Thank you for purchasing a DX Antenna product.
Please read this instruction manual carefully prior to using the product to ensure proper understanding and usage.
Keep this manual in a safe place for future reference.
AMPLIFIED INDOOR ANTENNA
(UHF•VHF•FM)
SK-24AU
FEATURES & BENEFITS
Twelve-Position Reception Tuning (Variable Direction)
Built-in Low-Noise Amplifier
Capable of receiving High Definition TV (HDTV) broadcasts
Retractable VHF dipoles tilt and rotate for improved reception
One-touch Connector
Non-Slip Rubber pads
NAME OF PARTS
23.7" Retractable and
Caps
VHF Adjustable Dipoles Antennas
Non-slip Rubber Pads
The followings indicate a potentially hazardous situation that could result in serious injury or death if the
instructions are ignored and the product is handled incorrectly as a result.
Do not tamper with the interior of the antenna by opening the case or disassembling the antenna.
This can cause an electric shock or injury. For inspection, adjustment or repair of the interior,
contact a retailer or a business that provides this service.
UHF Loop (Tilting)
Antenna
Reception Tuning Knob
LED Power Indicator
IMPORTANT SAFEGUARDS
One-touch
Connector
AC Adapter
WARNING
DC Jack
Integrated Coaxial Cable (59")
Adapter Cable (70")
Adapter Plug
