Yamaha MG06X Technical Specifications

MIXING CONSOLE

Technical Specifications

General Specifications

0 dBu = 0.775 Vrms Output impedance of signal generator (Rs) = 150 Ω
All level knobs are nominal if not specified.
Frequency Response Input to STEREO OUT
Total Harmonic Distortion
Input to STEREO OUT
(THD+N)
Equivalent Input Noise
Hum&Noise *1
(20 Hz to 20 kHz)
Residual Output Noise
Crosstalk (1 kHz) *2
Input Channels
Ouput Channels
Bus
PAD
HPF
EQ HIGH
Mono Input Channel Function
EQ LOW
PEAK LED
Post STEREO LEVEL
Level Meter
Knob
Internal Digital Effect (MG06X) SPX Algorithm
Phantom Power Voltage
Power Supply Adaptor
Power Consumption
Dimensions (W×H×D)
Net Weight
Optional Accessory
Included Accessory
Operating Temperature
*1 Noise is measured with A-weighting filter. *2 Crosstalk is measured with 1 kHz band pass filter.
ZG97350
+0.5 dB/-0.5 dB (20 Hz to 20 kHz),
refer to the nominal output level @ 1 kHz, GAIN knob: Min
0.01 % @ +8 dBu (20 Hz to 20 kHz), GAIN knob: Min
0.003 % @ +18 dBu (1 kHz), GAIN knob: Min
-128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)
-102 dBu (STEREO OUT, STEREO LEVEL knob: Min)
-88 dB
6 channels: Mono (MIC/LINE): 2, Stereo (LINE): 2
STEREO OUT: 2, PHONES: 1
STEREO: 1
26 dB
80 Hz, 12 dB/oct
Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving
Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
LED turns on when post EQ signal reaches 3 dB below clipping
(+11 dBu)
2 x 7-segment LED meter [PEAK (+11), +6, +3, 0, -3, -10, -20 dB]
6 programs
+48 V
PA-130 (DC12 V/1.0 A, Cable length = 1.8 m), 120 V, 60 Hz, or
MU18 (DC12 V/1.5 A, Cable length = 1.5 m), 100 V-240 V, 50 Hz/60 Hz,
or an equivalent recommended by Yamaha
12 W
149 mm×62 mm×202 mm (5.9"x 2.4"x 7.9")
0.9 kg (2.0 lbs)
Mic Stand Adaptor: BMS-10A
AC power adaptor, Owner's Manual, Technical Specifications (this leaflet)
0 to +40°C

Analog Input Characteristics

Actual
PAD GAIN
Input Jacks Load
26 dB Trim
Impedance
+64 dB
OFF
+20 dB
MIC/LINE 1/L,2/R 3 kΩ
+38 dB
ON
-6 dB
LINE 3/4, 5/6 - - 10 kΩ

Analog Output Characteristics

Actual Source For Use With
Output Jacks
Impedance Nominal
STEREO OUT L, R 75 Ω 10 kΩ Lines
PHONES 33 Ω 40 Ω Lines
0dBu is referenced to 0.775Vrms.
*1 Sensitivity is the lowest level that will produce an output of +4 dBu (1.228 V) or the nominal output level when the unit is set to maximum gain. (All level knobs are at
their maximum position.)
*2 1&Sleeve = Ground, 2&Tip = Hot, 3&Ring = Cold
*3 Tip = Signal, Sleeve = Ground
*4 1 = Ground, 2 = Hot, 3 = Cold
*5 Tip = Hot, Ring = Cold, Sleeve = Ground
Dimensions
The illustration shows the MG06X.
Unit: mm
62
2
149
30
Input level
For Use
With
Max. before
Sensitivity *1 Nominal
Nominal
clip
-72 dBu -60 dBu -46 dBu
(0.195 mV) (0.775 mV) (3.884 mV)
-28 dBu -16 dBu -2 dBu
(30.85 mV) (122.8 mV) (615.6 mV)
50-600 Ω
Mics/Lines
-46 dBu -34 dBu -20 dBu
(3.884 mV) (15.46 mV) (77.50 mV)
-2 dBu +10 dBu +24 dBu
(615.6 mV) (2.451 V) (12.28 V)
-22 dBu -10 dBu +4 dBu
600 Ω Lines
(61.56 mV) (245.1 mV) (1.228 V)
Output level
Nominal Max. before clip
+4 dBu +18 dBu
(1.228 V) (6.156 V)
2.4 mW + 2.4 mW 24 mW + 24 mW
* Specifications and descriptions in this document are for information pur-
poses only. Yamaha Corp. reserves the right to change or modify products
or specifications at any time without prior notice. Since specifications,
equipment or options may not be the same in every locale, please check
with your Yamaha dealer.
See reverse side for block and level diagrams.
Connector
Combo jack*2
(Balanced)
Phone jack*3
(Unbalanced)
Connector
XLR-3-32 *4
Phone jack *5
(Balanced)
Stereo phone jack
