GEM GL-1800F-IOTB Specification Sheet

Magnet Armature
(Power Off)
(Power On)
Anti-residual Magnetism
Our electromagnetic locks feature Anti-Residual Magnetism
(ARM) which ensures the door can be opened without any
resistance from leftover magnetism imparted to the armature
plate.
Features
High reliability
Dual voltage 12 or 24 VDC (selectable)
MOV provides spike and surge protection
Anti-Residual magnetism function
Holding force up to 1800 lbs
Mostly suit for prison or high security gate
Statement
GL-1800F-IOTB is designed for face mount on
sliding doors. With stainless steel housing, it is
suitable for outdoor applications and severe
weather conditions. 1800 lb holding force meets
the needs for high security.
Specification
Operating voltage: 12/24 VDC
Current draw: 500mA/12VDC; 250mA/24VDC
(at temperature 20ºC)
Operating temperature: -10~55ºC(14~131ºF)
Humidity: 0~95% non-condensing.
Holding force: Up to 1800 lbs(818 Kg)
Dimensions:
Magnet:(L) 284, (W) 71, (D) 46 mm
Armature plate:(L) 250, (W) 70, (D) 16 mm
Special finishes for magnet and armature plate: Zinc plated
Epoxy potting compound : E87252 (S), UL94V-0
Net Weight : 8.0 Kg
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-GL-1800F-IOTB Ver. D Published on 2011.08.30
Magnet
Armature
GL-1800F-IOTB
Wa terProof Electromagnetic Lock
Regular Installation
e
a m
F r
This series of Waterproof Magnetic Lock is
potting compound. Also, GEM Waterproof Series Magnetic
Locks have been proved to withstand water with the test
procedures of IPX7, IPX8 by a trusted third party. Therefore
users need not worry that the lock will rust or spark, if the lock
is in outdoor applications and installed in confined space
where inflammable gases are stored.
Warranty
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
S l
i d
i n
g D
o o
r
protected by epoxy
