High Output Flexible Strip Tape
Installation and Operation Manual
Overview
HO (High Output) Flexible LED Strip Tape is a linear array of high power
LEDs encased in a flexible, clear epoxy resin (interior version) or in a clear
silicone UV protected sleeve (exterior version). The thin diameter and
extremely low profile form factor allow these products to be installed in
areas too confined for traditional rope light products. A linear array of wide
angle SMD LEDs results in homogenous and even light distribution without
shadows or gaps. For mounting ease, the interior version is supplied with
3M double sided tape already installed on the product. The exterior version
is secured using flexible silicone clips. Each cut section comes with wire
leads so your LED Strip Tape is ready to connect to your DC power source.
HO Flexible LED Strip Tape may be cut to suit every 4" (12V version) or
every 6" (24V version).
Applications
Cove Lighting • Courtesy Lighting • Under Gunnels • Under Cabinets •
Stairs • Closets/Lockers • Architectural & Landscape

Specifications

Input Voltage
Input Power
Luminous Flux
Viewing Angle
Bulb Spacing
Cutability
Tape Dimensions (H x W)
Maximum Run
Ingress Protection
* IP65: "Protected from the ingress of dust and low pressure jets of water from all directions"
1 2
12V
1.90 watts per foot 2.44 watts per foot
46 lms per foot 59 lms per foot
151 lms per meter 194 lms per meter
140°
1.3' (330mm) 1.0" (25mm)
Every 4" (102mm) Every 6" (152mm)
3.52mm (0.14") x 10.20mm (0.40") – standard
5mm (0.20") x 14.20mm (0.56") - exterior
19.7' (6 meters) 31.5' (9.6 meters)
IP65
24V
