Summary of Contents for Ematic ED909
-
Page 2: Table Of Contents
Safety Precautions Table Of Contents Thank you for choosing our portable DVD player. It includes a 9" display and built-in DVD player. This units is designed for use at home or on the go. Please read the manual Safety Precautions carefully prior to use and keep it for future reference. -
Page 3: Package
Package This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that DVD Player may cause undesired operation. -
Page 4: Main Unit Controls
System Connection Main Unit Controls Powering and installation Plug one end of the AC/DC power adaptor into the DC IN 9-12V jack on the right of the unit, then plug the other end into the AC power receptacle. Please refer to the following illustration. - Page 5 Connecting to monitor Connecting with external Speaker The unit can be connected to external speakers. Please see the following illustration. The unit can also be connected to the external LCD monitor. Connect the unit to power by AC/DC adapter or cigarette lighter adapter. Then connect the unit DC OUT jack to DC IN 9-12V Jack of the LCD Monitor by a DC/AV cable.
-
Page 6: The Remote Control
When using remote control,make sure the infrared window is pointed to infrared receiving window of the machine.The distance between machine and remote control must be within 3 metres.Please refer to the following illustration. ED909 1. Number button 11. ZOOM(To zoom in/out the image during the playback) 2. -
Page 7: Basic Operation
”to resume playback from the point where you stopped;press“ ”twice to stop playback completely. ED909 5. During playback,press“ ”to pause; press it again to resume playback. 6. When the playing is finished, please turn off the power by sliding ON/OFF switch to OFF. - Page 8 13.from four window's top side to bottom side Angle 14.from four window's left side to right side 15.from 4 edges to center ED909 5. During viewing files,“ ”may appear when pressing“Angle”or“Subtitle”or “Audio” or“A-B”or“Title”etc; in this situation these options are unavailable to operate.
- Page 9 SD/MMC/USB main menu Browser mode 00 00 03 43 001/008 \Ctyy\ ..TRACK01 TRACK02 TRACK03 TRACK04 TRACK05 After entering the SD/MMC or USB,the system will show Main Menu which includes 4 Function ICONS.You can select them by “ ” and press “ENTER”...
- Page 10 When playing JPEG : Movie mode 1.To rotate the picture counter-clockwise,press “ ”; Press“ ” to rotate the picture clockwise 2. Press OSD button when viewing pictures,you can select different refresh modes as follows: 1. from top to bottom 001/006 2.
-
Page 11: System Setup
Speed: In this item, you can set the rip speed: Normal or Fast. General Setup Page Bitrate: In this item, you can set the bitrate. It has 6 choices,128Kbps,192Kbps,256Kbps, 320Kbps, 96Kbps and 112Kbps. Create ID3:In this item, you can create ID3 when playing CD text. Device: This item indicates whether USB or SD CARD is connected with DVD player. - Page 12 Video Setup Page Video Setup Preference Setup Subtitle Select your preferred language to show the TV Type NTSC NTSC subtitles on the screen. TV Type: Quality Audio English The default is OFF Enter this option to select TV type Panel Quality Subtitle French The subtitle languages depend on the...
-
Page 13: Specification
Troubleshooting Specification Compatible disc: DVD/VCD/CD/MP3/MPEG4 Signal system: PAL/NTSC Panel size: 9 inch PROBLEM SOLUTION Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75Ohm, unbalanced Make sure the machine is connected properly. No sound or Audio output: 1.4Vrms/10kOhm Make sure all cables are securely inserted into distorted sound Audio S/N: Better than 80dB the appropriate jacks.
