Location Icons
InVion
Model: GPS-3V506-IUS
The red GPS receiver means that a reliable GPS
signal is not yet located.
The green GPS receiver means that a reliable GPS
signal is located and that you are ready to navigate.
These icons display your power source. The battery
appears as green, yellow, or red depending on the
strength of the battery charge.
Tap this icon to set your QuickNav location. When
set, you can tap this button to automatically calculate
a route to this location.
Tap this icon to display the main menu.
Current location in Vehicle Mode or Walking Mode.
Last known location when GPS signal is unreliable.
Generated route.
The GPS bar is a toggle
button that displays the re-
maining travel distance and
travel time, estimated time
of arrival, street name and
address number, speed
and altitude.
