- Page 1 Anti-Mode 8033Cinema User's Manual Revision History Rev. Date Author Affected Description chapters 2007-11-30 TK & ToLi Original version Finnish and English for 8033B 2012-02-15 Updated for Anti-Mode 8033Cinema and 8033S-II 2012-03-18 Typo and language corrections...
- Page 2 8033C INEMA Recycling information The product you have purchased is marked according to the Waste Electrical and Electronic Equipment Directive (WEEE Directive). There are take-back systems in place that help to preserve nature and natural resources when products are disposed of appropriately. If you need to dispose of this product, use the take-back system that has dedicated collection facilities for electronic equipment.
-
Page 3: Table Of Contents
8033C INEMA Table of contents 1. Connections and Buttons..................4 1.1. Front panel:......................4 1.2. Back Panel......................4 2. Quick Setup Guide....................5 2.1. Before Calibration....................5 2.2. Calibration......................6 2.3. After Calibration....................6 2.4. Subwoofer Placement..................7 2.5. Cross-Over Frequency..................7 2.6. Multiple Subwoofers...................7 3. Wider Area Correction....................8 3.1. -
Page 4: Connections And Buttons
(please reduce input level). • 1.2. Back Panel Figure 2: ANTI-MODE 8033Cinema rear panel 1. 9 VAC / 12 VDC connector: Input power. 2. LINE OUT / RCA connector: To subwoofer 3. LINE IN / RCA connector: LFE (Low-Frequency-Effects) or SUB (subwoofer) signal from the pre-amplifier or AVR (Audio/Video Receiver). -
Page 5: Quick Setup Guide
8033C INEMA 2. Quick Setup Guide 1. Please read the rest of the manual to get the most out of your system and the Anti-Mode 8033. 2. Connect the subwoofer signal to "LINE IN" 3. Connect the active subwoofer to “LINE OUT” output. 4. -
Page 6: Calibration
8033C INEMA 2.2. Calibration Press both the LIFT and BYPASS buttons on the front panel and hold them down to start the calibration process. Make sure that both of the buttons are pressed down at the same time. After a couple of seconds the LIFT25 LED starts flashing and calibration begins. Now release the buttons and wait for the automatic calibration to finish. -
Page 7: Subwoofer Placement
8033C INEMA Important! If only one sweep signal was generated during the calibration, one of the following situations occurred: the microphone was not properly connected, the calibration signal was not detected, or the calibration was aborted. If only two sweeps were generated, perhaps both buttons on the front panel were not pressed. -
Page 8: Wider Area Correction
8033C INEMA 3. Wider Area Correction In some situations it is more favorable to compensate for room acoustics in a wider listening area. When this is done, the result is no longer optimal in any single listening position but is improved for a wider listening area. -
Page 9: Basic Operation
8033C INEMA 4. Basic operation 4.1. Bypass mode If you want to compare the corrected and uncorrected operation, press the BYPASS button quickly. This will switch between bypass and normal mode. The first press will put the Anti-Mode into bypass mode, which is also indicated by the BYPASS LED being lit. -
Page 10: Input Level Warning
4.5. Powering Up and Down The Anti-Mode 8033Cinema has almost no power-on and power-off transients, so you can easily power it on and off using a switchable power cord or the switchable power output from your AVR. -
Page 11: Connection Examples
AVR / pre-amplifier and the subwoofer using line-level connections. The Anti-Mode 8033Cinema can be used when connecting into a 2.1 stereo system which has only stereo pre-outs available (no dedicated LFE or sub output), but it requires an additional stereo to mono converter cable. -
Page 12: Technical Specifications
32 / 40-bit integer Latency: 2.7 ms Anti-Mode-Filters: Correction range: 16 – 160 Hz Lift filters: 20Hz, 30Hz 8. Manufacturer VLSI Solution / DSPeaker Division Hermiankatu 8 B FIN-33720 Tampere FINLAND Fax: +358-3-3140-8288 Tel: +358-3-3140-8200 Email: info@dspeaker.com 9. Contact Website: http://www.dspeaker.com/...
