w w w . w e s t m o u n t a i n r a d i o . c o m
Super PWRgate PG40S
Owners Manual
March 28, 2008

Introduction

Thank you for purchasing the Super PWRgate....the high power OR-gate with a built in four-stage battery
charger. It makes a true solid state UPS for the ham shack.
The Super PWRgate eliminates the danger of connecting a power supply directly across a battery. Many
power supplies will be damaged if this is done. The Super PWRgate also avoids introducing hum and RF
interference, caused by most lead acid battery chargers, by using a standard power supply. Furthermore
most lead acid battery chargers are designed for flooded lead acid marine or automotive batteries and are
inappropriate for charging sealed lead acid gel and AGM type batteries. The Super PWRgate will extend
the life span of a sealed lead acid battery compared to using a flooded lead acid charger.
The Super PWRgate transfers 40 amperes at 12 Volts dc continuously in a very safe manner. It connects
a battery and a power supply to a load, while electrically isolating both the battery and the supply from
each other. Whenever the power supply is on, the supply feeds the load. It also charges the battery with
a high-current four-state safe battery charger.
Whenever the power supply is off, the battery feeds the
load. If either the power supply or the battery is malfunctioning, neither draws current from the other.
Switching is instantaneous.
A Super PWRgate is very useful in the ham shack, and even more useful in a repeater installation.
Communication equipment will remain operative during ac power blackouts and power supply failure.
Power supplies and batteries can be swapped out while equipment remains on. No glitches.
Additionally, the Super PWRgate and a power supply may be used solely as a permanently installed
battery charger. This also may be configured to run a radio station directly from the battery, as described
by W1ZR in QST, December 2003.
Before installing the Super PWRgate, please read the following instructions.

Choosing a mounting location

Pick a location that is close, or central to, your power supply, battery, and load or 12volt distribution panel.
Radios and many 12 volt devices draw large amounts of current. Remember, all wires have resistance so
they must be kept as short as possible and should have large wire size in order to minimize the voltage
drop.
The Super PWRgate can be installed in any orientation in a cool dry location preferably well ventilated.
Do not tightly enclose the unit because the heat sink will become quite warm under maximum current. It
will rise about 40 degrees Fahrenheit over ambient temperature at 40 A continuous current in free air. Do
not place it in direct sunlight; it will absorb the suns rays and get unnecessarily hot.
The Super PWRgate can be mounted using number 8 hardware in the two mounting holes.
3 4 S m i t h S t r e e t , N o r w a l k , C o n n e c t i c u t 0 6 8 5 1 p h o n e : 2 0 3 8 5 3 8 0 8 0 f a x : 2 0 3 2 9 9 0 2 3 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Super PWRgate PG 40S and is the answer not in the manual?

Questions and answers

Summary of Contents for West Mountain Radio Super PWRgate PG 40S

  • Page 1: Choosing A Mounting Location

    w w w . w e s t m o u n t a i n r a d i o . c o m Super PWRgate PG40S Owners Manual March 28, 2008 Introduction Thank you for purchasing the Super PWRgate….the high power OR-gate with a built in four-stage battery charger.
  • Page 2: Connecting The Power Supply

    The power supply wire should be heavy gauge and as short as possible. We suggest #10 wire, 6 feet long, or preferably 3 feet long. Most power supplies have ¼ inch studs. Note that West Mountain Radio carries 3 and 6 ft long power supply cables, #10 red and black insulated wire, with 1/4 in ring terminals on one end and powerpoles on the other.
  • Page 3 5/16 inch studs. Therefore, we recommend a short 3 foot #10 wire, Powerpoles on one end, an in-line fuse (40 A max), and ring terminals for the battery end. West Mountain Radio carries a battery fuse kit, wire, and Powerpoles.
  • Page 4 If you have an ammeter on the supply it will show current. We recommend using an in-line meter, such the Power Analyzer, which is sold by West Mountain Radio. It measures volts, amperes, watts, ampere-hours, and watt-hours simultaneously.
  • Page 5 The charger is a very safe battery charger. It supplies the rated current if the battery is heavily discharged. The current drops in a smooth and progressively diminishing manner as the battery nears full charge. Note that the charger is a feedback device and it cannot overcharge a 12 volt battery. Also, it will not charge a battery that has a dead cell.
  • Page 6 If the radio station is connected directly to the battery and not through the Super PWRgate output, then the battery will supply the load while the battery is being charged. In fact, the current will be shared between the load and the battery. This method of powering a radio station was described by W1ZR in an article in QST, Dec 2003.
  • Page 7 Choosing and Setting the Maximum Charge Current The charger has three internal current sensing resistors that can be activated for determining the maximum current limit. We have chosen to use 40A fuses* as the high current switch. Note that leaving the fuses out provides a charge current of 1 ampere.
  • Page 8: Specifications

    Specifications Maximum Voltage: 18 Volts dc Maximum Current: 40 Amperes Circuit: Diode OR-Gate Diodes: Two Schottky 80 Ampere, 20 Volt Voltage Drop: 0.25 Vdc Quiescent 0.50 Vdc at 40 Amperes Charging Circuit: Charging regulator IC Field Effect Pass Transistor Schottky Diode Fuse switched for 1, 4, 7, or 10 Amperes ( +2,-8%) maximum Peak voltage limit: 13.8 (Gelled Cells), 14.2 (AGM), (+,-2%) Peak voltage terminate point: 1/10 maximum current...
