Installation & Operation Manual
DVW-KBD-D Universal Keyboard
CONTENTS
Section Page
Connecting the Keyboard .............................................. ............. 2
Switch settings .............................................................................. 3
Programming and operation.........................................................5
Keyboard functions........................................................................6
Scanning functions.........................................................................8
Programming limit stops...............................................................8
Specifications................................................................................. 9
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVW-KBD-D and is the answer not in the manual?

Questions and answers

Summary of Contents for SAY Security Group DVW-KBD-D

  • Page 1: Table Of Contents

    Installation & Operation Manual DVW-KBD-D Universal Keyboard CONTENTS Section Page Connecting the Keyboard ............2 Switch settings ................3 Programming and operation............5 Keyboard functions................6 Scanning functions.................8 Programming limit stops...............8 Specifications................. 9 - 1 -...

  • Page 2: Connecting The Keyboard

    INSTALLATION The keyboard is wired directly to a maximum of 16 receivers. You can communicate using Pelco P Protocol or Pelco D Protocol. In Direct P and Direct D modes you can now change the zoom speed of a PTZ by entering a number from 1 to 4 followed by a zoom command. This causes the zoom speed command to be sent.

  • Page 3: Switch Settings

    Settings section. 8. Plug in the keyboard data cable. 9. Plug the DVW-KBD-D transformer into a suitable outlet. The LED display shows number 1, which is the default camera number. 10. Go to the Programming and Operation section and program and test for...
  • Page 4 the local keyboard. To make programming easier, address keyboards in ascending order Table A. Keyboard Addresses Keyboard Switch settings Mode (Switches 5, 7, 8) Position the switches according to Table B. Switch 6 enables/disables turbo pan. It can be switched while the keyboard is on.

  • Page 5: Programming And Operation

    PROGRAMMING AND OPERATION Table C. Keyboard Functions Function Procedure Select Camera Enter camera number (1-16) and press CAM to select. Pan/Tilt/Zoom Move the joystick until the camera reaches the desired position. To increase the speed of movement, move the joystick further from center. Twist the joystick clock wise to zoom in, counterclockwise to zoom out.

  • Page 6: Keyboard Functions

    KEYBOARD FUNCTIONS Table D. DVW-KBD-D Button Functions Reference Description Number LED display Shift key Shift key LED Sequence keys: Previous, Next, Hold Function keys F1/Latch, F2/Off, F3/Mom control auxiliaries. With Shift on they control multiplexer display. The AUX ON and AUX OFF keys control receiver auxiliaries.
  • Page 7 Pattern key Joystick Focus and iris keys (iris keys can be used to scroll through menus on the CM6800 only) Camera selection key Keypad (numbers 1 through 0) Acknowledge key Operation of the scanning functions depends on the kind of receiver or pan/tilt mechanism you have and the operating mode of your keyboard, There are four types of scanning functions: auto (moves camera back and forth between stops), random (moves camera in a random pattern), frame...

  • Page 8: Scanning Functions

    SCANNING FUNCTONS Table E Operating scan Functions with Various Receivers AUTO SCAN RANDOM SCAN FRAME SCAN STOP SCAN 99 preset 97 preset 98 preset 96 preset Programming Limit Stops Spectra and Esprit can be programmed for scan and manual limit stops. Program left limit before programming right limit.

  • Page 9: Specifications

    SPECIFICATIONS GENERAL Keyboard Keypad: Electromechanical Joystick: 3-axis, vector-solving, with twisting, return-to-center head Digital Display: Red LED, 7-segment, 2 cells Shift Mode Indicator: Green LED Ambient Operating Temperature: 20 to 120 F (-7 to 49 C) Humidity: 10–90% non-condensing Dimensions: 9.50(W) x 7.125(D) x 2.25(H) inches (24.13 x 18.1 x 5.72cm) Weight: 2.5 lb (1.12 kg) Ratings: Meets NEMA Type 1 standards Meets IP 30 standards...
