Navpixel™ NPS1535 USER MANUAL 15” IP-65 Marine Display Panel PC Sunlight Readable LED B/L LCD (1st Edition 2/18/2009) All information is subject to change without notice. Approved by Checked by Prepared by Ming Hank Jacky Page 1...
TABLE OF CONTENT RECORD OF REVISION ......................2 1.0 INTRODUCTION......................5 2.0 SAFETY ........................7 3.0 9PRODUCT CARE AND MAINTENANCE ................9 4.0 PACKAGING CONTENTS....................11 5.0 CONNECTORS......................12 6.0 INSTALLATIONS ......................13 7.0 OSD Operation Buttons ..................... 14 8.0 Award BIOS Setup ....................16 9.0 Driver Installation ......................
Page 4
USAGE NOTICE Precautions To maximize the life and safe use of your unit, always be sure to follow the warnings, precautions and maintenance recommendations in this user’s guide. In a Watercraft or Vehicle: The panel PC should be visible to the driver only if it is used for navigation, or system control.
1.0 INTRODUCTION 1.1 About Navpixel™ Marine Display Panel PC Navpixel™ NPS1535, the high-performance, rugged touch panel PC Panel PC, is specially engineered to survive the most demanding applications. You will soon become familiar with the quality difference in this bright sunlight readable (0.5 to 1,000 nits) panel PC.
Page 6
1.5 System GENERAL SPECIFICATI0NS: System ® Processor Supports Intel Core 2 Duo (Merom)/ Core Duo/ Core Solo/ Celeron M (Yonah) Processors System Memory 240-pin DIMM x 2, DDRII 400/533/667 up to 4GB ® Chipset Intel 945GM + ICH7M (-DH optional for RAID) Ethernet Intel 82573L 10/100/1000Base-TX, RJ-45 x 2 BIOS...
2.0 SAFETY GENERAL SAFETY INSTRUCTIONS • Before operating the Navpixel™ NPS1535 Panel PC Panel PC, read this user manual thoroughly • Keep this user manual for future use • Verify the computer system capability (see Packaging Contents & Installation) to insure operation of the Panel PC •...
Page 8
• Do not disassemble or modify the unit to avoid the possibility of electrical shock, damage to its electrical components or scratching the display surface, and • Disassembly voids the warranty. Servicing – Navpixel™ Qualified Service Personnel may be required if the unit: • Does not operate normally when installation instructions are followed •...
3.0 PRODUCT CARE AND MAINTENANCE PRODUCT CARE This Navpixel™ NPS1535 Marine Display has been designed to provide optimum performance and service without any required scheduled maintenance other than occasional cleaning. Disconnect the Monitor from the power source before cleaning the Monitor, Touch Screen or unit’s enclosure.
Page 10
• For Flush or Panel Mount units, cover the product with a protective covering that will not scratch or transfer any dyes to the display screen. MAINTENANCE Power Cord To avoid shock and fire hazards, replaced the unit’s power cord if: .Insulation becomes damaged, or WARNING! .A loose connection is suspected.
4.0 PACKAGING CONTENTS The Navpixel™NPS1535 is shipped in a box with PE foam packaging. It is recommended the installer save the box and all packaging materials in case the unit would need to be returned to the Service Center or local dealer. (Figure 1) One Navpixel™...
5.0 CONNECTORS 5.1 CONNECTORS Connectors are located on the bottom of the unit housing, from left to right (Figure 2): Connectors are physically unique to insure the installer makes the proper connections. (Figure 2) Page 12...
The back of the panel PC includes mounting points that you can use to mount the panel PC as your installation requires. Mounting holes on the Navpixel™ NPS1535 allow the panel PC to be mounted by rear mounted using VESA75 or VESA100 mount Mounting from rear: VESA75 (4 hole pattern).
7.0 OSD Operation Buttons Your Sunlight Readable panel PC can be controlled using the manual buttons on the front bezel of the unit. The manual enables you to change the way in which your display is set up brightness using the manual buttons. Power on/off button Power on: To press the POWER button for start PC system.
Page 15
HDD LED button The HDD LED is for the PC system access status light. Light Sensor The light sensor is used to detect the ambient light and then adjust the brightness automatically. Brightness Up Dimming up the display brightness. Brightness Down Dimming down the display brightness.
8.0 Award BIOS Setup Awards BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. Entering Setup Power on the computer and press <Del>...
Page 17
Frequency/Voltage Control Use this menu to specify your settings for auto detect DIMM/PCI clock and spread spectrum. Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. Load Optimized Defaults Use this menu to load the BIOS default values that are factory settings for optimal performance system operations.
9.0 Driver Installation Insert the driver CD, please follow the sequence below to install the drivers. Follow the sequence below to install the drivers: Step 1 – Install INF Driver Step 2 – Install VGA Driver Step 3 – Install LAN Driver Step 4 –...
Page 19
Step 5 – Install SATA Driver 1. Click on the Step 5- ICH7M-GHM SATA Driver Folder 2. Select the Win OS folder and then double click on iatabl_cd.exe 3. Follow the instructions that the windows shows 4. The system will help you install the driver automatically Page 19...
