Page 1: Table Of Contents
TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE...1-1 1.2. KEY FEATURES ...1-1 1.3. PERFORMANCE LIST...1-2 1.4. BLOCK DIAGRAM ...1-3 1.5. INTRODUCE THE Pentium 1.6. What is AGP ...1-6 SPECIFICATION 2.1. HARDWARE ...2-1 2.2. SOFTWARE...2-2 2.3. ENVIRONMENT...2-2 HARDWARE INSTALLATION 3.1. UNPACKING ...3-1 3.2. MAINBOARD LAYOUT ...3-2 3.3. - Page 2 3.9. POWER LED CONNECTOR INSTALLATION ...3-7 3.10. IDE & ATAPI DEVICE INSTALLATION...3-7 3.11. PERIPHERAL DEVICE INSTALLATION...3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION...3-7 BIOS CONFIGURATION 4.1. ENTERING SETUP ...4-1 4.2. CONTROL KEYS ...4-1 4.3. GETTING HELP...4-2 4.3.1. Main Menu...4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu...4-2 4.4.
-
Page 3: Introduction
INTRODUCTION 1.1. PREFACE Welcome to use the 6EA motherboard. It is a Pentium PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor... -
Page 5: Block Diagram
1.4. BLOCK DIAGRAM 66MHz SLOT 1 SLOT Host Bus 82443EX AGP Bus CHIPSET 66MHz Ultra DMA/33 IDE Ports PCI Bus PIIX4 82371EB IDE Bus CHIPSET ISA Bus 14.318MHz 3.3V EDO/SDRAM DIMM Sockets DRAM Bus 33MHz 66MHz 33MHz 52C64-05 33MHz 48MHz 14.318MHz USB Ports USB Bus... -
Page 6: Introduce The Pentium Ii Processor
Introduction 1.5. INTRODUCE THE Pentium II Processor Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... - Page 7 Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
-
Page 8: What Is Agp
Introduction 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
SPECIFICATION 2.1. HARDWARE Pentium 242 pins 66MHz slot1 on board. 66 MHz system speed. SPEED 66 MHz AGP bus speed. (133MHz 2X mode) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 2 banks 168 pins DIMM module sockets on board. DRAM MEMORY Use 8 / 16 / 32 / 64 / 128 / 256 MB 50~60 ns DIMM module DRAM. -
Page 10: Software
Suspend mode support. GREEN FUNCTION Green switch & ACPI LED support. IDE & Display power down support. Monitors all IRQ / DMA / Display / I/O events. BIOS 2M bits FLASH RAM. Supports Plug & Play, DMI Function. DIMENSION Baby AT Form Factor, 4 layers PCB. 2.2. -
Page 11: Hardware Installation
HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6EA main board. The Retention Mechanism & Attach Mount USER'S MANUAL for main board. Cable set for IDE, Floppy & I/O devices. CD for main board Utility. (Bus Master IDE Driver, Suspend to HD Utility, LDCM, SIV, Patch 95) The main board contains sensitive electric components, which can be easily damaged by static electricity, so the main board should be left in its original... -
Page 12: Mainboard Layout
3.2. MAINBOARD LAYOUT BIOS PIIX4E BAT1 WAKE LANE SB-LINK BANK 1 BANK 0 FLOPPY ATX POWER POWER ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE1 For Primary IDE port. IDE2 For Secondary IDE port. For Keyboard port. - Page 13 IR : INFRARED Connector (IR) -- Function Option Pin No. IR Data Output IR Data Input Signal POWER (+) PWR : POWER ON LED ( PW-LED) Pin No. Function LED POWER (+) LED POWER (-) LED POWER (-) SPK : SPEAKER Connector Pin No.
- Page 14 Soft PWR : Soft Power Switch Pin No. Function CTRL-Signal FAN PWR : CPU cooling FAN Power Connector Pin No. Function GND. +12V SENSE J10 : System After Ac Back Pin No. Function 1-2 Open Soft Off. 1-2 Close Full On. JP1 : Keyboard Power On Selection Pin No.
-
Page 15: Dram Installation
3.4. DRAM INSTALLATION The main board can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO & 67MHz for SDRAM when system bus speed is set to 66MHz. -
Page 16: Main Clock
DIP SWITCH (SW) FREQ. RATIO MAIN CLOCK 66MHz 75MHz 83MHz The CPU is a sensitive electric component and it can be easily damaged by static electricity, so users must keep it away from metal surface when the CPU is installed onto main board. 3.6. -
Page 17: Speaker Connector Installation
3.7. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPK is used to connect speaker. 3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION The RESET switch on panel provides users with HARDWARE RESET function. The system will do a cold start after the RESET switch is pushed and released by user.
