Summary of Contents for ZENEC ZE-NC4612
- Page 1 ZE - NC4612 CAR SPECIFIC NAVICEIVER FOR MERCEDES-BENZ VEHICLES USER MANUAL...
-
Page 2: Table Of Contents
6. Do not disassemble or alter the unit in any way, because it will void your warranty. Do not attempt to repair or to service the unit yourself, but contact an authorized ZENEC dealer instead. PLAYBACK OF A/V SOURCES ..............14-19 7. -
Page 3: Front Panel Buttons
ZE - NC4612 FRONT PANEL BUTTONS FRONT PANEL BUTTONS FRONT PANEL BUTTONS Front Panel 1. INTERNAL MICROPHONE 14. SMART DIAL Rotate to move a cursor up and 2. IR RECEIVER down Press to confirm a selection 3. POWER ON/OFF Press to power on/off device 15. -
Page 4: Operation Of Steering Wheel Controls
Press and hold to fast forward 2. PREVIOUS* Press to choose previous Track|Chapter|Station Press and hold to fast rewind 3. MFA SOURCE+ No function for ZENEC device 4. MFA SOURCE- No function for ZENEC device 5. VOL+ Press to increase volume 6. -
Page 5: Basic Operation
ZE - NC4612 BASIC OPERATION BASIC OPERATION BASIC OPERATION POWER ON/OFF Basic elements (for all playback sources) Correctly installed, your device will power on together with the ignition of the vehicle. Ignition off: Device does not receive power. When the ignition is activated, you may ... - Page 6 ZE - NC4612 RADIO MODE RADIO MODE RDS text allows a radio station to transmit Display elements: free-form textual information that can be Red line marks current frequency either static e.g. station slogans or in sync ...
-
Page 7: Radio Mode
ZE - NC4612 RADIO MODE RADIO MODE Lower bar options: The selected item is highlighted in orange on the screen: Select preset or save a preset. Press and hold a center button to enter a new ON/OFF: When activated, AF function automatically switches to an frequency as preset. - Page 8 ZE - NC4612 PLAYBACK IPOD/USB/SD/DISC PLAYBACK IPOD/USB/SD/DISC Playback page: Playlist page iPod: Display elements: Display elements: iPod mode Source Track/folder/playlist Current folder/playlist Current folder ID3 tag info Progress bar ...
- Page 9 ZE - NC4612 PLAYBACK IPOD/USB/SD/DISC PLAYBACK IPOD/USB/SD/DISC Playlist page USB/SD/Disc: Search function: Display elements: iPod search: Tapping on Search pops up an Track index alphabetic keyboard, allowing you Track/folder to enter an initial letter. Alphabetic Current folder ...
- Page 10 information on the playlist page. To playlist/root menu of DVD Full screen mode DVD settings NOTE: See www.zenec.com for: Compatible fi le formats and their possible restrictions. iPod/iPhone compatibility list.
- Page 11 ZE - NC4612 BLUETOOTH MODE BLUETOOTH MODE Bluetooth main menu: Accept call, dial, hang up, switch between calls: Tap icon to select element. Control elements: Display elements: First incoming call Onscreen keypad Caller I Second incoming call ...
-
Page 12: Bluetooth Mode
ZE - NC4612 BLUETOOTH MODE BLUETOOTH MODE Pairing a mobile phone: Enter BT settings > Device Enter PIN code and tap OK or retry PIN code Deletes the last digit Acknowledge PIN code and continue ... - Page 13 ZE - NC4612 BLUETOOTH MODE BLUETOOTH MODE Contacts - Manage phonebook: Manage phonebook: Control elements: Control elements: Back to BT main menu Go back to BT main menu Tap a contact number to start a call Go to contacts page ...
- Page 14 It cannot be guaranteed, that all mobile phones can be paired and that all functions will work. For the "BT compatibility list" of tested and compatible mobile phones as well as the latest software updates look out on www.zenec.com.
-
Page 15: Navigation Mode
ZE - NC4612 NAVIGATION MODE NAVIGATION MODE How to input a destination and start a route guidance: Tap on "Find". Choose your preferred destination search method. Here, in our example, choose "Find address". Type in a city, street name, house number and confirm each step by tapping NOTE:... -
Page 16: System Setup
ZE - NC4612 SYSTEM SETUP: MAIN / FIRST SETTINGS SYSTEM SETUP: IMPORT/EXPORT SYSTEM SETTINGS SYSTEM Main setup screen: Go to Setup>Misc>Help Export system settings: Control elements: 1. Format USB flash drive with FAT32. 2. Connect USB flash drive to device. Return to the previous menu. - Page 17 ZE - NC4612 SYSTEM SETUP: VIDEO NOTE: NOTE: Animated picture visualises TV shape Name Descriptor Function Choice/Range settings. Normal Video display TV-Shape TV-Shape setting Cinema Animated picture visualises your setting Brightness Day 0...20 TFT bright- during adjusting TFT screen brightness. Picture ness control Brightness Night...
- Page 18 ZE - NC4612 SYSTEM SETUP: AUDIO NOTE: NOTE: Audio mixer: Descriptor Function Choice/Range Choose "Last" to adjust to last volume. Start volume last value, set value Choose "Set" to adjust to an arbitrary Set start volume 0...40 value. TA volume last value, set value Audio mixer Level adjustments for sources:...
- Page 19 ZE - NC4612 SYSTEM SETUP: GENERAL NOTE: NOTE: System time gets periodically updated Name Function Choice/Range by GPS time stamp. Beep On, Off Radio area Europe, USA, Latin (America) Main Bluetooth On, Off Beep Volume Pop-Up On, Off Antenna supply On, Off Animated picture visualises your driver assist settings.
- Page 20 Press "OK" to launch a software update. For preparations and details, consult the accompanying update installation instructions BEFORE you run software NOTE: updates. Compare installed software versions with potentially newer versions on www.zenec.com (see support and download area for updates).
-
Page 21: Remote Control Main
ZE - NC4612 REMOTE CONTROL MAIN REMOTE CONTROL MAIN REMOTE CONTROL MAIN Remote Control Buttons 1. SOURCE Choose between playing modes 2. PREVIOUS Press to choose the previous track, title or chapter Press to decrease the receiving frequency to search for a radio station Press and hold to fast rewind 3. - Page 22 ZE - NC4612 REMOTE CONTROL M-ZONE REMOTE CONTROL M-ZONE REMOTE CONTROL M-ZONE Remote Control Buttons MODE 14. FAST REVERSE Change source Fast reverse KEYPAD 15. FAST FORWARD Input track/chapter/title Fast forward MUTE 16. SLOW Mute/un-mute audio output Slow motion playback GOTO 17.
-
Page 23: External Playback And Sources
M-Zone monitors (blackscreen). The M-Zone volume cannot be adjusted on the device. Use the control For DVB-T reception you need to connect an external ZENEC DVB-T elements of the connected peripherals (i.e. roof monitor) instead, to adjust receiver. For a perfect compatibility match check out the manual and the the volume. -
Page 24: Glossary
ZE - NC4612 GLOSSARY TROUBLESHOOTING A2DP Advanced Audio Distribution Profile, Bluetooth Audio Problem Cause Solution AC-Control Optical indication showing air condition status information GENERAL A/V In Audio-Video Input AUX In Auxiliary Input, Audio only Input Radio fuse blown. Install new fuse with correct rating. CAN-Bus Controller Area Network-Bus;... -
Page 25: Specifications
ZE - NC4612 SPECIFICATIONS ZE-NC4612 TUNER Auto antenna not Connect the auto antenna GPS NAVIGATION SYSTEM properly connected. cable properly. • 3D High-Definition motor-caravan navigation system • 8 GB internal flash memory with map data for 46 Eastern and Western European countries •... -
Page 26: Warranty
ZENEC MODEL: ZE-NC4612 Dear customer, Serial number: ..........................Thank you for purchasing this ZENEC product. It is advisable to keep the original packaging material for any future transporting of the product. Should your ZENEC product require warranty Date of purchase: .......................... -
Page 27: Legal Disclaimer
Road vehicles - Electrical disturbances from conduction and coupling - Part 2: Electrical date. The information in this document is subject to change without prior notice. ZENEC shall not be liable for technical or editorial errors transient conduction along supply lines only or omissions contained herein;... - Page 28 ZE - NC4612 NOTES NOTES...
- Page 29 ZENEC by ACR AG · Bohrturmweg 1 · Bad Zurzach · Switzerland www.zenec.com Rev. A...
