Selecting Picture Mode

Selecting Picture
Mode
• Select the Picture mode
that is appropriate
depending on the kinds
of pictures, you enjoy.
44
1
Selecting Picture Mode
• Press the [PICTURE MODE] on the
remote control.
• While pressing the [PICTURE MODE] for
the first time, the current picture mode will
be displayed.
Each Press of the Button Will Select
2
One of Four Picture Modes.
Normal
* Normal :
* Dynamic: For a clear-cut image emphasizing high contrast
* Cinema:
* User:
3
Menu on the Screen will disappear.
• After selecting a desired picture mode, the
menu on the screen will be disappeared.
• If you want to customise the picture mode,
refer to the following page.
NOTES:
1) Normal, Dynamic, and Cinema modes are factory preset values.
2) When adjusting sub-menus while you are in Normal, Dynamic,
and Cinema modes, the Picture Mode will be automatically
converted to User Mode, and the adjustments will be made.
3) Selecting [Initialize] in the [Features], menu will allow the
Brightness, Contrast, etc. to return to the factory preset values.
• Each time you press the button, a
different picture mode appears. The
sequence used is as follows:
Dynamic
Cinema
For a highly defined image in a normally bright
room
for sports viewing
For a movie
Allows the user to customise settings as desired.
User
