Summary of Contents for Air Live MU-7000AV
- Page 1 MU-7000AV 3.5" Network Multimedia Player User’s Manual...
-
Page 2: Declaration Of Conformity
Declaration of Conformity We, Manufacturer/Importer OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product 3.5" Network Multimedia Player MU-7000AV is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive... - Page 3 [Portuguese] disposições da Directiva 1999/5/CE. aplicables o exigibles de la Directiva 1999/5/CE. ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ OvisLink Corp izjavlja, da je ta MU-7000AV v skladu Ελληνική [Greek] ΟΤΙ MU-7000AV ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ Slovensko z bistvenimi zahtevami in ostalimi relevantnimi ΟΥΣΙΩΔΕΙΣ...
- Page 4 Consult the dealer or an experienced radio/TV technician for help. TRADEMARKS MS-DOS, Windows, Windows 95/98/NT/2000/me/XP are trademarks of Microsoft Corporation. Macintosh and Mac are trademarks of Apple Computer *All of the third-party brands and names are the property of their respective owners. AirLive Mu-7000AV User’s Manual...
-
Page 5: Table Of Contents
Table of Contents 1. Before You Get Started ......................1 1.1 Safety Instructions......................1 1.2 Preliminary Tools ......................1 1.3 Take a look to the MU-7000AV ..................1 2. Easy Installation Guide ......................2 2.1 Package Contents ......................2 2.2 Specifications........................ 2 2.3 Supported Hard Disk Formats .................. - Page 6 6.7 Formatting NDAS Device.................... 27 6.7.1 Initialize NDAS Device ..................27 6.7.2 Partition NDAS Device ..................27 6.7.3 Format NDAS Device Through My Computer..........27 6.8 Uninstall ........................28 6.9 Use NDAS Device in Linux ..................28 7. FAQ............................29 AirLive Mu-7000AV User’s Manual...
-
Page 7: Before You Get Started
6. Do not clean the device with alcohol, thinner or benzene. 1.2 Preliminary Tools To install Hard Drive into your MU-7000AV, you need a cross screwdriver for following procedures. 1.3 Take a look at the MU-7000AV: AirLive Mu-7000AV User’s Manual... -
Page 8: Easy Installation Guide
128 MB RAM (256 MB recommended) USB 1.1 Port (USB 2.0 recommended) CD-ROM drive for installation 100Base-T full duplex switch for NDAS mode (for Lan Share Only) 2.5 Supported Media Playback Formats Video：MPEG1（VCD、SVCD、DAT）、 MPEG2（AVI、VOB）、MPEG4（AVI、DivX、XviD） Subtitle：ass、psb、smi、ssa、srt、sub-txt Music：MP3 Photo：JPEG AirLive Mu-7000AV User’s Manual... -
Page 9: Hardware Installation
2. Setup the folder or partition you want to copy, and push the button. The OTB function will start automatically. Note： If you plug the MU-7000AV into computer with USB, media file playback and NDAS will not work. AirLive MU-7000AV User’s Manual... -
Page 10: Media File Playback Mode
3. Using MU-7000AV 3.2 Media File Playback Mode Please connect the Audio and Video cables between MU-7000AV and TV as shown in the figure below. Please plug in the power adaptor and power on your TV. Please change your TV mode to AV mode. -
Page 11: Lan Share Device Setup Overview ( Ndas Mode )
3.4 Switching between TV Mode and NDAS mode Push the “Power” button on the MU-7000AV or the remote control, then the LED will light up between “MP4” and “NET HDD“. When the “MP4” LED is on, Media File Playback mode is active. When the “NET HDD”... -
Page 12: Remote Control Features
FILE FILE Mode. MAIN Go to the main menu. MENU SETUP Setup and customize the settings of MU-7000AV. INFO See the information of the file. Fast reverse in Music or Video. PAUSE Interrupts file playback. Fast forward in Music or Video. - Page 13 Direction button to move cursor on the screen. LEFT Direction button to move cursor on the screen. RIGHT Direction button to move cursor on the screen. MAIN Takes you to the main menu. MENU POWER Power switch AirLive MU-7000AV User’s Manual...
-
Page 14: Starting Quick Media Play
You can press arrow keys to move picture. The screen will be shown as below. Zoom Off Zoom In × 1 Zoom In × 3 ROTATE SIDPLAY You can press ’ROTATE’ button on the remote control to rotate the picture in clockwise direction. AirLive Mu-7000AV User’s Manual... - Page 15 This item can setup interval time between every picture Press ’▲’ or ’▼’ button on the remote control to select slideshow interval time TRANSITION This item can setup transition between every picture, there are fourteen items let you to choose. AirLive MU-7000AV User’s Manual...
-
Page 16: Music Play Mode
This item allows you to play your video files without going to MAIN MENU Press ’▲’ or ’▼’ button on the remote control to select your play mode. ON：Video file will play automatically when you power on MU-7000AV. OFF：You must play video file manually. -
Page 17: Video Play Mode
● Stop playback, press the button ’STOP’ on your remote control. ● To move to previous video file, press the button ’PREVIOUS’ or ’REV’ on your remote control. ● To move to next video file, press the button ’NEXT’ or ’FWD’ on your remote control. AirLive MU-7000AV User’s Manual... -
Page 18: File Library
Notes：If you turn on this item, you can see the icon at your TV upper left corner when you execute REV or FWD function. SETUP VALUES：Setup VALUES in default mode. Notes：If you execute this item, all setup values will return to default values. AirLive Mu-7000AV User’s Manual... -
Page 19: Network Hard Disk ( Ndas Mode )
3. Select I accept the terms in the license agreement, then click Next. 4. Click Install. 5. Put in the Windows 98SE CD, click OK. 6. Select Yes, I want to restart my computer now then click Finish restart the computer. AirLive MU-7000AV User’s Manual... -
Page 20: Ndas Administrator
7. If this is your first time installing LAN Share, Add New Hardware Wizard will appear. Click Next and follow further instructions. Otherwise, MU-7000AV will be listed as a local drive on My Computer. Driver letter and name may vary between Personal Computers. -
Page 21: Add / Register A New Ndas Device Without Using The Registration Wizard
1. After you have registered, the Found New Hardware Wizard may appear. If the window appears, click Next to install the new NDAS Device. It should automatically find the appropriate drivers for your NDAS Device. Note: For Windows 2000, Upgrade Device Driver Wizard will appear instead. AirLive MU-7000AV User’s Manual... -
Page 22: Sharing Ndas Device
7. At any time, any Windows ME、Windows 98SE and Mac OS system want to mount NDAS Device under Read/Write Mode, others computers must mount NDAS Device under Read Only Mode, they can’t mount NDAS Device under Read/Write Mode alone or at the same time. AirLive Mu-7000AV User’s Manual... -
Page 23: Introduction To Ndas Device Management
Click the NDAS Device Management located on the system tray. All registered NDAS Device(s) will be displayed on the NDAS Device Management Menu. 1. When you click on the icon - Lists all NDAS Devices that are registered. AirLive MU-7000AV User’s Manual... -
Page 24: Ndas Device Functions
Unmount - Enables users to change NDAS Device mode to Connected Mode. Properties - Displays properties of the NDAS Device. C. NDAS Device in Disconnected Mode Disconnected - The current state of NDAS Device. Unregister - Enables users to un-register NDAS Device. AirLive Mu-7000AV User’s Manual... -
Page 25: Changing From Read/Write Mode To Read-Only Mode
6.3.3 Changing from Read Mode to Read/Write Mode 1. Click NDAS Device Management and select the NDAS Device you want to change from Read-Only to Read/Write. 2. Select Unmount 3. A warning message will appear. Click Yes. AirLive MU-7000AV User’s Manual... -
Page 26: Use With Lan Share Mode In Mac Os X
Enable RO - Enable NDAS Device into Read Only Mode. Quit - End NDAS Device Admin. NDAS Device IDs Window Displays all the NDAS Device that are registered in the computer. Configuration Window Displays NDAS Device status user wants to achieve for that Lan Share. AirLive Mu-7000AV User’s Manual... -
Page 27: Using Ndas Device
- Once both Configuration and Status displays Read / Write, NDAS Device is in Read / Write Mode. 6.4.5 Uninstall NDAS 1. Start the Uninstaller by double clicking NDAS Uninstaller. 2. Authenticate Enter Admin Name and Password. Then click OK. 3. Click Uninstall. 4. NDAS has been successfully uninstalled. Click Quit. AirLive MU-7000AV User’s Manual... -
Page 28: Ndas Bind Management
- Aggregation can bind any number of units between 2 and 8. - RAID0 can bind 2, 4 or 8 units. - RAID1 can bind 2, 4, 6 or 8 units. Note : Currently RAID4 is not supported. AirLive Mu-7000AV User’s Manual... -
Page 29: Unbind
Make sure that no programs are using the NDAS Device and try again. 3. After you have unmounted the NDAS Devices, go to NDAS Bind Management. 4. From the NDAS Bind Management, select the Bound NDAS Device you have just unmounted. Click the Unbind button AirLive MU-7000AV User’s Manual... - Page 30 Bound device. You will have to recreate the Bind and format it again. 6. For formation of the NDAS Device, please refer to Chapter 9 Formatting NDAS Device. 7. When you are finished formatting, your NDAS Device should show up in My Computer as a local drive. AirLive Mu-7000AV User’s Manual...
-
Page 31: Other Ndas Bind Management Functions
You can add a NDAS device to RAID 1 as spare disk so that the NDAS device is replaced automatically when any disk in RAID goes missing or out of order. 1. Right click on your Mirror then select Add Spare Disk. AirLive MU-7000AV User’s Manual... -
Page 32: Remove Spare Disk
3.11 as well. Once the user with 3.11 migrates the Mirrored NDAS device’s binding information, other users sharing the Mirrored NDAS device will no longer have access to the Mirrored NDAS devices if they are still running older versions of NDAS Device software. Here are some notes： AirLive Mu-7000AV User’s Manual... -
Page 33: Formatting Ndas Device
Check the box that says Quick Format (Recommended) 4. A Warning will appear asking if you are sure you want to format the drive. Click on OK. 5. Click on OK once the format has completed. AirLive MU-7000AV User’s Manual... -
Page 34: Uninstall
NOTE：A warning window may appear if any of the NDAS Device is still in mounted state. Click Cancel and unmount the NDAS Devices. 3. Restart the PC once uninstall is finished. 6.9 Use NDAS Device in Linux Please go to below web site to download driver and user menu. http://www.ximeta.com/web/support/download/linux/index.php AirLive Mu-7000AV User’s Manual... -
Page 35: Faq
Media File Playback 1. I can see files when connected with the computer but can't see them on the TV？ A：MU-7000AV can only recognize FAT32 partitions. If the hard drive is partitioned using NTFS, No files can be displayed on the TV. - Page 36 2. I have just installed NDAS, why does NDAS show up as a red color？ Try turning off your MU-7000AV power cord, wait about 10 seconds, and turn it on. If this doesn't work, try restarting your computer as well.
