PN: xxxxxxxxx
Insert Barcode
Copyright © 2012 Nokia Siemens Networks. All rights reserved.
Nokia is a registered trademark of Nokia Corporation, Siemens is a registered trademark
of Siemens AG. The wave logo is a trademark of Nokia Siemens Networks Oy.
Other company and product names mentioned in this document may be trademarks of
their respective owners, and they are mentioned for identification purposes only.
Nokia Siemens Networks Corporation, Karaportti 3, FI-02610 ESPOO, Finland
1. Plug the power and network cables into the device.
2. Plug the network cable into the broadband router.
3. Plug the power supply into the main socket.
4. The green light will stop flashing when the device is ready
to use. It may take a few minutes to complete the
Rear Panel
Broadband
Router
Installation Procedure
Power Supply
Main
Socket
Network
FAPr-hsp 5000
User Manual
process. If the green light does not stop flashing after 30
minutes, please call the operator for help.
5. For the complete User Manual, please log on to
http://www.nokiasiemensnetworks.com/manuals
Power Cable
Cable
Device
Page 1 of 3
Advertisement
Summary of Contents for Nokia Siemens Networks FAPr-hsp 5000
-
Page 1: User Manual
Nokia is a registered trademark of Nokia Corporation, Siemens is a registered trademark of Siemens AG. The wave logo is a trademark of Nokia Siemens Networks Oy. Other company and product names mentioned in this document may be trademarks of their respective owners, and they are mentioned for identification purposes only. -
Page 2: Package Contents
Package Contents 3G Access Point Ethernet cable Main power supply LEDs Front-Mounted LED This device has 1 LED. Femto (Green / Red / Off) LED State Definition Power on. Green Fast Flashing Initialization or temporarily out of service. Slow Flashing One or more calls are currently active. -
Page 3: Faq
Frequently Asked Questions (FAQs) “How many mobile phones can communicate with the Femtocell Access Point (FAP)?” The FAP can handle voice calls or data sessions for up to eight mobile devices at a time. These can be defined when purchasing the FAP to restrict the use to certain phones. Guests can be added at a later date if required.
