Automatic Transfer Switch Systems
Installation, Operating and Maintenance Instructions
Model ATS1001D
Model ATS1001R
NOTE TO INSTALLER: Please leave this manual with the customer for future reference.
Una versión en español de este manual está disponible para descargar en nuestra página web www.gen-
MODEL NUMBER ___________________________________SERIAL NUMBER ________________________________________________________
DATE OF INSTALLATION ______________________________DEALER NAME/PHONE ___________________________________________________
Please note your model number and serial number here for future reference. The serial number may be found inside the
enclosure, lower left or right.
OVATION™ Series Automatic Transfer Switches should NOT be used for Emergency Systems
(See NEC Articles 517 and 700), nor as a Legally Required System (see NEC Article 701), nor for
primary power in place of the electric utility or in life support applications.
OVATION™ Series
For Models:
• ATS1001D, ATS1001R
• ATS2001D, ATS2001R
• ATS2002R
Model ATS2001D
tran.com/support/installation
Model ATS2001R
Model ATS2002R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GenTran OVATION ATS1001D
Summary of Contents for GenTran OVATION ATS1001D
- Page 1 OVATION™ Series Automatic Transfer Switch Systems Installation, Operating and Maintenance Instructions Model ATS1001D Model ATS1001R NOTE TO INSTALLER: Please leave this manual with the customer for future reference. Una versión en español de este manual está disponible para descargar en nuestra página web www.gen-...
-
Page 2: Safety Precaution Definitions
Every effort has been made to ensure the accuracy and completeness of the information in this manual. GenTran reserves the right to change and update the manual and product at any time without prior notice. -
Page 3: Table Of Contents
1.1 General Description ... 4 1.2 Standard Configurations ... 5 1.3 Typical Installations... 5 1.4 How the OVATION™ Series Automatic Transfer Switch Works ... 6 1.5 Key Components... 7 1.6 Standards Compliance ... 10 SECTION 2 – COMPATIBLE EQUIPMENT... 11 2.1 Compatible Generators... -
Page 4: Section 1 - Introduction
(utility), the transfer switch system transfers the load to the secondary (generator) source. Once utility power is restored to the home or building, the transfer switch transfers the load back to the normal source, and initiates generator engine shutdown. -
Page 5: Standard Configurations
Incorrect connection of a central air conditioning/heat pump system to an OVATION™ Series ATS can be dangerous, and may cause damage to the transfer switch, generator, or air conditioning/heat pump equipment, and will void all warranties. Late model (2007+) air conditioning/heat pump compressors may require modification with Hard Start Kits to ensure proper startup under generator power. -
Page 6: How The Ovation™ Series Automatic Transfer Switch Works
1) When the utility power fails or drops below 190 volts or 54 Hz or exceeds 280 volts or 66 Hz, the OVATION™ Automatic Transfer Switch will begin the generator starting sequence after a 5-second delay. 2) Once the generator is started, the system is programmed to allow the generator to warm up and wait for possible successful utility power grid re-strike (approx. -
Page 7: Key Components
PowerPause™ Load Management modules in reverse priority order until the connected load is less than 85%. Those appliances that are “locked out” by the transfer switch will stay “locked out” for 5 minutes before the transfer switch will attempt to re-power the PowerPause™... - Page 8 1.5 Key Components: (continued) Neutral Bar Generator Main 200 Amp Utility Main 200 Amp Current Transformers* (CT1 + CT2) * Supplied with optional PowerPause™ Load Management Module (Model LSM) ** Not shown: ATSRK Relay Kit Model ATS2002R** [ Circuit Breaker Spaces - 4] Ground Bar To Set Exercise Schedule...
- Page 9 Up to 6 connected loads based on parameters set up at installation are actively managed to optimize generator capacity utilization. As generator power capacity becomes available, the transfer switch will attempt to turn on each load controlled by PowerPause™ Load Management until the generator reaches 85% output utilization. Ideal for seasonal (i.e. air conditioning, pool equipment, etc) or intermittent (i.e.
-
Page 10: Standards Compliance
Call Factory if your installer needs the UL file number. Each OVATION™ Series ATS complies with NFPA 70 (National Electric Code) Article 702 as an “automatic transfer switch for use in Optional Standby Systems.”... -
Page 11: Section 2 - Compatible Equipment
SECTION 2 – COMPATIBLE EQUIPMENT 2.1 Compatible Generators In order for the OVATION™ Series ATS to function as designed, it must be connected to a permanently installed, automatic starting generator, with a continuous supply of fuel, such as gasoline, diesel, LPG or natural gas. Additionally, gasoline or diesel-powered generators must be equipped with automatic choke and electric/remote start. -
Page 12: Section 3 - Preparing For Installation
Standard, Arc-fault, GFCI or Surge protection circuit breakers for branch circuits. If Arc-fault, GFCI or Surge protection circuit breakers are used as the branch circuit protector in the main load center, they MUST be used in the transfer switch. See Section 2.2 for compatible breakers. - Page 13 NOTE: Critical loads that MUST operate when required should NOT be connected to a PowerPause ™ Load Management Module. It is recommended that the generator and transfer switch be sized properly to power ALL critical loads without the need for load management.
- Page 14 Examples of critical loads that are NOT recommended (NOT OK) to be connected to the PowerPause ™ Load Management Module and Relay Box are: • Refrigerators and freezers • Aquariums • Central heating systems (gas, oil, electric) • Furnace fan (air handler) •...
-
Page 15: Section 4 - Installation And Wiring
SECTION 4 – INSTALLATION AND WIRING Extreme care should be taken to protect the transfer switch from drill chips, fillings, and other contaminants when making the cable entry holes and mounting the enclosure to prevent component damage or a future malfunction. - Page 16 INTERNAL WIRING DIAGRAMS MODELS ATS2001D/R: Diagram 4.2...
- Page 17 INTERNAL WIRING DIAGRAMS MODEL ATS2002R: Diagram 4.3...
-
Page 18: Standard Mounting Procedures
4.1 Standard Mounting Procedures 4 .1.1. As Service Equipment and/or primary Load Center Panel: Models ATS1001D/R, ATS2001D/R or ATS2002R: When using the transfer switch as Service Entrance Equipment, mount the OVATION™ Series ATS as close as possible to the utility meter. - Page 19 4.1.2. As a Generator subpanel: Models ATS1001D/R: If using the Ovation™ Series ATS as a generator sub panel, mount the transfer switch as close to the load center as possible. The OVATION™ ATS can be installed on either the left or right side of the load center. If flush-mounting is desired, the OVATION™ ATS can be mounted in the adjacent stud space next to the existing load center.
-
Page 20: Mounting Procedure For Two Load Centers
If the generator is a 2-wire control system, use a 3-wire conductor to ensure a -12VDC signal is wired to the transfer switch on PIN 1. If 3-wire conductor is not available, install a jumper between PIN 1 and the ground bar in the OVATION™... -
Page 21: Connecting The Low Voltage Cable To The Generator
Some generators use 2, others 4 control wires. Refer to the generator installation manual for proper connection. Connect the PIN 1 wire from the transfer switch to the battery “–“ (negative) terminal. If there is no battery terminal block, run the PIN 1 wire to the “–“... - Page 22 Hold at 30° angle, push onto bus stabs c. Lower outside end flush with enclosure. d. Slide Control Module ½” towards enclosure outside edge, lock into place. e. Install (if required) circuit breaker opposite Control Module. 9. Route and dress wires in gutter of transfer switch enclosure.
-
Page 23: Section 5 - Programming The System
If transferring the load during generator exercise is required, on the User Display, press TRANSFER, then immediately press the SERVICE switch. LED 5 flashes once when properly set. To set back to NO transfer during generator exercise, press TRANSFER, then immediately press the SERVICE switch. -
Page 24: User Interface Display/Control Module Functions
5.4 User Interface Display/Control Module Functions Each OVATION™ ATS User Interface Display has five (5) buttons that program and control the automatic transfer switch and control certain generator functions. NOTE: The generator may also have controls that program certain generator features that are NOT programmable from the OVATION™... -
Page 25: Section 6 -Startup And Testing
Turn OFF the service equipment disconnect in the transfer switch or feeding the transfer switch. This will simulate a utility power interruption. After a 5 second delay, the OVATION™ transfer switch will attempt to start the generator. Use a digital volt meter to verify generator voltage at GENERATOR MAIN circuit breaker lugs. Verify the following: Turn ON service disconnect that was turned OFF in Step 1 above. -
Page 26: Re-Installing Covers And Labeling Circuits
1) Determine where branch circuit breakers have been installed and remove the required dead-front twist-outs. All dead-front openings must be covered with circuit breakers or with filler plates. Order GenTran PN 51022 for additional filler plates. 2) Install dead front cover on enclosure with screws provided. For Models 1001 and 2001, any excess openings between circuit breakers and twist out openings must be corrected by adjusting the two screws on the inside of door or adjusting the depth of the box. -
Page 27: Section 7 - Troubleshooting
Check generator oil level alert and refill reservoir if necessary. Check generator battery for low or dead cell. Check all power cord and cable connections. Generator main circuit breaker (on generator) should be in the ON position and run switch should be in AUTO position. 7.2 Troubleshooting Guide PROBLEM POSSIBLE CAUSE A. - Page 28 1. Reset computer by pressing RESET button on controller module. (Note: User custom programming is retained in ROM) 2. Replace Control Module. Call GenTran. 1. Change to desired delay. 2. Install an Uninterruptible Power System (UPS) on critical appliances to ensure continuous power.
-
Page 29: Section 8 - Maintenance And Service
GENERATOR START DELAY AFTER UTILITY LOSS: 8.3 Product Registration Complete enclosed Product Registration card and mail to GenTran to ensure you receive notification of product updates/bulletins. 8.4 Exploded Views and Replacement Parts List Incorrect parts replacement and/or service can result in severe personal injury, death and/or equipment damage. Use only recommended GenTran service parts. - Page 30 22-22 510081 Circuit breaker 100A, 2 pole, 120/240V, 22K AIC 51037 Warranty Reply Card/Product Registration, not shown 51147 Label, GENTRAN, silver/green (340), not shown 72006 Label, "Gen, Util", not shown 72009 Label, Serial Number, not shown 72010 Label, SN, controller, not shown...
- Page 31 Circuit breaker 100A, 2 pole, 120/240V, 22K AIC 51037 Warranty reply card, not shown 51080 Options Order Sheet, not shown 51147 Label, GENTRAN, silver/green (340), not shown 72005 Label, "Gen, Util", not shown 72009 Label, SN, not shown 72010 Label, SN, Control Module, not shown...
- Page 32 Deadfront, 2001D,modified, loadcenter 40/40 51037 Warranty reply card, not shown 51102 Circuit breaker 125A, 2 pole, 120/240V 51147 Label, GENTRAN, silver/green (340), not shown 72006 Label, "Gen, Util", not shown 72009 Label, SN, not shown 72010 Label, SN, controller, not shown 72915 Screw, 8-32x.5, FLAT TH, SS, SMS...
- Page 33 Warranty reply card, not shown 51080 Options Order Sheet, not shown 51102 Circuit breaker 125A, 2 pole, 120/240V, 10K AIC 51147 Label, GENTRAN, silver/green (340) , not shown 72006 Label, "Gen, Util", not shown 72009 Label, SN, not shown 72010...
- Page 34 27-22 511011 Circuit breaker 200A, 2 pole, 120/240V, 22K AIC 51121 Screw, Thumb grip, SS, 8-32x1.125" 51147 Label, GENTRAN, silver/green (340) , not shown 510950 Pigtail, neutral bond, 4AWG, green, 6" 72008 Label, "Gen, Util", ATS2002R, not shown 72009 Label, SN, not shown...
-
Page 35: Part Number Description
OPTIONAL ITEMS FOR YOUR OVATION™ ATS – AVAILABLE FROM GENTRAN CORPORATION: PART NUMBER DESCRIPTION PowerPause™ Load Management Module Kit with Current sense cable For up to 2 x 240V circuits up to 50 amps (or 4 x 120V circuits) PP30-1 PowerPause™... - Page 36 Customer Service Hours: 8:00 a.m. until 5:00 p.m. Eastern Time, Monday – Friday 07/16/10 PN 530001 Rev D © Copyright 2008-2010 Gen-Tran Corporation. All rights reserved. GenTran and the GenTran Logo are registered trademarks of Gen-Tran Corporation. Ovation and PowerPause are trademarks of Gen-Tran Corporation.
