MP3 PLAYER USER MANUAL
ITMP-505
Please read this manual carefully before operating your unit
Keep this manual convenient for reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITMP-505 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Innovative Technology ITMP-505

  • Page 1 MP3 PLAYER USER MANUAL ITMP-505 Please read this manual carefully before operating your unit Keep this manual convenient for reference.

  • Page 2: Table Of Contents

    Catalogue PREFACE---------------------------------------------------------------------------------------------------------------------------------------------------3 NOTICE------------------------------------------------------------------------------------------------------------------------------------------------------3 FEATURE---------------------------------------------------------------------------------------------------------------------------------------------------4 1. Buttons and the functions----------------------------------------------------------------------------------------------------------------------------5 1.1 MSC/VOI Operation -----------------------------------------------------------------------------------------------------------------------6 1.2 FM Operation---------------------------------------------------------------------------------------------------------------------------------7 1.3SYSOperation---------------------------------------------------------------------------------------------------------------------------------8 2. Operation Process-------------------------------------------------------------------------------------------------------------------------------------8 2.1 Open/Close Player -----------------------------------------------------------------------------------------------------------------------8 2.2 ModeSelection-------------------------------------------------------------------------------------------------------------------------------9 2.3 MSC(Music Mode) -------------------------------------------------------------------------------------------------------------------------9 2.3.1 Play Music----------------------------------------------------------------------------------------------------------------------------------9 2.3.2 Operation of Music Menu--------------------------------------------------------------------------------------------------------------10 2.4 VOI ( Voice Mode ) -----------------------------------------------------------------------------------------------------------------------14 2.4.1 Play Voice---------------------------------------------------------------------------------------------------------------------------------14 2.4.2 Operation of Voice Menu--------------------------------------------------------------------------------------------------------------14 2.5 FM (FM Mode) -----------------------------------------------------------------------------------------------------------------------------16...
  • Page 3 2.6.7 Memory Info------------------------------------------------------------------------------------------------------------------------------22 2.6.8 Edition--------------------------------------------------------------------------------------------------------------------------------------22 2.6.9 Default-------------------------------------------------------------------------------------------------------------------------------------23 2.6.10 Exit----------------------------------------------------------------------------------------------------------------------------------------23 2.7 USB Connection---------------------- ------------------------------------------------------------------------------------------- ---23 ----------------------------------------------------------------------------------------------- 3. Technical Specification--------------- --------24 4. Appendix: User's Guide of AMT-------- ----------------------------------------------------------------------------------------------- ---25 -------------------------------------------------------------------------------------------- Introduction------------------ -----------------25 -------------------------------------------------------------------------------------------- Notice------------------------------- -----------25 -------------------------------------------------------------------------------------------- Operation---------------------------------- ---25 ----------------------------------------------------------------------------------------- 4.1 System Startup and Functions----- ----25 4.2 Supported Music File Type -------------------------------------------------------------------------------------------...

  • Page 4: Preface

    PREFACE Please read the data along with the player carefully before you use it, so that you can operate it conveniently and fast. If the information of the book changes, we are sorry not to inform you separately. NOTICE 1. Do not use the player in the extra hot, cold, dusty or damp environments. 2.

  • Page 5: Feature

    installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...

  • Page 6: Buttons And The Functions

    1. Buttons and the functions 1. VOL- 2. VOL+ 3. LAST 4. NEXT 5. PLAY/PAUSE 6. NECK STRING HOLE 7. USB JACK 8. HOLD 9. LCD 10. MODE 11. REC 12. HEADPHONE JACK Attention: If there is no operation of the player within 5 seconds in all menus of each mode, the player will return to the main menu of the mode automatically;...

  • Page 7: Msc/Voi Operation

    1.1 MSC/VOI Operation Button Operation Play State Pause State Main Menu Submenu Return to top mode Return main Short Press Pause Play PLAY/ menu menu STOP Long Press Shut off Shut off Shut off Shut off Select next Short Press song Select next song Select next menu...

  • Page 8: Fm Operation

    1.2 FM Operation Tuning Button Operation Preset mode Auto scan Main menu Submenu mode Switch Select next Stop Return to FM Return to main Short Press PLAY/ Preset mode preset channel scanning mode menu STOP Long Press Shut off Shut off Shut off Shut off Shut off...

  • Page 9: Sysoperation

    1.3 SYS Operation Button Operation Main menu Submenu Short Press Return to top mode menu Return to main menu PLAY/ STOP Long Press Shut off Shut off Short Press Select next menu Select next menu NEXT Long Press Select next menu continuously Select next menu continuously Short Press Select last menu...

  • Page 10: Modeselection

    2. In the working state, long press the "PLAY" button will shut off the player; 3. In the process of power on if the player is in "HOLD" state, it will close after displaying the information; And also in the process of power on, if the battery is low, the player will shut off after displaying the information. 2.2 Mode Selection 1.

  • Page 11: Operation Of Music Menu

    2. Short press "PLAY" button, will pause or play music; 3. In the state of playing music, long press "NEXT" or "LAST" buttons, the player will fast forward or backward scan the active song; 4. Short press "NEXT" or "LAST" button, select next or last song; 5.
  • Page 12 4. Short press "PLAY" button, returns to last menu until enter into the main menu of music mode. EQ: includes Normal, Pop, Rock, Jazz, Headphone, Live and Bass; a. In playing state, short press "MODE" button and enter into Play Menu, select "Repeat"; b.
  • Page 13 a. In playing state, short press "MODE" button and enter into Play Menu, select "A-B Replay"; b. Short press "MODE" button and return to the main interface of music mode, "A-B" icon begins flicker; c. Short press "NEXT" button to set the A, B point of replay, and player will replay between the A, B point; d.
  • Page 14 a. In pause state, short press "MODE" button and enter into Pause Menu, select "Browse Folder"; b. Short press "MODE" again to confirm selection and enter into submenu; c. Press "NEXT/LAST" button to select different folder; d. Short press "VOL+" ("VOL-") button to enter into (exit) folder. And if the folder is root folder, press "VOL-" button to return to the main interface of music mode;...

  • Page 15: Voi (Voice Mode)

    d. Short Press "MODE" to confirm deleting, return to the main interface of music mode, and the player in the state of "No File". Attention: the player will return to the top mode menu after displays "No File" without any operation in two seconds.
  • Page 16 2. Short press "NEXT" or "LAST" button to switch menu item; 3. Short press "MODE" button to confirm the selection or enter into the submenu; 4. Short press "PLAY" button, returns to last menu until enter into the main interface of voice mode. Repeat: includes Repeat Folder, Repeat One, Normal, Random and Preview;...

  • Page 17: Fm (Fm Mode)

    Delete File: Delete the current file, which is playing; a. Short press "MODE" button and enter into voice menu, select "Delete File"; b. Short press "MODE" again to confirm selection and enter into submenu; c. Press "NEXT/LAST" button to select "Yes" or "No"; d.

  • Page 18: Operation Of Fm Menu

    2.5.1 FM 1. In the top mode menu, select the icon of "FM", short press "MODE" button, the player will enter into the main interface of FM mode 2. Short press "NEXT/LAST" button to turn the frequency by 0.1MHz step; 3.
  • Page 19 b. Short press "MODE" button to save current channel, and return to the main interface of FM mode; Attention: the player can save 30 channels at most, if you want to save a channel that has beyond 30, the player will save the channel on the last position.

  • Page 20: Sys (System Setting)

    d. Short press "MODE" button to confirm deleting all channels, and return to the main interface of FM. Normal Frequency: a. Short press "MODE" button and enter into FM main menu, select "Normal Frequency"; b. Short press "MODE" button to confirm selection and return to the main interface of FM; c.

  • Page 21: Power Off

    2. Short press "MODE" button again to confirm and enter into submenu; 3. Press "NEXT/LAST" button to select 0 (always light), 5, 10, 20 or 60 seconds; 4. Short press "MODE" button to confirm selection, and return to the main menu of system setting. 2.6.2 Power off: 1.

  • Page 22: Contrast

    2. Short press "MODE" button again to confirm and enter into submenu; 3. Short press "NEXT/LAST" button to choose "Manual Mode" or "Auto Mode"; 4. Short press "MODE" button to confirm selection. Attention: Manual Mode means that you should set Replay Times and Gap manually when playing music; Auto Mode means A-B replay continually without setting Replay Times and Gap.

  • Page 23: Auto Music Transfer

    2.6.6 Auto Music Transfer: Transform other audio format to the format of MP3. 1. Short press "MODE" button and enter into main menu of system setting, select "Auto Music Transfer"; 2. Short press "MODE" button again to confirm and enter into submenu; 3.

  • Page 24: Default

    2.6.9 Default 1. Short press "MODE" button and enter into main menu of system setting, select "Default"; 2. Short press "MODE" button again to confirm and enter into submenu; 3. Press "NEXT/LAST" button to select "Yes" or "No"; 4. Short press "MODE" button to confirm selection, and return to the main menu of system setting. Attention: Restore the original factory default settings, includes the menu setting.

  • Page 25: Technical Specification

    6. When the player transmits files, the USB interface will show "BUSY" on LCD. If the transmission has finished, it will show "IDLE" on LCD; 7. With the connection of player and PC by USB cable, you also can exit USB mode to play music: a.

  • Page 26: Appendix: User's Guide Of Amt

    Frequency scope: 76MHz – 108MHz FM Radio Number of channels: 30 Simple Chinese, English, Traditional Chinese, German, French, Italian, Spanish, Portuguese, Multilanguage Display Japanese, Korean, Danish and Swedish 4. Appendix: User's Guide of AMT Introduction AMT is the green software, which can convert the audio files automatically in OS. It means that AMT will transform the supported audio files to MP3 type files, and then store the MP3 files to the player.

  • Page 27: Supported Music File Type

    In static status, the program does not use system time, and the color of the icon represents the connection status between MP3 player and PC. Red stands for connected MP3 player, and black stands for unconnected MP3 player. When files are copied, pasted or dragged onto MP3 player plugged onto the USB port, ATM will convert pre-defined supported music files into MP3 type music files and then save them into corresponding position on MP3 player.

  • Page 28: Tone Quality, File Size And Conversion Speed

    Description of contents in the window is as follows. Automatic-conversion: While being chosen, automatic-conversion function will start up; otherwise, all files will be copied into MP3 player directly. WMA: WMA automatic-conversion flag. While being chosen, WMA file will be converted into MP3 file. RM: RM automatic-conversion flag.

  • Page 29: Menu

    Menu Right-click on AMT icon, and menu will be shown on corresponding position as follows. Safe File Folder (RAWDATA) AMT generates default safe file folder "RAWDATA" automatically. If there is no file folder "RAWDATA" found on the MP3 player plugged onto the PC, AMT will generate file folder "RAWDATA" automatically on the MP3 player. When files are copied or dragged into file folder "RAWDATA", AMT will not do the conversion, which means if original file copy is needed, it could be copied into file folder "RAWDATA"...

  • Page 30: Warranty

    Limited Warranty: 90 Days Labor, One Year Parts Innovative Technology Electronics Corp. (IT) warrants the product to be free from “Defects” in materials under normal use for a period of “One Year” from the date of the original purchase. The Warranty is “Not” transferable. IT agrees, within the initial “90 Day”...
