- Page 1 USER MANUAL ATSC CONVERTER BOX CHANNEL AT2016 AT2016 Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
-
Page 2: Table Of Contents
1.1.2 Using the remote control ..............6 1.2 Front Panel and Rear Panel Illustration ..........7 1.2.1 Front Panel..................7 1.2.2 Rear Panel ..................7 1.3 Connecting your Atsc Converter Box............ 8 1.3.1 Connecting Antennas...............8 1.3.2 Connecting to a TV Set..............9 1.3.3 Connecting to an Audio System............10 2.On-Screen Menus................11... -
Page 3: Important Safety Instructions
Important Safety Instructions 1. The apparatus shall not be exposed to dripping or Splashing and that no objects filled with liquids, such as Vases, shall be placed the apparatus. 2. The mains plug is used as the disconnect device, the disconnect device shall remain readily operable. 3. - Page 4 1. Read these Instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. Clean only with dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
- Page 5 Note: 1. Important safety instructions shall be provide will each appliance. These safety instructions may be in the form of a separate booklet, separate sheet, or part of the instruction manual. 2. If included in the instruction manual, the safety instructions shall be located before any operating instructions.
-
Page 6: Introduction
DTV is broadcast from transmitters and received via a rooftop aerial. It works like traditional TV, but because the signals are Digital you need an Atsc Converter Box to convert them. There are three ways to watch DTV: an external DTV Atsc... -
Page 7: Remote Control
12. AUDIO: Press to select the available multi-tracks. (Depending on the particular broadcast, one or more foreign language translations might be available.) 13. STANDBY: Press to switch the Atsc Converter Box to on and off. 14. VOL+: Press to increase the output volume level. -
Page 8: Installing The Batteries
2.Install batteries 3.Close the cover 1.1.2 Using the Remote Control To use the remote control, point it towards the front of the digital Atsc Converter Box. The remote control has a range of up to 7 metres from the Atsc Converter at an angle of up to 60 degrees. -
Page 9: Front Panel And Rear Panel Illustration
POWER BUTTON: Used to turn on or off of the main power of the unit. REMOTE CONTROL SENSOR: Used to receive the signal from the remote control. STANDBY INDICATOR: Used to visually show power state of the Atsc Converter Box the red LED will be light if the Atsc Converter Box entered standby mode. -
Page 10: Connecting Your Atsc Converter Box
B.The Atsc Converter Box can receive DTV signals in the event that a local cable provider is passing 8VSB through on their system. (8VSB is the RF modulation format utilized by the DTV(ATSC) digital television standard to transmit digital bits over the airwaves to the home consumer.) -
Page 11: Connecting To A Tv Set
1.3.2 Connecting to a TV Set TV Aerial (For smart antenna only) ATSC NTSC VIDEO Video Out 100-240V~ RF IN RF OUT CH 3 CH 4 SERVICE 50/60Hz SMART ANT. I /F Audio Out Composite Video White Yellow VIDEO IN... -
Page 12: Connecting To An Audio System
1.3.3 Connecting to an Audio System ATSC NTSC VIDEO Video Out 100-240V~ RF IN RF OUT CH 3 CH 4 50/60Hz SERVICE SMART ANT. I /F Audio Out Amplifier VOLUME INPUT SELECTOR POWER BYPASS PRO LOGIC 3 STEREO MODE TEST... -
Page 13: On-Screen Menus
2. On-Screen Menus Ensure all connections have been made following the diagrams on the previous pages for reference. When you plug the power cord of this set-top box into a power outlet and press the POWER switch on the front panel, the box will be turn on for the first time. Press STANDBY button on the remote control will switch the set-top box to or from standby mode. -
Page 14: Manual Channel Set
You can specific the selected channel Viewable Not viewable , the not viewable channels will be skipped when you do zapping next time. Manual Channel Set Menu Ch 14-1 ATSC-1 Viewable Ch 14-2 ATSC-2 Viewable Ch 14-3... -
Page 15: Advanced Closed Caption
2),The TV Rating system include the following ratings: TV-Y(all children) and TV-Y7(directed to older children),TV-G (general audience), TV-PG(parental guidance suggested), TV-14(parents strongly cautioned), and TV-MA(mature audiences only). The letters FV(Fantasy Violence),V(moderate Violence), S (mild Sexual situations), L(mild coarse Language), D(mature themes suggestive Dialogue) were added to indicate the presence of violence, sex, language, suggestive dialogue respectively. -
Page 16: Language
2.6 Language When this item is highlighted, you can press OK button to change the OSD menu language as you want, there are 3 options: English, Spanish, French. 2.7 Auto Power Down Timer When this item is highlighted, press the OK button you can choose the options: Off, 2 hours, 4 hours. -
Page 17: Troubleshooting
3. Troubleshooting Q: It takes a while to display picture on the screen after turning power on or after changing channel. A: It will take several seconds for this receiver to show the logo or picture after power on sincee the system have to finished the initialization of the main chip and demodulator. -
Page 18: Specifications
Decoder Video Format: Standard definition CVBS. Audio Format: Dolby Digital audio R F Signal Input/Output ATSC Antenna/Cable RF In: F-Connector NTSC Ch3/4 RF out: F-Connector Antenna Impedance: 75 Ohms Channels: VHF 2 -13 , UHF 14 - 69 Smart Antenna interface... -
Page 19: Glossary
4:3 or 16:9 aspect ratios, and it includes surround sound. Variations of fps (frames per second), lines of resolution, and other factors of 480p and 480i make up the 12 SDTV formats in the ATSC standard. HDTV: "High-definition Television." This is the most superior video picture available in Digital TV.
