of the IDP100. This name will appear on the user interface as a source or it can be left with the default name. Click on the drop-down arrow to the right of the iPod Dock option to display a list of IPD100 devices on the network.
  • Page 10 Click on the “ send Configuration to Devices” button from the Dealer Setup toolbar. Click on the “ select all” button from the dialog screen that appears then click on the “ok” button. Once the system is done updating the new device, a dialog window will display a message stating that the update is complete.
  • Page 11 Click the “ X” button in the upper-right of the dialog window to exit this screen. From the user interface (TLA250 in the Basic Connection diagram), set the Source to be the iPod Docking Station. This will allow the end user to control the connected iPod, access its library of music, make selections and view the metadata (including cover art) of the selection.

  • Page 12: Chapter 4: Technical Specifications

    EMEa aPaC 5225 Wiley Post Way tel: 801-974-3621 tel: 44 (0) 1189 036 053 tel: 801-303-3388 Suite 500 E-mail: global@ClearOne.com E-mail: global@ClearOne.com E-mail: global@ClearOne.com Salt Lake City, UT 84116 tel: 801-975-7200 toll Free: 800-945-7730 Fax: 801-977-0087 E-mail: sales@ClearOne.com...
