EnGenius ECB600 Datasheet

Dual Band, Long Range
Wireless N Indoor
Access Point/
Client Bridge
Make your business network
bigger. Expand its bandwidth
and double its user capacity —
all at Wireless N speeds!
The EnGenius ECB600 is a concurrent dual band 2.4 / 5 GHz Wireless-N Indoor Access
Point that features high transmit RF power (29 dBm on 2.4GHz and 26 dBm on 5GHz)
for long range connectivity. With wireless speeds up to 300Mbps on each radio and
a Gigabit port for connecting to a switch or router it' s ideal for expanding a network
with additional bandwidth to support additional users.
The dual band Wireless-N ECB600 now enables companies to connect to more
employees, guests, staff or students more especially those who transfer large files
within the network or use other bandwidth intensive applications like streaming HD
video. The AP' s Gigabit Ethernet (10/100/1000) port also offers greater bandwidth
capacity and faster data transfers through the network. This high-powered Access
Point/Bridge with its enhanced receive sensitivity and external MIMO (Multiple In/
Multiple Out) antennas array extends wireless coverage and enhances connectivity to
client devices even in areas where connections have been previously challenging or
non-existent and in some buildings it' s wireless signal can penetrate up to 3 floors. This
makes the ECB600 ideal for extending networks within large or multi-story buildings
or expansive, client-intensive properties like hotels, resorts, hospitals, office buildings,
universities or other multi-building campus facilities.
The ECB600 can be configured to operate in several modes – as a dual band Wireless-N
Access Point, a WDS Access Point, or Repeater. It operates concurrently in the 2.4GHz
and 5GHz frequency spectrums supporting 802.11a/b/g/n standards. ECB600 also
includes EZ Controller, access point monitoring and management software that
provides a robust suite of tools for IT managers, installers and network administrators
to monitor the performance of their deployed EnGenius access points and bridges,
update them with new firmware or reconfigure the operation mode that they are in
from one central location.
www.engeniustech.com
Datasheet
ECB600

Key Features

Up to 29dBm transmit power enabling long
+
range connectivity
Supports IEEE802.11a/b/g/n wireless
+
standards with up to 300 Mbps data rate
Four detachable 5 dBi omni-directional
+
MIMO antennas
Can be monitored after deployment with
+
EnGenius EZ Controller™ software for
Windows
PoE
+
Dual Band/Two Stream
+
Leader in Price/Performance
+
Band Steering
+
