Summary of Contents for BenQ MOD 9001
-
Page 1: User Manual
© 2005 Sky’s Microwave Limited Company All Rights Reserved MOD 9001 BENQ GSM/GPRS Modem User Manual Sky Microwave Co. LTD. Tel: +86-755-26483329, 26483458 Fax: +86-755-26483329 Http://www.skymicrowave.com Email:sales@skymicrowave.com PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn... -
Page 2: Read First
© 2005 Sky’s Microwave Limited Company All Rights Reserved Read First Before operating the system, please read this manual thoroughly, and retain it for future reference. Attention Please not leave the GSM/GPRS Modem and its power adapter in raining or humidity place. - Page 3 Modem. Users of this product can add wireless communication capability easily to their own products, and then, develop many applications. The MOD 9001 BENQ GSM/GPRS Modem mostly fits the need of data transfer, with SMS data communication, GPRS data navigation, Circuit Switch / Data Connectivity, TCP/IP protocol etc.
-
Page 4: Specifications
© 2005 Sky’s Microwave Limited Company All Rights Reserved 4. Specifications Operation temperature ：-25 - +60℃ Storage temperature：-35 - +80℃ Humidity ：0 - 95％ non-condense Receive Sensitivity：-102dBm Maximum Transmit Power：1W Dynamic range：62dB Frequency tolerance ：≤±0.1ppm Power supply： 5V、 7.5V、 12V optional, and can be changed according to customer’s requirement.。... - Page 5 © 2005 Sky’s Microwave Limited Company All Rights Reserved Side view (end side) Side view (front side) 6. Module EVB DOME Basic Operation A. Module connection with Hyper Terminal. à Accessories- à 1. Establish or Open Hyper Terminal from All Programs Communications and setting up relevant parameters.
- Page 6 © 2005 Sky’s Microwave Limited Company All Rights Reserved (2). Setting up usage port. (3). Setting up port parameters. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
- Page 7 © 2005 Sky’s Microwave Limited Company All Rights Reserved (4). Setting up property File Menu of Hyper Terminal PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
- Page 8 2. Insert in a valid SIM Card provided by GSM network operator or service provider. Then connect BENQ Modem with computer by RS232 port and power supply. When the Red light is flash, Module is work property. You can input word “AT” then press “Enter”...
- Page 9 © 2005 Sky’s Microwave Limited Company All Rights Reserved ：AT+VTS=（0-9，#，*，A-Z） 5. Enter information once connection established（DTMF） ：AT+VTS=1 Dial Extension number（example：1234） AT+VTS=2 AT+VST=3 AT+VST=4 6. Receive call: 7. Hang off call: 8. Incoming call ID: AT+CLIP=1 9、SMS function： ⑴ Setting up SMS Center number：AT+CSCA=“+8613800XXXXXX”...
- Page 10 © 2005 Sky’s Microwave Limited Company All Rights Reserved 4. Click Properties and select Advanced option. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
- Page 11 © 2005 Sky’s Microwave Limited Company All Rights Reserved 5. Enter AT command AT+CGDCONT=1,"IP","CMNET" into textbox. Establish Dial Connection. Dial number is *99#. User name and Password are empty. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
- Page 12 © 2005 Sky’s Microwave Limited Company All Rights Reserved Click the icon from Network Connection to initial connection. 8. After initial period, the connection is on. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
