Gianni Industries Micro Surface Specification

Features
Stainless steel casing
MOV provides spike and surge protection
Anti-residual magnetism function
Statement
The 10003S is recommended to be installed on
small doors, drawers and cabinets etc. With
stainless steel housing, it is suitable for outdoor
applications and severe weather conditions.
Specification
Operating Voltage: Single Voltage: 12 or 24VDC
Current Draw:
Single Voltage: 300mA/12VDC, 260mA/24VDC
(at temperature 20ºC)
Operating temperature:-10~55ºC(14~131ºF)
Humidity: 0~95% non-condensing.
Holding force: Up to 300 lbs (136 Kg )
Dimensions:
Magnet:(L) 170, (W) 32, (D) 24 mm
Armature plate:(L) 152, (W) 32, (D) 10 mm
Zinc plated finish for magnet and armature plate
Epoxy potting compound: E87252 (S), UL94V-0
Net Weight: 1.5 Kg
Warranty
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original client. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-10003S Ver. F Published on 2011.08.24
10003S Micro Magnetic Lock
Surface Mount and Waterproof
Standard Installation
Suitable for server cabinet
Magnet
Armature
(Power On)
Anti-residual statement
Our electromagnet locks feature Anti-Residual Magnetism
(ARM) which ensures the door can be opened without any
resistance from left over magnetism imparted to the armature
plate
GIANNI INDUSTRIES , INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
Magnet
Armature
(Power Off)
