MODEL ACC1600
ACCESSORY SUNSHADE HOUSING
SUNSHADE HOUSING
SPACER (TO USE WITH XX CAMERAS)
FEATURES
camera from weather elements
1. Protects
2. Can be used with any LOREX / SYLVANIA Observation System Cameras
and most other security cameras
Ideal for use under an eves trough or over hang
3.
4. Durable plastic construction
PARTS AND IDENTIFICATION
Sunshade Housing - Back View
Sunshade Housing - Rear View
METAL STAND (INCLUDED WITH CAMERA)
SCREW
WASHER
THIS PACKAGE CONTAINS:
1 – Accessory Sunshade Housing
1 - Spacer
1 - Washer
1 - Mounting Screw
1 – Owners Manual
1 – Warranty Card
Cable Outlet
Bracket
Mounting Hole
Camera Mounting
Hole
Advertisement
Table of Contents
Summary of Contents for Strategic Victa ACC1600
- Page 1 MODEL ACC1600 ACCESSORY SUNSHADE HOUSING THIS PACKAGE CONTAINS: 1 – Accessory Sunshade Housing 1 - Spacer 1 - Washer 1 - Mounting Screw 1 – Owners Manual 1 – Warranty Card SUNSHADE HOUSING METAL STAND (INCLUDED WITH CAMERA) SCREW WASHER...
- Page 2 INSTALLATION WITH LOREX / SYLVANIA OBSERVATION SYSTEM CAMERAS 1. Insert camera cable through the cable outlet of the sunshade housing and attach the camera cable to the 6 DIN input located at back of the camera. 2. Hold the sunshade housing facing you and slide the camera between the side groves into the housing. While holding the camera from inside the housing, reverse the housing and use the supplied mounting screw and washer to attach the camera to the housing through the camera mounting hole.
