- Page 1 Motorcycle Tire 8155236 Changer Attachment OWNER'S MANUAL Read and understand all instructions before use. Retain this manual for future reference.
-
Page 2: Specifications
8155236 Motorcycle Tire Changer Attachment Specifications Tire Rim Capacity: 22" Max. / 9" Min. Mounting Hole Diameter: 1.70" Center Post bar Diameters: 1/2" & 5/8" Overall Dimensions: 27" x 23" x 28 - 1/2" Features • Will handle tire rims up to 22" diameter •... - Page 3 Assembly Use the Parts Diagram as a guide to aid in assembly and operation. This tool must be used with the tire changer. References to the tire changer or its parts will be made in italic type. Secure the upper crossbeam (2) to the centre post (1) with the knob. Bolt the upright post (3) to both the upper crossbeam and the adjustable support tube (8).
- Page 4 8155236 Description Description Centre post Triangle frame Upper crossbeam Knob Upright post Bolt M10x25 Wheel clamp Bolt M10x60 Support tube Nut M10 Lock pin Adjustable Wheel clamp Cotter pin Handle Adjustable support tube For any technical questions, please call 1-800-665-8685...
