Summary of Contents for DB Drive E6BE
- Page 1 okur DIGITAL BASS OPTIMIZER...
- Page 2 E6BE SPECIFICATIONS & FEATURES • Parametric Bass Equalization • Variable Output Gain Control • Variable Center Frequency Control • Selectable Output Gain Limiter • Selectable Ground Isolation Switch • Remote Bass Control • 2 Channel Digital Bass Restoration • Selectable Sub-Sonic Filter •...
- Page 3 RCA OUTPUTS to your amplifier(s). It is important to note that the E6BE has a built in line driver capable of sending 9 volts of signal output to your amplifier(s). CENTER FREQUENCY: This control allows you to select the frequency you want the E6BE bass restoration circuit to enhance.
- Page 4 E6BE WIRING DIAGRAM CHASSIS GROUND GROUND ISOLATION GROUND TO BATTERY +12v VIA ISOLATED 200-OHMS 5 AMP FUSE REMOTE TURN-ON OUTPUT GAIN CONTROL CENTER FREQUENCY BASS REMOTE okur Digital Bass Optimizer FREQUENCY BANDWIDTH WIDE NARROW SUBSONIC FILTER RCA INPUT 20Hz BALANCED...
- Page 6 okur...
