Owner's Manual
M11571GNEA
Instructions for Assembly, Testing, Operation,
Log Splitter: Outdoor hydraulic powered machine that
READ and UNDERSTAND this manual completely before using log splitter.
All operators of this equipment must read and completely understand all safety information, operating instructions,
maintenance and storage instructions. Failure to properly operate and maintain the log splitter could result in serious
injury to the operator or bystanders from moving parts that can crush or cut, flying objects, burns, fire or explosion,
escaping high pressure hydraulic fluid, or carbon monoxide poisoning. In particular, be aware of the following
hazards:
Moving parts can crush and cut hands and fingers. Keep hands clear of endplates, wedge, and logs while splitting.
High fluid pressures and temperatures are developed in hydraulic log splitters. Hydraulic fluid escaping through
even a pin-size hold opening can puncture skin and cause severe blood poisoning. Inspect hydraulic system
regularly for possible leaks. Never check for leaks with your hand while the system is pressurized. Seek medical
attention immediately if injured by escaping fluid.
If your log splitter is intended for use near any ignitable forest, brush, or grassy covered land, the engine exhaust
should be equipped with a spark arrestor.
Keep a fire extinguisher with you, rated for ordinary combustibles and flammable liquids.
ASSEMBLY REQUIRED: This product requires assembly before use. See "Assembly" section for instructions.
INSPECT COMPONENTS. Closely inspect upon receipt to make sure no components are missing or damaged. See
"Assembly" section for instructions on whom to contact to report missing or damaged parts.
ADD ENGINE OIL and HYDRAULIC OIL BEFORE USING: This product is shipped without engine oil or
hydraulic oil. DO NOT start log splitter before adding both oils. See "Assembly" and "Initial Unpacking & Set-
up" sections for detailed instructions.
Any Questions, Comments, Problems or Parts Orders
Servicing, & Storage
splits wood logs.
WARNING
Crush and Cut Hazards
High Pressure Hydraulic Fluid Hazards
Fire Hazards
STOP!
Call Product Support 1-866-443-2576
ITEM NUMBER: 11571GNE
_______________
SERIAL NUMBER:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M11571GNEA and is the answer not in the manual?

Questions and answers

Summary of Contents for Northern Tool + Equipment M11571GNEA

  • Page 1 Owner’s Manual ITEM NUMBER: 11571GNE M11571GNEA _______________ SERIAL NUMBER: Instructions for Assembly, Testing, Operation, Servicing, & Storage Log Splitter: Outdoor hydraulic powered machine that splits wood logs. WARNING READ and UNDERSTAND this manual completely before using log splitter. All operators of this equipment must read and completely understand all safety information, operating instructions, maintenance and storage instructions.
  • Page 2 Hazard Signal Word Definitions...
  • Page 3: Table Of Contents

    Table of Contents About Your Log Splitter......................4 Safety Label Locations ......................5 Machine Components Identification ..................6 Initial Set-up ..........................7 Moving & Towing to the Job Site .................... 9 Before Each Use: Step One: Inspection/Maintenance................. 11 Step Two: Fueling ......................13 Step Three: Work site Selection &...
  • Page 4: About Your Log Splitter

    About Your Log Splitter Thank you for purchasing your log splitter! About Your Log Splitter This log splitter is a machine designed to split wood logs using a hydraulically powered moving wedge. The gasoline-powered engine is used to pressurize the system. This log splitter model is capable of splitting logs up to 24”...
  • Page 5: Safety Label Locations

    Safety Label Location DANGER Log splitter exhaust contains carbon monoxide. This is a poison you cannot see or smell. NEVER use inside a home Only use OUTSIDE and IF LOG BECOMES STUCK ON WEDGE or garage. EVEN IF doors far away from windows, and windows are open.
  • Page 6: Machine Components Identification

    Machine Components Identification 1.) Log Table. This large log table keeps the log from falling on the ground after splitting. The log table will keep the log on the beam without operator assistance. 2.) Beam/Cylinder. The hydraulic cylinder has a 4” bore and a 24” stroke, depending on model. 3.) Wedge.
  • Page 7: Initial Set-Up

    Initial Set-up WARNING Carefully read and follow all instructions for initial assembly and set-up of this log splitter. Failure to properly assemble and set up this equipment could result in serious injury to the user or bystanders, or cause equipment damage. Step One: Assemble your log splitter.
  • Page 8 Initial Set-up • NEVER check for leaks with your hand. Leaks can be located by holding a piece of cardboard or wood (at least two feet long) with your hand at one end and passing the other end over the suspected area (wear eye protection). Look for discoloration of the cardboard or wood.
  • Page 9: Moving & Towing To The Job Site

    Moving & Towing to Job Site WARNING The log splitter is heavy. It can crush and cause serious injury if it rolls out of control or tips over. Follow the instructions below for safely moving and towing the log splitter. Moving the log splitter: 1.
  • Page 10 Moving & Towing to Job Site 3. Swing leg UP Lock the leg in the “UP” position before you move the log splitter anywhere by hand. Pin Catch Swing leg 4. Attach to hitch Attach Log Splitter to vehicle hitch. Unlocked Locking lever (2”...
  • Page 11: Step One: Inspection/Maintenance

    Before Each Use – Inspection / Maintenance Step One: Inspect and maintain log splitter before each use. If the log splitter has been used previously, it must be inspected and maintained BEFORE EACH SUBSEQUENT USE. WARNING ALWAYS shut off the engine, disconnect the spark plug, and relieve system pressure before inspecting, cleaning, adjusting, or repairing the splitter.
  • Page 12 Before Each Use – Inspection / Maintenance Do NOT operate the log splitter if there is any indication of damage or oily residue. Small leaks in hydraulic lines can cause severe injuries and can also be an indication of catastrophic failure in the near future. The life of hydraulic hoses may be from a few months to a few years, depending on use and storage patterns.
  • Page 13: Before Each Use

    Before Each Use – Fueling Step Two: Fueling WARNING Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Use extreme care when handling gasoline. 1. Engine off / cool The engine must be off and allowed to cool at least two minutes before adding fuel.
  • Page 14: Step Three: Work Site Selection & Set-Up

    Before Each Use – Work Site Selection & Set-Up Step Three: Work site selection and log splitter set-up WARNING It is important to select an appropriate work site and properly set up the log splitter in order to minimize the risk of slips and falls, equipment rolling or tipping over, carbon monoxide poisoning, and accidental fires.
  • Page 15: Splitting Operation

    Splitting Operation WARNING Before starting the log splitter, review the following instructions and safety information for safe operation. Failure to follow these rules may result in serious injury to the operator or bystanders from moving parts that crush, cut, or entangle; from flying objects, burns, fire, falling or tripping; or from carbon monoxide poisoning.
  • Page 16 Splitting Operation Wear the following protective clothing and safety gear. 1. Put on protective clothing / gear 1) Eye protection. Always wear safety glasses or goggles when operating the machine. Pieces of log may fly out and serious eye injury can occur 2) Boots.
  • Page 17 Splitting Operation FIG02218 Correct Incorrect Log Orientation Log Orientation WARNING: ALWAYS keep hands and feet away from the wedge and partially split logs while loading, operating and unloading the log splitter. Important safety instructions: • Hold bark side. Hold the bark side of logs when loading or positioning, never the ends.
  • Page 18 Splitting Operation Important safety instructions: • Operator position. ALWAYS operate the log splitter from the manufacturer’s indicated OPERATOR POSITION. (See diagram above.) Other positions are unsafe because they can increase the risk of injury from crushing, cutting, flying objects, or burns. •...
  • Page 19 Splitting Operation If a log does not split completely and becomes stuck on the wedge, follow the 7. Important instructions below to remove the log. STUCK LOG A log can become stuck to the wedge if the wedge becomes embedded in the log and the procedure log doesn’t split and separate.
  • Page 20: Storage

    Storage WARNING Gasoline vapors can ignite and cause a fire. Select a well-ventilated storage area away from sources of heat, flame, or sparks. Follow the instructions below for storing your log splitter between uses: 1. Retract cylinder Retract the wedge completely to the hitch end of the log splitter to keep the rod protected from corrosion.
  • Page 21: Periodic Maintenance

    Periodic Maintenance In addition to the maintenance performed with each use, periodic maintenance should also be performed according to the following schedule. WARNING ALWAYS shut off the engine, disconnect the spark plug, and relieve system pressure before cleaning, adjusting, or repairing the splitter. Relieve system pressure by moving Split Control Lever back and forth several times.
  • Page 22: Troubleshooting

    Troubleshooting WARNING Before troubleshooting or attempting to service, read the following safety instructions to avoid serious injury to the operator or bystanders from moving parts that can crush or cut, burns, fire or explosion, or escaping high pressure hydraulic fluid. Important Safety Instructions 1.
  • Page 23: Specifications

    Specifications Maximum Pressure ..… 3000 PSI Maximum Flow ....…... 11 GPM Hydraulic Fluid Capacity.… 3 Gallons Hydraulic Fluid Type……... 10 wt AW32, ASLE H-150, or ISO32 Coupler Size...………….… 2” Maximum Towing Speed.… 45 MPH Maximum Log Length ..24” Pressure Relief Setting ..… 3000 PSI Hydraulic Cylinder Bore .…...
  • Page 24: Parts Breakdown - Exploded View

    Parts Breakdown – Exploded View – Rev A...
  • Page 25 Parts Breakdown – Exploded View – Rev A Item Part Number Description 780234 Tip Bracket 4011 4” Suction Strainer 50NBR12 Hose Barb Elbow 17141 ¾” Hose Clamp 30289 ¾” PVC Hose 22” 783808 Hose Guide 782400 Grommet 777799 High Speed Tire 82140 Cotter Pin 777910...
  • Page 26: Summary Of Important Safety Information For Operation

    Summary of Important Safety Information for Operation WARNING Carefully read and make sure you understand the following safety information before using the log splitter. Improper use or maintenance of the log splitter can result in serious injury to the operator or bystanders from moving parts that can crush or cut, flying objects, escaping high pressure hydraulic fluid, or carbon monoxide poisoning.
  • Page 27 Summary of Important Safety Information for Operation Safety During Towing • Read instructions. Review towing safety instructions in your towing vehicle manual. • Securely attached. Be sure the log splitter is securely attached to the towing vehicle before towing. • Tires.
  • Page 28 Summary of Important Safety Information for Operation Therefore, the following instructions should be heeded at all times when inspecting or servicing the hydraulic components of the log splitter: o Do not remove the hydraulic oil fill cap when the engine is running. Hot oil can escape causing severe burns.
  • Page 29 Summary of Important Safety Information for Operation • Block wheels. Always block the wheels to prevent unintended movement of the log splitter. • Carbon monoxide. The running engine gives off carbon monoxide, a poisonous gas that can kill you. CANNOT smell it, see it, or taste it.
  • Page 30 Summary of Important Safety Information for Operation Loading/Unloading • Unsplit log pile. Do not pile logs to be split in a place that will make you reach across the log splitter in order to load them. • Hold bark side. Hold the bark side of logs when loading or positioning, never the ends. Never place your hands or any part of your body between a log and any part of the log splitter.
  • Page 31: Assembly Instructions

    Assembly Instructions Closely inspect all log splitter components and contents of manual bag (see diagrams). If you have missing components, contact Product Support at 1-866-443-2576. If you have damaged components, contact the Freight Company that delivered the unit and file a claim. CAUTION! Heavy lifting required.
  • Page 32 Assembly Instructions...
  • Page 33 Assembly Instructions 5/16” nut Step 1 Install Leg to Tow Leg Weldment using 5/16 x 2-3/4 Bolt and 5/16 Nyloc nut. Install Catch Pin through Hole in Tow Leg as shown. Tow leg weldment Catch pin 5/16” x 2-¾” bolt Step 2 3/8”...
  • Page 34 Assembly Instructions Step 4 Slide Tire onto Axle with Valve Stem facing High speed Tire axle Thread Axle Nut onto Axle (hand tight) Back Axle Nut off ¼ turn Make sure Tire spins freely Slotted jam Insert Cotter Pin through hole in Axle and bend it so Axle Nut cannot come off Make sure Tire spins freely Tap Dust Cap onto Tire with a soft faced...
  • Page 35 Assembly Instructions Step 7 Valve plate Install the Valve Plate to the Beam Assembly. Use 3/8” x 1” Bolts and 3/8” Flange Nut. 3/8” x 1” bolts 3/8” flange nuts Beam assembly Valve plate Step 8 Install the Hose Barb Elbow to the Control Valve port marked “Out”.
  • Page 36 Assembly Instructions Step 10 Control valve Attach the Cylinder Hoses to the Control Valve. Use Teflon Tape on Hose Threads. Attach the Long Cylinder Hose to the Control Valve Port marked “B”. Attach the Short Cylinder Hose to the Control Valve Port marked “A”. Short hose Long hose * Pump Hose removed for Clarity...
  • Page 37 Assembly Instructions Step 12 Attach the Cylinder Hoses to the High Long hose Pressure Fittings. Short hose High pressure fittings Control valve Step 13 Connect the Long Low Pressure Hose to the Hydraulic Tank Assembly and the Control Long hose Valve with the Hose Clamps.
  • Page 38 Assembly Instructions Step 16 Attach coupler to Tow Leg Assembly using (2) ½” x 3” bolts and (2) ½” Class G Flange Nuts. Tighten Bolts to a 90 lb-ft torque. Coupler ½” nuts Tow leg assembly ½” x 3” bolts Step 17 Attach safety chains to beam using 3/8”...
  • Page 39 This page has intentionally been left blank.
  • Page 40 Manufactured by Northern Tool + Equipment Co., 2800 SouthCross Drive West P.O. Box 1499 Burnsville, MN 55337-0499 Made in the USA...
