JBL C29AV-1/WH Technical Manual

Technical Manual
JBL C29AV-1/WH

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Power Capacity:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet
• Grille:
• System DC Resistance:
•
Low Frequency
Transducer:
• DC Resistance:
• Transformer Taps:
PACKAGE
Specification Sheet
337716-001
Screw (4)
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
8 Ohms
300W Continuous Program
150W Continuous Pink Noise
40 Hz – 19 kHz (–10dB)
91 dB, 1 Watt @ 1 Meter
3rd Order High Pass,
2nd Order Low Pass With
Impedance Compensation
2.5 kHz Crossover
Enclosure (Not for Sale)
337703-001, 337841-001 (WH)
5.9 ohms
200mm (8 in.) Kevlar Cone
(337646-001)
5.0 ohms
70V: 110W, 55W, 28W, and 14W
100V: 110W, 55W, and 28W
Thru Position 8 ohms Nominal
Warranty 59660
Owners Manual
337715-001
MTC-PC2
337710-001
Nylon Invisiball
Assembly
337711-001
337842-001 (Wh)
Wrench
337712-001
6mm x 10"
Polybag
End Pad,
Top and Bottom
337709-001
Install Kit
for Eyebolts
337714-001
Carton
337720-001
SYSTEM COMPONENTS:
• High Frequency
Transducer:
• DC Resistance:
• Crossover Network/
Terminal Cup:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
•
Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

Speaker,
High Freq
2413H
(337663-001)
Speaker,
Low Freq
337646-001
Fuse
337836-001
(CONT'D)
2413H,25 mm (1 in.) Compression
Driver, Pure Titanium Diaphragm
3.7 ohms
361414-001
337692-001
7.0V Input, 20 Hz to 20 kHz
7.0V Input, 20 Hz to 1 kHz
.75V Input, 1.2 kHz to 10 kHz
520 x 306 x 277 mm D
(20.5 x 12.0 x 10.9 in. D)
38.8 lb (14.0 kg.)
RED
BLK
Network
361414-001
RED
BRN
SCHEMATIC 361414-001
10-11
