- Page 1 SETUP GUIDE Model: OCZDIY17B1 Series...
- Page 2 DIY GAMING NOTEBOOK DIY Notebook Quick Installation Guide...
- Page 3 DIY GAMING NOTEBOOK Installing / Replacing Storage Drive One of the two drive bay covers is labeled “HDD1” for the primary drive while the second one is...
- Page 4 DIY GAMING NOTEBOOK...
- Page 5 DIY GAMING NOTEBOOK...
- Page 6 (circled), which are used for fastening the SSD to the bracket and one silver screw (arrowhead) is used for securing the bracket into storage drive compartment. Also have your OCZ SSD ready for the best storage performance. For your reference, the bracket and SSD are shown according to how they...
- Page 7 DIY GAMING NOTEBOOK...
- Page 8 DIY GAMING NOTEBOOK Insert the SSD/bracket assembly into the bay as shown in the picture. Slide the SSD to the right and engage the edge connector in the SATA socket.
- Page 9 DIY GAMING NOTEBOOK Tighten the SSD bracket with the silver screw as shown in the picture. Carefully replace the cover and fasten with the appropriate screw. Repeat the same process when...
- Page 10 DIY GAMING NOTEBOOK Installing/Replacing The Memory:...
- Page 11 DIY GAMING NOTEBOOK This will expose the motherboard with the memory sockets:...
- Page 12 DIY GAMING NOTEBOOK module into the slot.
- Page 13 DIY GAMING NOTEBOOK Insert your OCZ SODIMMs into the vacant slots at approximately 45 angles as shown below. Note that the memory must be fully inserted into the slots.
- Page 14 DIY GAMING NOTEBOOK...
- Page 15 DIY GAMING NOTEBOOK Installing/Replacing the CPU:...
- Page 16 DIY GAMING NOTEBOOK First, remove the blower by removing the two black screws (arrowheads) and unplugging the blower power connector (arrow) from the motherboard.
- Page 17 DIY GAMING NOTEBOOK Next, unscrew the seven screws (arrowheads) securing the CPU/Chipset cooler. Remove the screws following the numbering scheme next to the screws.
- Page 18 DIY GAMING NOTEBOOK...
- Page 19 DIY GAMING NOTEBOOK If no CPU is present, you see the CPU socket exposed as shown below. Note that a locking screw...
- Page 20 DIY GAMING NOTEBOOK Please ensure that the notch on the screw faces the “unlocked” symbol on the CPU socket before...
- Page 21 DIY GAMING NOTEBOOK...
- Page 22 DIY GAMING NOTEBOOK...
- Page 23 CPU heat sink interface. If the cooler needs to be reseated or a new CPU is installed as replacement of the previous one, please clean both CPU and the cooler from any residual TIM pad and apply new thermal compound like OCZ FreeZe to the CPU.
- Page 24 DIY GAMING NOTEBOOK Carefully re-assemble the system in reverse order: Install the CPU/Chipset cooler and fasten the screws following the numbering scheme next to the screws. Install the blower and make sure the blower power socket is connected as shown in the picture. Carefully replace the cover and fasten all necessary screws.
- Page 25 DIY GAMING NOTEBOOK...
- Page 26 (408) 733-8400 Sales TECHNICAL SUPPORT For warranty support and technical information about your DIY Gaming Notebook, visit www.ocztechnology.com. All OCZ PRODUCTS include free technical support for direct, expert advice. Contact OCZ Technical support at (800) 459-1816 or email us at support@ocztechnology.com.
